Automatic Transaxle: Diagnosis Infiniti M45 II

DTC No. Index

Note. If DTC U1000 is displayed with other DTCs, first perform the trouble diagnosis for DTC U1000. Refer to DTC U1000: CAN COMMUNICATION LINE .

Scheme 53

Precautions for On Board Diagnostic (OBD) System of A/T and Engine

The ECM has an on board diagnostic system. It will light up the malfunction indicator lamp (MIL) to warn the driver of a malfunction causing emission deterioration.

OBD-II SELF-DIAGNOSIS

1. A/T self-diagnosis is performed by the TCM in combination with the ECM. The results can be read through the blinking pattern of the A/T CHECK indicator or the malfunction indicator lamp (MIL). Refer to the table on " «Self- diagnostic result test mode»(ref-181179-S22730923792005080100000) " for the indicator used to display each self- diagnostic result.
2. The self-diagnostic results indicated by the MIL are automatically stored in both the ECM and TCM memories. Always perform the procedure on " «HOW TO ERASE DTC»(ref-181179-S05429639152005080100000) " to complete the repair and avoid unnecessary blinking of the MIL. For details of OBD-II, Refer to "ON BOARD DIAGNOSTIC (OBD) SYSTEM ".
3. Certain systems and components, especially those related to OBD, may use the new style slidelocking type harness connector. For description and how to disconnect, refer to "HARNESS CONNECTOR ".

Wiring Diagrams and Trouble Diagnosis

When you read wiring diagrams, refer to the following

1. "How to Read Wiring Diagrams ".
2. "POWER SUPPLY ROUTING " for power distribution circuit.

When you perform trouble diagnosis, refer to the following

1. "How to Follow Trouble Diagnoses ".
2. "How to Perform Efficient Diagnosis for an Electrical Incident ".

HOW TO READ DTC AND 1ST TRIP DTC

DTC and 1st trip DTC can be read by the following methods. ( with CONSULT-II or GST ) CONSULT-II or GST (Generic Scan Tool) Examples: P0705, P0720 etc. These DTC are prescribed by SAE J2012.

(CONSULT-II also displays the malfunctioning component or system.)

1. 1st trip DTC No. is the same as DTC No.
2. Output of the diagnostic trouble code indicates that the indicated circuit has a malfunction. However, in case of the Mode II and GST, they do not indicate whether the malfunction is still occurring or occurred in the past and returned to normal. CONSULT-II can identify them as shown below, therefore, CONSULT-II (if available) is recommended.

A sample of CONSULT-II display for DTC and 1st trip DTC is shown. DTC or 1st trip DTC of a malfunction is displayed in SELF-DIAGNOSTIC RESULTS mode for "ENGINE" with CONSULT-II. Time data indicates how many times the vehicle was driven after the last detection of a DTC.

Scheme 54

If the DTC is being detected currently, the time data will be "O".

Scheme 55

If a 1st trip DTC is stored in the ECM, the time data will be "1t".

Scheme 56

HOW TO ERASE DTC

The diagnostic trouble code can be erased by CONSULT-II, GST or ECM DIAGNOSTIC TEST MODE as described following

1. If the battery cable is disconnected, the diagnostic trouble code will be lost within 24 hours.
2. When you erase the DTC, using CONSULT-II or GST is easier and quicker than switching the mode selector on the ECM.

The following emission-related diagnostic information is cleared from the ECM memory when erasing DTC related to OBD-II. For details, Refer to "Emission-related Diagnostic Information ".

1. Diagnostic trouble codes (DTC)
2. 1st trip diagnostic trouble codes (1st trip DTC)
3. Freeze frame data
4. 1st trip freeze frame data
5. System readiness test (SRT) codes
6. Test values

Scheme 57

1. If a DTC is displayed for both ECM and TCM, it is necessary to be erased for both ECM and TCM. If the ignition switch stays "ON" after repair work, be sure to turn ignition switch "OFF" once. Wait at least 10 seconds and then turn it "ON" (engine stopped) again. Turn CONSULT-II "ON" and touch "A/T". Touch "SELF-DIAG RESULTS". Touch "ERASE". (The DTC in the TCM will be erased.) Then touch "BACK" twice. Touch "ENGINE". Touch "SELF-DIAG RESULTS". Touch "ERASE". (The DTC in the ECM will be erased.)

HOW TO ERASE DTC (WITH GST)

1. If the ignition switch stays "ON" after repair work, be sure to turn ignition switch "OFF" once. Wait at least 10 seconds and then turn it "ON" (engine stopped) again.
2. Perform "TCM SELF-DIAGNOSTIC PROCEDURE (No Tools)". Refer to " «TCM SELF-DIAGNOSTIC PROCEDURE (NO TOOLS)»(ref-181179-S20986917652005080100000) ". (The engine warm-up step can be skipped when performing the diagnosis only to erase the DTC.)
3. Select Mode 4 with Generic Scan Tool (GST). For details, refer to "Generic Scan Tool (GST) Function ".

HOW TO ERASE DTC (NO TOOLS)

The A/T CHECK indicator lamp is located on the instrument panel.

1. If the ignition switch stays "ON" after repair work, be sure to turn ignition switch "OFF" once. Wait at least 10 seconds and then turn it "ON" (engine stopped) again.
2. Perform "TCM SELF-DIAGNOSTIC PROCEDURE (No Tools)". Refer to " «TCM SELF-DIAGNOSTIC PROCEDURE (NO TOOLS)»(ref-181179-S20986917652005080100000) ". (The engine warm-up step can be skipped when performing the diagnosis only to erase the DTC.)
3. Perform "OBD-II SELF-DIAGNOSTIC PROCEDURE (No tools)". Refer to "No Tools ".

DTC Inspection Priority Chart

DTC INDEX

If some DTCs are displayed at the same time, perform inspections one by one based on the following priority chart.

Note. If DTC U1000 is displayed with other DTCs, first perform the trouble diagnosis for DTC U1000. Refer to DTC U1000: CAN COMMUNICATION LINE .

Scheme 58

Fail-Safe

The TCM has an electrical fail-safe mode. This mode makes it possible to operate even if there is a malfunction in a main electronic control input/output signal circuit.

In fail-safe mode, even if the select lever is "D" or "M" mode, the transmission is fixed in 2nd or 4th (depending on the breakdown position), so the customer should feel "slipping" or "poor acceleration". When fail-safe mode is triggered, when the ignition switch is switched "ON", the A/T CHECK indicator lamp flashes for about 8 seconds. (Refer to " TCM SELF-DIAGNOSTIC PROCEDURE (NO TOOLS) ").

Even when the electronic circuits are normal, under special conditions (for example, when slamming on the brake with the wheels spinning drastically and stopping the tire rotation), the transmission can go into fail-safe mode. If this happens, switch "OFF" the ignition switch for 10 seconds, then switch it "ON" again to return to the normal shift pattern. Also, the A/T CHECK indicator lamp flashes for about 8 seconds once, then is cleared. Therefore, the customer's vehicle has returned to normal, so handle according to the "diagnostics flow" (Refer to DIAGNOSTIC WORKSHEET ).

