Heating and Ventilation

For Diagnosis and Testing information, refer to CLIMATE CONTROL SYSTEM-GENERAL INFORMATION .

Scheme 57

Scheme 58

Scheme 59

1. Drain the cooling system. For additional information, refer to «COOLING SYSTEM»(ref-161157-S28866673372004032200000) .
2. Remove the air intake tube. For additional information, refer to «AIR CLEANER OUTLET PIPE»(ref-199543-S00056862962005101900000) .
3. Remove the receiver drier. For additional information, refer to «RECEIVER DRIER»(ref-199554-S18295220122005101900000) .
4. Disconnect the auxiliary coolant flow pump electrical connector.
5. Remove the auxiliary coolant flow pump bolts.
6. Remove the auxiliary coolant flow pump.

Scheme 60

1. To install, reverse the removal procedure.

Scheme 61

Scheme 62

Scheme 63

1. Disconnect the battery ground cable.
2. Remove the cover.
3. Remove the blower motor. Disconnect the electrical connector.
4. Remove the wheel from the blower motor. Remove the push clip.(1) Remove the wheel from the blower motor. (2)
