Air Conditioning: Diagnosis Jaguar S-type I

Diagnosis and Testing

For additional information refer to CLIMATE CONTROL SYSTEM-GENERAL INFORMATION .

Scheme 66

Scheme 67

Scheme 68

1. Reclaim the refrigerant. For additional information, refer to «AIR CONDITIONING (A/C) SYSTEM RECOVERY, EVACUATION AND CHARGING»(ref-199551-S27055283222005101900000) .
2. Remove the accessory drive belt. For additional information, refer to «SPECIFICATIONS & DRIVE BELT ROUTING»(ref-164247) .
3. Disconnect the compressor electrical connector.
4. Detach the compressor supply and return tubes.
5. Remove the compressor O-rings.
6. Remove the compressor.
7. Remove the clutch and clutch field coil. For additional information, refer to «CLUTCH AND CLUTCH FIELD COIL»(ref-199554-S16227230302005101900000) .