Cruise test Part 1

1. CHECK STARTING OUT FROM D1 Drive the vehicle for about 10 minutes to warm up the engine oil and A/T fluid. Appropriate temperature for the A/T fluid: 50 - 80°C (122 - 176°F) Park the vehicle on a level surface. Move selector lever to "P" position. Start the engine. Move selector lever to "D" position. Press the accelerator pedal about half way down to accelerate the vehicle. With CONSULT-II Read off the gear positions. Starts from D1? YES >> GO TO 2. NO >> Enter a check mark at "Vehicle cannot be started from D1" on the diagnostics worksheet, then continue the road test.
2. CHECK SHIFT UP D1 --> D2 Press down the accelerator pedal about half way and inspect if the vehicle shifts up (D1 --> D2) at the appropriate speed. Refer to «CRUISE TEST PART 3»(ref-181179-S15909804892005080100000) . With CONSULT-II Read the gear position, throttle degree of opening, and vehicle speed. Does the A/T shift up D1 --> D2 at the correct speed? YES >> GO TO 3. NO >> Enter a check mark at "A/T does not shift D1 --> D2" on the diagnostics worksheet, then continue the road test.
3. CHECK SHIFT UP D2 --> D3 Press down the accelerator pedal about half way and inspect if the vehicle shifts up (D2 --> D3) at the appropriate speed. Refer to «CRUISE TEST PART 3»(ref-181179-S15909804892005080100000) . With CONSULT-II Read the gear position, throttle degree of opening, and vehicle speed. Does the A/T shift up D2 --> D3 at the correct speed? YES >> GO TO 4. NO >> Enter a check mark at "A/T does not shift D2 --> D3" on the diagnostics worksheet, then continue the road test.
4. CHECK SHIFT UP D3 --> D4 Press down the accelerator pedal about half way and inspect if the vehicle shifts up (D3 --> D4) at the appropriate speed. Refer to «CRUISE TEST - PART 3»(ref-181179-S02437084342005080100000) . With CONSULT-II Read the gear position, throttle degree of opening, and vehicle speed. Does the A/T shift up D3 --> D4 at the correct speed? YES >> GO TO 5. NO >> Enter a check mark at "A/T does not shift D3 --> D4" on the diagnostics worksheet, then continue the road test.
5. CHECK SHIFT UP D4 --> D5 Press down the accelerator pedal about half way and inspect if the vehicle shifts up (D4 --> D5) at the appropriate speed. Refer to «CRUISE TEST - PART 3»(ref-181179-S02437084342005080100000) . With CONSULT-II Read the gear position, throttle degree of opening, and vehicle speed. Does the A/T shift up D4 --> D5 at the correct speed? YES >> GO TO 6. NO >> Enter a check mark at "A/T does not shift D4 --> D5" on the diagnostics worksheet, then continue the road test.
6. CHECK LOCK-UP When releasing accelerator pedal from D5, check lock-up from D5 to L/U. Refer to «CRUISE TEST - PART 3»(ref-181179-S02437084342005080100000) . With CONSULT-II Select "TCC SOLENOID 0.00A" with the "MAIN SIGNAL" mode for A/T. Refer to " «CONSULT-II REFERENCE VALUE»(ref-181179-S30931068782005080100000) ". Does it lock-up? YES >> GO TO 7. NO >> Enter a check mark at "A/T does not perform lock-up" on the diagnostics worksheet, then continue the road test.
7. CHECK LOCK-UP HOLD Does it maintain lock-up status? YES >> GO TO 8. NO >> Enter a check mark at "A/T hold does not lock-up condition" on the diagnostics worksheet, then continue the road test.
8. CHECK LOCK-UP RELEASE Check lock-up cancellation by depressing brake pedal lightly to decelerate. With CONSULT-II Select "TCC SOLENOID 0.00A" with the "MAIN SIGNAL" mode for A/T. Refer to " «CONSULT-II REFERENCE VALUE»(ref-181179-S30931068782005080100000) ". Does lock-up cancel? YES >> GO TO 9. NO >> Enter a check mark at "Lock-up is not released" on the diagnostics worksheet, then continue the road test.
9. CHECK SHIFT DOWN D5 --> D4 Decelerate by pressing lightly on the brake pedal. With CONSULT-II Read the gear position and engine speed. When the A/T shift down D5 --> D4, does the engine speed drop smoothly back to idle? YES >> Stop the vehicle. Go to Cruise test - Part 2 (Refer to «CRUISE TEST PART 2»(ref-181179-S21983805132005080100000) ). NO >> Enter a check mark at "A/T does not shift down" on the diagnostics worksheet, then continue the road test. Go to Cruise test - Part 2 (Refer to «CRUISE TEST PART 2»(ref-181179-S21983805132005080100000) ).

Cruise test Part 2

1. CHECK STARTING FROM D1 Move selector lever the "D" position. Accelerate at half throttle. With CONSULT-II Read the gear position. Does it start from D1? YES >> GO TO 2. NO >> Enter a check mark at "Vehicle cannot be started from D1" on the diagnostics worksheet, then continue the road test.
2. CHECK SHIFT UP D1 --> D2 Press the accelerator pedal down all the way and inspect whether or not the transmission shifts up (D1 --> D2) at the correct speed. Refer to «VEHICLE SPEED WHEN SHIFTING GEARS»(ref-181179-S37556727542005080100000) . With CONSULT-II Read the gear position, throttle position and vehicle speed. Does the A/T shift up D1 --> D2 at the correct speed? YES >> GO TO 3. NO >> Enter a check mark at "Vehicle does not shift D1 --> D2" on the diagnostics worksheet, then continue the road test.
3. CHECK SHIFT UP D2 --> D3 Press the accelerator pedal down all the way and inspect whether or not the transmission shifts up (D2 --> D3) at the correct speed. Refer to «VEHICLE SPEED WHEN SHIFTING GEARS»(ref-181179-S37556727542005080100000) . With CONSULT-II Read the gear position, throttle position and vehicle speed. Does the A/T shift up D2 --> D3 at the correct speed? YES >> GO TO 4. NO >> Enter a check mark at "Vehicle does not shift D2 --> D3" on the diagnostics worksheet, then continue the road test.
4. CHECK SHIFT UP D3 --> D4 AND ENGINE BRAKE When the transmission changes speed D3 --> D4, return the accelerator pedal. Does the A/T shift up D3 --> D4 and apply the engine brake? YES >> Stop the vehicle. Go to Cruise test - Part 3 (Refer to «CRUISE TEST - PART 3»(ref-181179-S02437084342005080100000) ). NO >> Enter a check mark at "Vehicle does not shift D3 --> D4" on the diagnostics worksheet, then continue the road test.

Cruise test Part 3

1. MANUAL MODE FUNCTION Move to manual mode from D position. Does it switch to manual mode? YES >> GO TO 2. NO >> Continue road test and add check mark to "Cannot be changed to manual mode" on diagnostics worksheet.
2. CHECK SHIFT DOWN During manual mode driving, is downshift from 5 M --> 4 M --> 3 M --> 2 M --> 1 M performed? With CONSULT-II Read the gear position. Is downshifting correctly performed? YES >> GO TO 3. NO >> Enter a check mark at "Vehicle does not shift" at the corresponding position (5 M --> 4 M , 4 M --> 3 M , 3 M --> 2 M , 2 M --> 1 M ) on the diagnostics worksheet, then continue the road test.
3. CHECK ENGINE BRAKE Does engine braking effectively reduce speed in M1 position? YES >> Stop the vehicle. Carry out the self-diagnostics. Refer to " «SELF-DIAGNOSTIC PROCEDURE (WITH CONSULT-II)»(ref-181179-S39981246612005080100000) ", " «Diagnostic Procedure Without CONSULT-II»(ref-181179-S24362098842005080100000) ". NO >> Enter a check mark at "Vehicle does not decelerate by engine brake" on the diagnostics worksheet, then continue trouble diagnosis.

Scheme 59

1. At half throttle, the accelerator opening is 4/8 of the full opening.

Scheme 60

1. At closed throttle, the accelerator opening is less than 1/8.
2. At half throttle, the accelerator opening is 4/8 of the full opening.

Scheme 61

1. At closed throttle, the accelerator opening is less than 1/8.

Symptom Chart

The diagnostics item numbers show the sequence for inspection. Inspect in order from Item 1.

Scheme 62

Scheme 63

Scheme 64

Scheme 65

Scheme 66

Scheme 67

Scheme 68

Scheme 69

Scheme 70

Scheme 71

Scheme 72

Scheme 73

Scheme 74

Scheme 75

Scheme 76

Scheme 77

Scheme 78

Scheme 79

Scheme 80

Scheme 81

Scheme 82

Scheme 83

Scheme 84

Scheme 85

TCM INSPECTION TABLE

Data are reference value and are measured between each terminal and ground.

