SPECIFICATIONS
| Application | Specification |
|---|
| Compressor Type | (1) FVS90 Variable Scroll |
| Compressor Belt Tension | (2) |
| Compressor Oil Capacity | (3) 6.1-7.4 ozs. |
| Refrigerant (R-134a) Capacity | 28.2 ozs. |
| System Operating Pressures | (4) |
| (1) Although the same type compressor is used on 3.0L and 4.0L engines, compressors are not interchangeable between engines. (2) Belt tension is automatically adjusted by belt tensioner. (3) Use PAG (WSH-MIC231-B) refrigerant oil. (4) Information is not available from manufacturer. |
| (1) | Although the same type compressor is used on 3.0L and 4.0L engines, compressors are not interchangeable between engines. |
| (2) | Belt tension is automatically adjusted by belt tensioner. |
| (3) | Use PAG (WSH-MIC231-B) refrigerant oil. |
| (4) | Information is not available from manufacturer. |
TORQUE SPECIFICATIONS
| Application | Ft. Lbs. (N.m) |
|---|
| A/C Compressor Clutch Retaining Nut | 13 (17) |
| Compressor Mounting Bolts | 18 (25) |
| Engine Compartment Cross-Brace | 18 (25) |
| Instrument Panel Bolts | 15 (20) |
| Steering Column Support Bolts | 13 (18) |
| Steering Column Lower Pinch Bolt | 22 (30) |
| Steering Wheel Center Bolt | 26 (35) |
| Thermostatic Expansion Valve (TXV) Fittings | 18 (25) |
| Wiper Arm Nuts | 13 (18) |
| INCH Lbs. (N.m) |
| Auxiliary Pump Bolt | 51 (6) |
| Compressor Manifold Bolt | 71 (8) |
| Condenser Core Mounting Bolts | 89 (10) |
| Coolant Fill Cap (4.0L) | 80 (9) |
| Driver Side Air Bag Bolts | 106 (12) |
| Evaporator Core Housing Nut/Bolt | 62 (7) |
| Heater Hose Bracket Bolt | 80 (9) |
| Horn Contact Switch Bolts | 44 (5) |
| Manifold & Tube Retaining Bolt | 71 (8) |
| Pressure Relief Valve | 106 (12) |
| Peanut Fitting Retaining Nut | 71 (8) |
| Receiver-Drier Manifold Nut | 71 (8) |
| Receiver-Drier Mounting Bracket Clamp Bolt | 62 (7) |
| Thermostatic Valve Fitting Nut | 80 (9) |
Automatic A/C-Heater System Wiring Diagram (2000-01 S-Type - 1 Of 2). Scheme 1
Scheme 1: Automatic A/C-Heater System Wiring Diagram (2000-01 S-Type - 1 Of 2)
Automatic A/C-Heater System Wiring Diagram (2000-01 S-Type - 2 Of 2). Scheme 2
Scheme 2: Automatic A/C-Heater System Wiring Diagram (2000-01 S-Type - 2 Of 2)