Scheme 86

Scheme 87

Scheme 88

OBD-II SELF-DIAGNOSTIC PROCEDURE (WITH GST)

Refer to "Generic Scan Tool (GST) Function "

OBD-II SELF-DIAGNOSTIC PROCEDURE (NO TOOLS)

Refer to "Malfunction Indicator Lamp (MIL) ".

Diagnostic procedure

1. CHECK A/T CHECK INDICATOR LAMP Start the engine with selector lever in "P" position. Warm engine to normal operating temperature. Turn ignition switch "ON" and "OFF" at least twice, then leave it in the "OFF" position. Wait 10 seconds. Turn ignition switch to "ON" position. (Do not start engine.) Does A/T CHECK indicator lamp come on for about 2 seconds? YES >> GO TO 2. NO >> GO TO " «A/T CHECK INDICATOR LAMP DOES NOT COME ON»(ref-181179-S33144867022005080100000) ".
2. JUDGEMENT PROCEDURE STEP 1 Turn ignition switch "OFF". Push shift lock release button. Move selector lever from "P" to "D" position. Release accelerator pedal. (Set the closed throttle position signal "ON".) Depress brake pedal. (Brake switch signal "ON".) Turn ignition switch "ON". Wait 3 seconds. Move the selector lever to the Manual shift gate side. (Manual mode switch "ON".) Release brake pedal. (Brake switch signal "OFF".) Move the selector lever to "D" position. (Manual mode switch "OFF".) Depress brake pedal. (Brake switch signal "ON".) Release brake pedal. (Brake switch signal "OFF".) Depress accelerator pedal fully and release it. >> GO TO 3.
3. CHECK SELF-DIAGNOSIS CODE Check A/T CHECK indicator lamp. Refer to " «JUDGEMENT SELF-DIAGNOSIS CODE»(ref-181179-S04139043342005080100000) ". If the system does not go into self-diagnostics. Refer to " «PARK/NEUTRAL POSITION, MANUAL MODE, BRAKE AND THROTTLE POSITION SWITCH CIRCUIT»(ref-181179-S13996516412005080100000) ". >> DIAGNOSIS END

Judgement self-diagnosis code

If there is a malfunction, the lamp lights up for the time corresponding to the suspect circuit.

Scheme 89

Erase self-diagnosis

1. In order to make it easier to find the cause of hard-to-duplicate malfunctions, malfunction information is stored into the control unit as necessary during use by the user. This memory is not erased no matter how many times the ignition switch is turned ON and OFF.
2. However, this information is erased by turning ignition switch "OFF" after executing self-diagnostics or by erasing the memory using the CONSULT-II.

On Board Diagnosis Logic

1. This is an OBD-II self-diagnostic item.
2. Diagnostic trouble code "CAN COMM CIRCUIT" with CONSULT-II or U1000 without CONSULT-II is detected when TCM cannot communicate to other control units.

DTC Confirmation Procedure

Note. If "DTC Confirmation Procedure" has been previously conducted, always turn ignition switch "OFF" and wait at least 10 seconds before conducting the next test.

After the repair, perform the following procedure to confirm the malfunction is eliminated.

Scheme 90

1. Turn ignition switch to "ON" position. (Do not start engine.)
2. Select "DATA MONITOR" mode for "ENGINE" with CONSULT-II.
3. Start engine and wait for at least 6 seconds.
4. If DTC is detected, go to " «DIAGNOSTIC PROCEDURE»(ref-181179-S19869885722005080100000) ".

1. This is not an OBD-II self-diagnostic item.
2. Diagnostic trouble code "STARTER RELAY/CIRC" with CONSULT-II or 14th judgement flicker without CONSULT-II is detected when detects as irregular when switched "ON" other than at "P" or "N" position. (Or when switched "OFF" at "P" or "N" position).

Note. If "DTC Confirmation Procedure" has been previously conducted, always turn ignition switch "OFF" and wait at least 10 seconds before conducting the next test.

After the repair, perform the following procedure to confirm the malfunction is eliminated.

WITH CONSULT-II

Scheme 91

1. Turn ignition switch to "ON" position. (Do not start engine.)
2. Select "DATA MONITOR" mode for "A/T" with CONSULT-II.
3. Start engine.
4. Vehicle start for at least 2 consecutive seconds.
5. If DTC is detected, go to " «DIAGNOSTIC PROCEDURE»(ref-181179-S01884729282005080100000) ".

Scheme 92

TCM terminal and data are reference value. Measured between each terminal and ground.

Scheme 93

Scheme 94

Scheme 95

Scheme 96

1. CHECK PNP RELAY (WITH CONSULT-II) With CONSULT-II Turn ignition switch to "ON" position. (Do not start engine.) Select "SELECTION FROM MENU" in "DATA MONITOR" mode for "A/T" with CONSULT-II and check monitor "STARTER RELAY" (PNP relay) ON/OFF. OK or NG OK >> GO TO 4 . NG >> GO TO 3 .
2. CHECK PNP RELAY (WITHOUT CONSULT-II) Without CONSULT-II Turn ignition switch to "ON" position. (Do not start engine.) Check the voltage between the TCM connector and ground. OK or NG OK >> GO TO 2 . NG >> GO TO 3.
3. DETECT MALFUNCTIONING ITEM Check the following items: PNP relay. Refer to "STANDARDIZED RELAY". Disconnections or short-circuits in the harness between TCM and the PNP relay Ground circuit for the PNP relay OK or NG OK >> GO TO 4. NG >> Repair or replace damaged parts.
4. CHECK DTC Perform "DTC Confirmation Procedure". Refer to " «DTC CONFIRMATION PROCEDURE»(ref-181179-S30104037802005080100000) ". OK or NG OK >> INSPECTION END NG >> GO TO 5.
5. PERFORM TCM INSPECTION Perform TCM input/output signal inspection. If NG, recheck TCM pin terminals for damage or loose connection with harness connector. OK or NG OK >> INSPECTION END NG >> Repair or replace damaged parts.

1. This is an OBD-II self-diagnostic item.
2. Diagnostic trouble code "PNP SW/CIRC" with CONSULT-II or P0705 without CONSULT-II is detected under the following conditions. When TCM does not receive the correct voltage signal from the PNP switch 1, 2, 3, 4 based on the gear position. When monitor terminal of PNP switch 3 is disconnected. When no other position but "P" position is detected from "N" positions.

Note. If "DTC Confirmation Procedure" has been previously conducted, always turn ignition switch "OFF" and wait at least 10 seconds before conducting the next test.

After the repair, perform the following procedure to confirm the malfunction is eliminated.

Scheme 97

1. Turn ignition switch to "ON" position. (Do not start engine.)
2. Select "DATA MONITOR" mode for "ENGINE" with CONSULT-II.
3. Start engine.
4. Maintain the following conditions for at least 2 consecutive seconds. THRTL POS SEN: More than 1.2V
5. If DTC is detected, go to " «DIAGNOSTIC PROCEDURE»(ref-181179-S15155817962005080100000) "

1. This is an OBD-II self-diagnostic item.
2. Diagnostic trouble code "VEH SPD SEN/CIR AT" with CONSULT-II or P0720 without CONSULT-II is detected under the following conditions. When TCM does not receive the proper voltage signal from the sensor. After ignition switch is turned "ON", irregular signal input from vehicle speed sensor MTR before the vehicle starts moving.

Note. If "DTC Confirmation Procedure" has been previously conducted, always turn ignition switch "OFF" and wait at least 10 seconds before conducting the next test.

After the repair, perform the following procedure to confirm the malfunction is eliminated.

Scheme 98

1. Turn ignition switch to "ON" position. (Do not start engine.)
2. Select "DATA MONITOR" mode for "A/T" with CONSULT-II.
3. Check for an increase of "VHCL/S SE.A/T" value in response to "VHCL/S SE-MTR" value. If the check result is NG, go to " «Diagnostic Procedure»(ref-181179-S22759497032005080100000) ". If the check result is OK, go to following step.
4. Select "DATA MONITOR" mode for "ENGINE" with CONSULT-II.
5. Start engine and maintain the following conditions for at least 5 consecutive seconds. VHCL SPEED SE: 30 km/h (19 MPH) or more THRTL POS SEN: More than 1.0/8 Selector lever: "D" position If the check result is NG, go to " «Diagnostic Procedure»(ref-181179-S22759497032005080100000) ". If the check result is OK, go to following step.
6. Maintain the following conditions for at least 5 consecutive seconds. ENGINE SPEED: 3, 500 rpm or more THRTL POS SEN: More than 1.0/8 Selector lever: "D" position If the check result is NG, go to " «Diagnostic Procedure»(ref-181179-S22759497032005080100000) ".

1. This is not an OBD-II self-diagnostic item.
2. Diagnostic trouble code "ENGINE SPEED SIG" with CONSULT-II or 16th judgement flicker without CONSULT-II is detected when TCM does not receive the ignition signal from ECM during engine cranking or running.

Note. If "DTC Confirmation Procedure" has been previously conducted, always turn ignition switch "OFF" and wait at least 10 seconds before conducting the next test.

After the repair, perform the following procedure to confirm the malfunction is eliminated.

Scheme 99

1. Turn ignition switch to "ON" position and select "DATA MONITOR" mode for "A/T" with CONSULT-II.
2. Start engine and maintain the following conditions for at least 10 consecutive seconds. VHCL SPEED SE: 10 km/h (6 MPH) or more ACCELE POSI: More than 1/8 Selector lever: "D" position
3. If DTC is detected, go to " «DIAGNOSTIC PROCEDURE»(ref-181179-S03630484332005080100000) ".

Scheme 100

Scheme 101

1. CHECK DTC WITH ECM With CONSULT-II Turn ignition switch to "ON" position. (Do not start engine.) Select "SELF-DIAG RESULTS" mode for "ENGINE" with CONSULT-II. Refer to "CONSULT-II Function". OK or NG OK >> GO TO 2. NG >> Check the DTC detected item, go to "CONSULT-II Function". If CAN communication line is detected, go to " «DTC U1000: CAN COMMUNICATION LINE»(ref-181179-S23641977552005080100000) ".
2. CHECK DTC WITH TCM With CONSULT-II Start engine. Select "MAIN SIGNALS" in "DATA MONITOR" mode for "A/T" with CONSULT-II. While monitoring engine speed, check for engine speed change corresponding to wide-open throttle position signal. OK or NG OK >> GO TO 3. NG >> Check the ignition signal circuit. Refer to "IGNITION SIGNAL".
3. CHECK DTC Perform "DTC Confirmation Procedure". Refer to " «DTC CONFIRMATION PROCEDURE»(ref-181179-S15978445212005080100000) ". OK or NG OK >> INSPECTION END NG >> GO TO 4.
4. PERFORM TCM INSPECTION Perform TCM input/output signal inspection. If NG, recheck TCM pin terminals for damage or loose connection with harness connector. OK or NG OK >> INSPECTION END NG >> Repair or replace damaged parts.

1. This is an OBD-II self-diagnostic item.
2. Diagnostic trouble code "TCC SOLENOID/CIRC" with CONSULT-II or P0740 without CONSULT-II is detected under the following conditions. When TCM detects an improper voltage drop when it tries to operate the solenoid valve. When TCM detects as irregular by comparing target value with monitor value.

Note. If "DTC Confirmation Procedure" has been previously conducted, always turn ignition switch "OFF" and wait at least 10 seconds before conducting the next test.

After the repair, perform the following procedure to confirm the malfunction is eliminated.

Scheme 102

1. Turn ignition switch to "ON" position. (Do not start engine.)
2. Select "DATA MONITOR" mode for "ENGINE" with CONSULT-II.
3. Start engine and maintain the following conditions for at least 5 consecutive seconds. VHCL SPEED SE: 80 km/h (50 MPH) or more ACCELE POS: 0.5/8 - 1.0/8 SELECTOR LEVER: "D" position
4. If DTC is detected go to " «DIAGNOSTIC PROCEDURE»(ref-181179-S21446556092005080100000) ".

1. This is an OBD-II self-diagnostic item.
2. Diagnostic trouble code "A/T TCC S/V FNCTN" with CONSULT-II or P0744 without CONSULT-II is detected under the following conditions. When A/T cannot perform lock-up even if electrical circuit is good. When TCM detects as irregular by comparing difference value with slip rotation.

Note. If "DTC Confirmation Procedure" has been previously conducted, always turn ignition switch "OFF" and wait at least 10 seconds before conducting the next test.

After the repair, perform the following procedure to confirm the malfunction is eliminated.

Scheme 103

1. Start engine and select "TCC S/V FNCTN CHECK" of "DTC WORK SUPPORT" mode for A/T" with CONSULT-II and touch "START".
2. Accelerate vehicle to more than 80 km/h (50 MPH) and maintain the following condition continuously until "TESTING" has turned to "COMPLETE". (It will take approximately 30 seconds after "TESTING" shows.) ACCELE POSI: More than 1.0/8 (at all times during step 4) TCC SOLENOID: 0.4 - 0.6 A Selector lever: "D" position [Reference speed: Constant speed of more than 80 km/h (50 MPH)] Check that "GEAR" shows "5". For shift schedule, refer to " «VEHICLE SPEED WHEN PERFORMING AND RELEASING COMPLETE LOCK-UP»(ref-181179-S40241126132005080100000) ". If "TESTING" does not appear on CONSULT-II for a long time, select "SELF- DIAG RESULTS". In case a 1st trip DTC other than P0744 is shown, refer to applicable "TROUBLE DIAGNOSIS FOR DTC".
3. Make sure that "OK" is displayed. (If "NG" is displayed, refer to "DIAGNOSTIC PROCEDURE".) Refer to " «DIAGNOSTIC PROCEDURE»(ref-181179-S23065330312005080100000) ". Refer to shift schedule, " «VEHICLE SPEED WHEN PERFORMING AND RELEASING COMPLETE LOCK-UP»(ref-181179-S40241126132005080100000) ".

1. This is an OBD-II self-diagnostic item.
2. Diagnostic trouble code "L/PRESS SOL/CIRC" with CONSULT-II or P0745 without CONSULT-II is detected under the following conditions. When TCM detects an improper voltage drop when it tries to operate the solenoid valve. When TCM detects as irregular by comparing target value with monitor value.

Note. If "DTC Confirmation Procedure" has been previously conducted, always turn ignition switch "OFF" and wait at least 10 seconds before conducting the next test.

After the repair, perform the following procedure to confirm the malfunction is eliminated.

Scheme 104

1. Turn ignition switch to "ON" position and select "DATA MONITOR" mode for "ENGINE" with CONSULT-II.
2. Engine start and wait at least 5 second.
3. If DTC is detected, go to " " «DIAGNOSTIC PROCEDURE»(ref-181179-S23280735062005080100000) ".

1. This is not an OBD-II self-diagnostic item.
2. Diagnostic trouble code "TCM-POWER SUPPLY" with CONSULT-II is detected when TCM does not receive the voltage signal from the battery power supply.
3. This is not a malfunction message. (Whenever shutting "OFF" a power supply to the TCM, this message appears on the screen.)

Note. If "DTC Confirmation Procedure" has been previously conducted, always turn ignition switch "OFF" and wait at least 10 seconds before conducting the next test.

After the repair, perform the following procedure to confirm the malfunction is eliminated.

Scheme 105

1. Turn ignition switch to "ON" position. (Do not start engine.)
2. Select "DATA MONITOR" mode for "A/T" with CONSULT-II.
3. Wait for at least 2 consecutive seconds.
4. If DTC is detected, go to " «DIAGNOSTIC PROCEDURE»(ref-181179-S26141186112005080100000) ".

Scheme 106

Scheme 107

Scheme 108

TCM terminals and data are reference value. Measured between each terminal and ground.

Scheme 109

Scheme 110

Scheme 111

Scheme 112

Scheme 113

Scheme 114

1. CHECK TCM POWER SOURCE, STEP 1 Turn ignition switch to "OFF" position. Check voltage between TCM terminal and ground. OK or NG OK >> GO TO 2. NG >> GO TO 3 .
2. CHECK TCM POWER SOURCE, STEP 2 Turn ignition switch to "ON" position. Check voltage between TCM terminal and ground. OK or NG OK >> GO TO 4 . NG >> GO TO 3.
3. DETECT MALFUNCTIONING ITEM Check the following items: Harness for short or open between battery and TCM terminal 9 Harness for short or open between ignition switch and TCM terminals 2, 3, 33 and 42 10A fuse [No. 32 or 35, located in the fuse block (J/B)] Ignition switch. Refer to "POWER SUPPLY ROUTING ". A/T PV IGN relay. Refer to " «COMPONENT INSPECTION»(ref-181179-S29564043082005080100000) ". ECM relay. Refer to "POWER SUPPLY CIRCUIT FOR ECM ". OK or NG OK >> GO TO 4. NG >> Repair or replace damaged parts.
4. CHECK TCM GROUND CIRCUIT Turn ignition switch to "OFF" position. Disconnect TCM harness connector. Check continuity between TCM terminals 5 (B), 14 (B), 24 (B), 46 (B) and ground. Continuity should exist. If OK, check harness for short to ground and short to power. OK or NG OK >> GO TO 5. NG >> Repair open circuit or short to ground or short to power in harness or connectors.
5. CHECK DTC Check again. Refer to " «DTC CONFIRMATION PROCEDURE»(ref-181179-S13946086142005080100000) ". OK or NG OK >> INSPECTION END NG >> GO TO 6.
6. PERFORM TCM INSPECTION Perform TCM input/output signal inspection. If NG, recheck TCM pin terminals for damage or loose connection with harness connector. OK or NG OK >> INSPECTION END NG >> Repair or replace damaged parts.

Scheme 115

Scheme 116

1. Apply 12V direct current between A/T PV IGN relay terminals 1 and 2.
2. Check continuity between relay terminals 3 and 5.
3. If NG, replace A/T PV IGN relay.

1. This is not an OBD-II self-diagnostic item.
2. Diagnostic trouble code "TCM-RAM" with CONSULT-II is detected when TCM memory RAM is malfunctioning.

Note. If "DTC Confirmation Procedure" has been previously conducted, always turn ignition switch "OFF" and wait at least 10 seconds before conducting the next test.

After the repair, perform the following procedure to confirm the malfunction is eliminated.

Scheme 117

1. Turn ignition switch to "ON" position. (Do not start engine.)
2. Select "DATA MONITOR" mode for A/T with CONSULT-II.
3. Start engine.
4. Run engine for at least 2 consecutive seconds at idle speed.
5. If DTC is detected, go to " «DIAGNOSTIC PROCEDURE»(ref-181179-S08074419142005080100000) ".

Scheme 118

1. CHECK DTC With CONSULT-II Turn ignition switch to "ON" position. (Do not start engine.) Select "SELF DIAG RESULTS" mode for "A/T" with CONSULT-II. Touch "ERASE". Turn ignition switch to "OFF" position and wait at least 10 seconds. Perform DTC confirmation procedure, " «CONFIRMATION PROCEDURE»(ref-181179-S23745746762005080100000) ". Is the "TCM-RAM" displayed again? YES >> Replace TCM. NO >> INSPECTION END

1. This is not an OBD-II self-diagnostic item.
2. Diagnostic trouble code "TCM.ROM" with CONSULT-II is detected when TCM memory ROM is malfunctioning.

Note. If "DTC Confirmation Procedure" has been previously conducted, always turn ignition switch "OFF" and wait at least 10 seconds before conducting the next test.

After the repair, perform the following procedure to confirm the malfunction is eliminated.

WITH CONSULT-II

Scheme 119

1. Turn ignition switch to "ON" position. (Do not start engine.)
2. Select "DATA MONITOR" mode for A/T with CONSULT-II.
3. Start engine.
4. Run engine for at least 2 consecutive seconds at idle speed.
5. If DTC is detected, go to " «DIAGNOSTIC PROCEDURE»(ref-181179-S02434046712005080100000) ".

Scheme 120

1. CHECK DTC With CONSULT-II Turn ignition switch to "ON" position. (Do not start engine.) Select "SELF DIAG RESULTS" mode for "A/T" with CONSULT-II. Touch "ERASE". Turn ignition switch to "OFF" position and wait at least 10 seconds. Perform DTC confirmation procedure, " «DTC CONFIRMATION PROCEDURE»(ref-181179-S27397910102005080100000) ". Is the "TCM.ROM" displayed again? YES >> Replace TCM. NO >> INSPECTION END

1. This is not an OBD-II self-diagnostic item.
2. Diagnostic trouble code "TCM.EEPROM" with CONSULT-II is detected when TCM memory EEPROM is malfunctioning.

Note. If "DTC Confirmation Procedure" has been previously conducted, always turn ignition switch "OFF" and wait at least 10 seconds before conducting the next test.

After the repair, perform the following procedure to confirm the malfunction is eliminated.

Scheme 121

1. Turn ignition switch to "ON" position. (Do not start engine.)
2. Select "DATA MONITOR" mode for A/T with CONSULT-II.
3. Start engine.
4. Run engine for at least 2 consecutive seconds at idle speed.
5. If DTC is detected, go to " «DIAGNOSTIC PROCEDURE»(ref-181179-S35289519792005080100000) ".

Scheme 122

1. CHECK DTC With CONSULT-II Turn ignition switch to "ON" position and select "SELF DIAGNOSIS" mode for "A/T" with CONSULT-II. Move selector lever to "R" position. Depress accelerator pedal (Full throttle position). Touch "ERASE". Turn ignition switch to "OFF" position and wait at least 10 seconds. Perform "DTC Confirmation Procedure". Refer to " «DTC CONFIRMATION PROCEDURE»(ref-181179-S12445628022005080100000) ". Is the "TCM.EEPROM" displayed again? YES >> Replace TCM. NO >> INSPECTION END

1. This is not an OBD-II self-diagnostic item.
2. Diagnostic trouble code "TP SEN/CIRC A/T" with CONSULT-II or 15th judgement flicker without CONSULT-II is detected when TCM does not receive the proper accelerator pedal position signals (input by CAN communication) from ECM.

Note. If "DTC Confirmation Procedure" has been previously conducted, always turn ignition switch "OFF" and wait at least 10 seconds before conducting the next test.

After the repair, perform the following procedure to confirm the malfunction is eliminated.

Scheme 123

1. Turn ignition switch to "ON" position. (Do not start engine.)
2. Select "DATA MONITOR" mode for "A/T" with CONSULT-II.
3. Start engine and let it idle for 1 second.
4. If DTC is detected, go to " " «DIAGNOSTIC PROCEDURE»(ref-181179-S04834744782005080100000) ".

Scheme 124

Scheme 125

1. CHECK DTC WITH ECM With CONSULT-II Turn ignition switch to "ON" position. (Do not start engine.) Select "SELF-DIAG RESULTS" mode for "ENGINE" with CONSULT-II. Refer to "CONSULT-II Function ". OK or NG OK >> GO TO 2. NG >> Check the DTC detected item. Go to "CONSULT-II Function ". If CAN communication line is detected, go to " «DTC U1000: CAN COMMUNICATION LINE»(ref-181179-S23641977552005080100000) ".
2. CHECK DTC WITH TCM With CONSULT-II Turn ignition switch to "ON" position. (Do not start engine.) Select "ECU INPUT SIGNALS" in "DATA MONITOR" mode for "A/T" with CONSULT-II. Depress accelerator pedal and read out the value of "ACCLEPOS" and "THROTTLE POSI". Check engine speed changes according to throttle position. Select "SELF-DIAG RESULTS" mode for "A/T" with CONSULT-II. Refer to " «CONSULT-II»(ref-181179-S30931068782005080100000) ". OK or NG OK >> GO TO 3. NG >> Repair or replace damaged parts.
3. CHECK DTC Perform "DTC Confirmation Procedure". Refer to " «DTC CONFIRMATION PROCEDURE»(ref-181179-S36309423102005080100000) ". OK >> INSPECTION END NG >> GO TO 4.
4. PERFORM TCM INSPECTION Perform TCM input/output signal inspection. If NG, recheck TCM pin terminals for damage or loose connection with harness connector. OK or NG OK >> INSPECTION END NG >> Repair or replace damaged parts.

1. This is an OBD-II self-diagnostic item.
2. Diagnostic trouble code "ATF TEMP SEN/CIRC" with CONSULT-II or P1710 (A/T), P0710 (ENGINE) without CONSULT-II is detected when TCM receives an excessively low or high voltage from the sensor.

Note. If "DTC Confirmation Procedure" has been previously conducted, always turn ignition switch "OFF" and wait at least 10 seconds before conducting the next test.

After the repair, perform the following procedure to confirm the malfunction is eliminated.

Scheme 126

1. Turn ignition switch to "ON" position. (Do not start engine.)
2. Select "DATA MONITOR" mode for "ENGINE" with CONSULT-II.
3. Start engine and maintain the following conditions for at least 10 minutes (Total). (It is not necessary to maintain continuously.) VHCL SPEED SE: 10 km/h (6 MPH) or more THRTL POS SEN: More than 1.0/8 Selector lever: "D" position
4. If DTC is detected, go to " «DIAGNOSTIC PROCEDURE»(ref-181179-S38044783122005080100000) ".

1. This is an OBD-II self-diagnostic item.
2. Diagnostic trouble code "TURBINE REV S/CIRC" with CONSULT-II or P1716 without CONSULT-II is detected under the following conditions. When TCM does not receive the proper voltage signal from the sensor. When TCM detects an irregularity only at position of 4th gear for turbine revolution sensor 2.

Note. If "DTC Confirmation Procedure" has been previously conducted, always turn ignition switch "OFF" and wait at least 10 seconds before conducting the next test.

After the repair, perform the following procedure to confirm the malfunction is eliminated.

Scheme 127

1. Turn ignition switch to "ON" position. (Do not start engine.)
2. Select "DATA MONITOR" mode for "A/T" with CONSULT-II.
3. Start engine and maintain the following conditions for at least 5 consecutive seconds. VHCL SPEED SE: 40 km/h (25 MPH) or more ENGINE SPEED: 1, 500 rpm or more ACCELE POS: 0.5/8 or more Selector lever: "D" position Gear position (Turbine revolution sensor 1): 4th or 5th position Gear position (Turbine revolution sensor 2): All position
4. If DTC is detected, go to " «DIAGNOSTIC PROCEDURE»(ref-181179-S20645331152005080100000) ".

1. This is not an OBD-II self-diagnostic item.
2. Diagnostic trouble code "VHE SPD SE.MTR" with CONSULT-II is detected when TCM does not receive the proper vehicle speed sensor MTR signal (input by CAN communication) from combination meter.

Note. If "DTC Confirmation Procedure" has been previously conducted, always turn ignition switch "OFF" and wait at least 10 seconds before conducting the next test.

After the repair, perform the following procedure to confirm the malfunction is eliminated.

Scheme 128

1. Turn ignition switch to "ON" position. (Do not start engine.)
2. Select "DATA MONITOR" mode for "A/T" with CONSULT-II.
3. Start engine and maintain the following conditions for at least 5 consecutive seconds. ACCELE POS: 1/8 or less VHCL SPEED SE: 30 km/h (17 MPH) or more
4. If DTC is detected, go to " «DIAGNOSTIC PROCEDURE»(ref-181179-S16268466812005080100000) ".

Scheme 129

1. CHECK INPUT SIGNALS With CONSULT-II Start engine. Select "ECU INPUT SIGNALS" in "DATA MONITOR" mode for "A/T" with CONSULT-II. Drive vehicle and read out the value of "VHCL/S SE.MTR". OK or NG OK >> GO TO 3 . NG >> GO TO 2.
2. CHECK DTC, STEP 1 Check following items. Refer to " «DTC U1000: CAN COMMUNICATION LINE»(ref-181179-S23641977552005080100000) ". Refer to "CONSULT-II FUNCTIONS ". Refer to "COMBINATION METERS ". OK or NG OK >> INSPECTION END NG >> If NG, recheck pin terminals for damage or loose connection with harness connector.
3. CHECK DTC, STEP 2 Perform DTC confirmation procedure. " «DTC CONFIRMATION PROCEDURE»(ref-181179-S40784382872005080100000) ". OK or NG OK >> INSPECTION END NG >> If the system returns a malfunction, recheck pin terminals for damage or loose connection with harness connector.

1. This is an OBD-II self-diagnostic item.
2. Diagnostic trouble code "A/T INTERLOCK" with CONSULT-II or P1730 without CONSULT-II is detected when TCM does not receive the proper voltage signal from the sensor and switch.
3. TCM monitors and compares gear position and conditions of each pressure switch when gear is steady.

Note. If "DTC Confirmation Procedure" has been previously conducted, always turn ignition switch "OFF" and wait at least 10 seconds before conducting the next test.

After the repair, perform the following procedure to confirm the malfunction is eliminated.

Scheme 130

1. Turn ignition switch to "ON" position. (Do not start engine.)
2. Select "DATA MONITOR" mode for "A/T" with CONSULT-II.
3. Start engine.
4. Drive vehicle and maintain the following conditions for at least 2 consecutive seconds. Selector lever: "D" position
5. If DTC is detected, go to " «DIAGNOSTIC PROCEDURE»(ref-181179-S10987972492005080100000) ".

1. This is not an OBD-II self-diagnostic item.
2. Diagnostic trouble code "A/T 1ST E/BRAKING" with CONSULT-II or 13th judgement flicker without CONSULT-II is detected under the following condition. When TCM does not receive the proper voltage signal from the sensor. When TCM monitors each pressure switch and solenoid monitor value, and detects as irregular when engine brake of 1st gear acts other than at M1 position.

Note. If "DTC Confirmation Procedure" has been previously conducted, always turn ignition switch "OFF" and wait at least 10 seconds before conducting the next test.

After the repair, perform the following procedure to confirm the malfunction is eliminated.

Scheme 131

1. Turn ignition switch to "ON" position. (Do not start engine.)
2. Select "DATA MONITOR" mode for "A/T" with CONSULT-II.
3. Start engine.
4. Maintain the following conditions for at least 2 consecutive seconds. ENGINE SPEED: 1, 200 rpm Selector lever: "D" position Gear position: 1st gear
5. If DTC is detected, go to " «DIAGNOSTIC PROCEDURE»(ref-181179-S22252518852005080100000) ".

Scheme 132

TCM terminals and data are reference value. Measured between each terminal and ground.

Scheme 133

Scheme 134

Scheme 135

Scheme 136

Scheme 137

Scheme 138

1. CHECK INPUT SIGNALS With CONSULT-II Start engine. Select "ECU INPUT SIGNALS" or "MAIN SIGNALS" in "DATA MONITOR" mode for "A/T" with CONSULT-II. Accelerate vehicle in the "D" position (1st gear), and confirm the ON/OFF actuation of the "ATF PRES SW 2". OK or NG OK >> GO TO 4 . NG >> GO TO 2.
2. CHECK HARNESS BETWEEN TCM AND A/T UNIT ASSEMBLY HARNESS CONNECTOR Turn ignition switch to "OFF" position. Disconnect TCM connector. Check continuity between A/T unit assembly harness connector and TCM connector. If OK, check harness for short to ground and short to power. Reinstall any part removed. OK or NG OK >> GO TO 3. NG >> Repair open circuit or short to ground or short to power in harness or connectors.
3. CHECK TERMINAL CORD ASSEMBLY Remove oil pan. Refer to " «Control Valve Assembly»(ref-181179-S41631355262005080100000) ". Disconnect A/T unit assembly harness connector and control valve assembly harness connector. Check continuity between A/T unit assembly harness connector and control valve assembly harness connector. If OK, check harness for short to ground and short to power. Reinstall any part removed. OK or NG OK >> Replace the control valve assembly. Refer to " «Control Valve Assembly»(ref-181179-S41631355262005080100000) ". NG >> Repair open circuit or short to ground or short to power in harness or connectors.
4. CHECK DTC Perform "DTC Confirmation Procedure". Refer to " «DTC CONFIRMATION PROCEDURE»(ref-181179-S00292154802005080100000) ". OK or NG OK >> INSPECTION END NG >> GO TO 5.
5. PERFORM TCM INSPECTION Perform TCM input/output signal inspection. If NG, recheck TCM pin terminals for damage or loose connection with harness connector. OK or NG OK >> INSPECTION END NG >> Repair or replace damaged parts.

1. This is an OBD-II self-diagnostic item.
2. Diagnostic trouble code "I/C SOLENOID/CIRC" with CONSULT-II or P1752 without CONSULT-II is detected under the following conditions. When TCM detects an improper voltage drop when it tries to operate the solenoid valve. When TCM detects as irregular by comparing target value with monitor value.

Note. If "DTC Confirmation Procedure" has been previously conducted, always turn ignition switch "OFF" and wait at least 10 seconds before conducting the next test.

After the repair, perform the following procedure to confirm the malfunction is eliminated.

Scheme 139

1. Turn ignition switch to "ON" position. (Do not start engine.)
2. Select "DATA MONITOR" mode for "A/T" with CONSULT-II.
3. Start engine.
4. Maintain the following conditions for at least 5 consecutive seconds. ACCELE POS: 1.5/8 - 2.0/8 Selector lever: "D" position Gear position: 3rd => 4th Gear (I/C ON/OFF)
5. If DTC is detected go to " " «DIAGNOSTIC PROCEDURE»(ref-181179-S35921951332005080100000) ".

1. This is an OBD-II self-diagnostic item.
2. Diagnostic trouble code "I/C SOLENOID FNCTN" with CONSULT-II or P1754 without CONSULT-II is detected under the following conditions. When TCM detects that actual gear ratio is irregular, and relation between gear position and condition of ATF pressure switch 3 is irregular during depressing accelerator pedal. (Other than during shift change) When TCM detects that relation between gear position and condition of ATF pressure switch 3 is irregular during releasing accelerator pedal. (Other than during shift change)

Note. If "DTC Confirmation Procedure" has been previously conducted, always turn ignition switch "OFF" and wait at least 10 seconds before conducting the next test.

After the repair, perform the following procedure to confirm the malfunction is eliminated

Scheme 140

1. Start engine.
2. Accelerate vehicle to maintain the following condition. ACCELE POSI: 1.5/8 - 2.0/8 Selector lever: "D" position Gear position: 3rd => 4th Gear (I/C ON/OFF)
3. Perform step " 2 " again.
4. Turn ignition switch to "OFF" position, then perform step "1" to "3" again.
5. Check "SELF-DIAG RESULTS" mode for "A/T" with CONSULT-II. If DTC (P1754) is detected, Refer to " «DIAGNOSTIC PROCEDURE»(ref-181179-S37574805612005080100000) ". If DTC (P1752) is detected, go to " «DIAGNOSTIC PROCEDURE»(ref-181179-S35921951332005080100000) ". If DTC (P1843) is detected, go to " «DIAGNOSTIC PROCEDURE»(ref-181179-S08168365552005080100000) ".

1. This is an OBD-II self-diagnostic item.
2. Diagnostic trouble code "FR/B SOLENOID/CIRC" with CONSULT-II or P1757 without CONSULT-II is detected under the following conditions. When TCM detects an improper voltage drop when it tries to operate the solenoid valve. When TCM detects as irregular by comparing target value with monitor value.

Note. If "DTC Confirmation Procedure" has been previously conducted, always turn ignition switch "OFF" and wait at least 10 seconds before conducting the next test.

After the repair, perform the following procedure to confirm the malfunction is eliminated.

Scheme 141

1. Turn ignition switch to "ON" position. (Do not start engine.)
2. Select "DATA MONITOR" mode for "A/T" with CONSULT-II.
3. Start engine.
4. Maintain the following conditions for at least 5 consecutive seconds. ACCELE POS: 1.5/8 - 2.0/8 Selector lever: "D" position Gear position: 3rd => 4th Gear (FR/B ON/OFF)
5. If DTC is detected go to " «DIAGNOSTIC PROCEDURE»(ref-181179-S04370644802005080100000) ".

1. This is an OBD-II self-diagnostic item.
2. Diagnostic trouble code "FR/B SOLENOID FNCT" with CONSULT-II or P1759 without CONSULT-II is detected under the following conditions. When TCM detects that actual gear ratio is irregular, and relation between gear position and condition of ATF pressure switch 1 is irregular during depressing accelerator pedal. (Other than during shift change) When TCM detects that relation between gear position and condition of ATF pressure switch 1 is irregular during releasing accelerator pedal. (Other than during shift change)

Note. If "DTC Confirmation Procedure" has been previously conducted, always turn ignition switch "OFF" and wait at least 10 seconds before conducting the next test.

After the repair, perform the following procedure to confirm the malfunction is eliminated.

Scheme 142

1. Start engine.
2. Accelerate vehicle to maintain the following condition. ACCELE POS: 1.5/8 - 2.0/8 Selector lever: "D" position Gear position: 3rd => 4th Gear (FR/B ON/OFF)
3. Perform step " 2 " again.
4. Turn ignition switch to "OFF" position, then perform step "1" to "3" again.
5. Check "SELF-DIAG RESULTS" mode for "A/T" with CONSULT-II. If DTC (P1759) is detected, Refer to " «DIAGNOSTIC PROCEDURE»(ref-181179-S23970348092005080100000) ". If DTC (P1757) is detected, go to " «DIAGNOSTIC PROCEDURE»(ref-181179-S04370644802005080100000) ". If DTC (P1841) is detected, go to " «DIAGNOSTIC PROCEDURE»(ref-181179-S16178161742005080100000) ".

1. This is an OBD-II self-diagnostic item.
2. Diagnostic trouble code "D/C SOLENOID/CIRC" with CONSULT-II or P1762 without CONSULT-II is detected under the following conditions. When TCM detects an improper voltage drop when it tries to operate the solenoid valve. When TCM detects as irregular by comparing target value with monitor value.

Note. If "DTC Confirmation Procedure" has been previously conducted, always turn ignition switch "OFF" and wait at least 10 seconds before conducting the next test.

After the repair, perform the following procedure to confirm the malfunction is eliminated.

Scheme 143

1. Turn ignition switch to "ON" position. (Do not start engine.)
2. Select "DATA MONITOR" mode for "A/T" with CONSULT-II.
3. Start engine.
4. Maintain the following conditions for at least 5 consecutive seconds. ACCELE POS: 1.5/8-2.0/8 Selector lever: "D" position Gear position: 1st => 2nd Gear (D/C ON/OFF)
5. If DTC is detected, go to " «DIAGNOSTIC PROCEDURE»(ref-181179-S30453178052005080100000) ".

1. This is an OBD-II self-diagnostic item.
2. Diagnostic trouble code "D/C SOLENOID FNCTN" with CONSULT-II or P1764 without CONSULT-II is detected under the following conditions. When TCM detects that actual gear ratio is irregular, and relation between gear position and condition of ATF pressure switch 5 is irregular during depressing accelerator pedal. (Other than during shift change) When TCM detects that relation between gear position and condition of ATF pressure switch 5 is irregular during releasing accelerator pedal. (Other than during shift change)

Note. If "DTC Confirmation Procedure" has been previously conducted, always turn ignition switch "OFF" and wait at least 10 seconds before conducting the next test.

After the repair, perform the following procedure to confirm the malfunction is eliminated.

Scheme 144

1. Start engine.
2. Accelerate vehicle to maintain the following condition. ACCELE POS: 1.5/8 - 2.0/8 Selector lever: "D" position Gear position: 1st => 2nd Gear (D/C ON/OFF)
3. Perform step " 2 " again.
4. Turn ignition switch to "OFF" position, then perform step "1" to "3" again.
5. Check "SELF-DIAG RESULTS" mode for "A/T" with CONSULT-II. If DTC (P1764) is detected, Refer to " «DIAGNOSTIC PROCEDURE»(ref-181179-S19208393842005080100000) ". If DTC (P1762) is detected, go to " «DIAGNOSTIC PROCEDURE»(ref-181179-S30453178052005080100000) ". If DTC (P1845) is detected, go to " «DIAGNOSTIC PROCEDURE»(ref-181179-S28268091402005080100000) ".

1. This is an OBD-II self-diagnostic item.
2. Diagnostic trouble code "HLR/C SOL/CIRC" with CONSULT-II or P1767 without CONSULT-II is detected under the following conditions. When TCM detects an improper voltage drop when it tries to operate the solenoid valve. When TCM detects as irregular by comparing target value with monitor value.

Note. If "DTC Confirmation Procedure" has been previously conducted, always turn ignition switch "OFF" and wait at least 10 seconds before conducting the next test.

After the repair, perform the following procedure to confirm the malfunction is eliminated.

Scheme 145

1. Turn ignition switch to "ON" position. (Do not start engine.)
2. Select "DATA MONITOR" mode for "A/T" with CONSULT-II.
3. Start engine.
4. Maintain the following conditions for at least 5 consecutive seconds. ACCELE POS: 1.5/8 - 2.0/8 Selector lever: "D" position Gear position: 2nd => 3rd Gear (HLR/C ON/OFF)
5. If DTC is detected, go to " «DIAGNOSTIC PROCEDURE»(ref-181179-S13447833902005080100000) ".

1. This is an OBD-II self-diagnostic item.
2. Diagnostic trouble code "HLR/C SOL FNCTN" with CONSULT-II or P1769 without CONSULT-II is detected under the following conditions. When TCM detects that actual gear ratio is irregular, and relation between gear position and condition of ATF pressure switch 6 is irregular during depressing accelerator pedal. (Other than during shift change) When TCM detects that relation between gear position and condition of ATF pressure switch 6 is irregular during releasing accelerator pedal. (Other than during shift change)

Note. If "DTC Confirmation Procedure" has been previously conducted, always turn ignition switch "OFF" and wait at least 10 seconds before conducting the next test.

After the repair, perform the following procedure to confirm the malfunction is eliminated.

Scheme 146

1. Start engine.
2. Accelerate vehicle to maintain the following condition. ACCELE POS: 1.5/8 - 2.0/8 Selector lever: "D" position Gear position: 2nd => 3rd Gear (HLR/C ON/OFF)
3. Perform step " 2 " again.
4. Turn ignition switch to "OFF" position, then perform step "1" to "3" again.
5. Check "SELF-DIAG RESULTS" mode for "A/T" with CONSULT-II. If DTC (P1769) is detected, Refer to " «DIAGNOSTIC PROCEDURE»(ref-181179-S27830371562005080100000) ". If DTC (P1767) is detected, go to " «DIAGNOSTIC PROCEDURE»(ref-181179-S13447833902005080100000) ". If DTC (P1846) is detected, go to " «DIAGNOSTIC PROCEDURE»(ref-181179-S26646558722005080100000) ".

1. This is an OBD-II self-diagnostic item.
2. Diagnostic trouble code "LC/B SOLENOID/CIRC" with CONSULT-II or P1772 without CONSULT-II is detected when TCM detects an improper voltage drop when it tries to operate the solenoid valve.

Note. If "DTC Confirmation Procedure" has been previously conducted, always turn ignition switch "OFF" and wait at least 10 seconds before conducting the next test.

After the repair, perform the following procedure to confirm the malfunction is eliminated.

Scheme 147

1. Turn ignition switch to "ON" position. (Do not start engine.)
2. Select "DATA MONITOR" mode for "A/T" with CONSULT-II.
3. Start engine.
4. Maintain the following conditions for at least 5 consecutive seconds. Selector lever: "M" position Gear position: "M1-1st" or "M2-2nd" gear (LC/B ON/OFF)
5. If DTC is detected, go to " «DIAGNOSTIC PROCEDURE»(ref-181179-S05057244582005080100000) ".

1. This is an OBD-II self-diagnostic item.
2. Diagnostic trouble code "LC/B SOLENOID FNCT" with CONSULT-II or P1774 without CONSULT-II is detected under the following conditions. When TCM detects that actual gear ratio is irregular, and relation between gear position and condition of ATF pressure switch 2 is irregular during depressing accelerator pedal. (Other than during shift change) When TCM detects that relation between gear position and condition of ATF pressure switch 2 is irregular during releasing accelerator pedal. (Other than during shift change)

Note. If "DTC Confirmation Procedure" has been previously conducted, always turn ignition switch "OFF" and wait at least 10 seconds before conducting the next test.

After the repair, perform the following procedure to confirm the malfunction is eliminated.

Scheme 148

1. Start engine.
2. Accelerate vehicle to maintain the following condition. Selector lever: "M" position Gear position: "M1-1st" or "M2-2nd" gear (LC/B ON/OFF)
3. Perform step " 2 " again.
4. Turn ignition switch to "OFF" position, then perform step "1" to "3" again.
5. Check "SELF-DIAG RESULTS" mode for "A/T" with CONSULT-II. If DTC (P1774) is detected, Refer to " «DIAGNOSTIC PROCEDURE»(ref-181179-S02136517222005080100000) ". If DTC (P1772) is detected, go to " «DIAGNOSTIC PROCEDURE»(ref-181179-S05057244582005080100000) ".

1. This is not an OBD-II self-diagnostic item.
2. Diagnostic trouble code "MANU MODE SW/CIR" with CONSULT-II is detected when TCM monitors Manual mode, Non manual mode, Up or Down switch signal, and detects as irregular when impossible input pattern occurs 1 second or more.

Note. If "DTC Confirmation Procedure" has been previously conducted, always turn ignition switch "OFF" and wait at least 10 seconds before conducting the next test.

After the repair, perform the following procedure to confirm the malfunction is eliminated.

Scheme 149

1. Turn ignition switch to "ON" position. (Do not start engine.)
2. Select "DATA MONITOR" mode for "A/T" with CONSULT-II.
3. Start engine.
4. Move selector lever to "M" position for at least 2 consecutive seconds.
5. If DTC is detected, go to " «DIAGNOSTIC PROCEDURE»(ref-181179-S20573963092005080100000) ".

Scheme 150

Scheme 151

1. CHECK MANUAL MODE SWITCH CIRCUIT (WITH CONSULT-II) With CONSULT-II Turn ignition switch to "ON" position. (Do not start engine.) Select "ECU INPUT SIGNALS" in "DATA MONITOR" mode for "A/T" with CONSULT-II. Read out ON/OFF switching action of the "MANU MODE SW", "NON M-MODE SW", "UP SW LEVER", "DOWN SW LEVER". OK or NG OK >> GO TO 4 . NG >> GO TO 3.
2. CHECK MANUAL MODE SWITCH CIRCUIT (WITHOUT CONSULT-II) Without CONSULT-II Drive vehicle in the manual mode, and confirm that the actual gear position and the meter's indication of the position mutually coincide when the selector lever is shifted to the "+ (up)" or "- (down)" side (1st => 5th gear). OK or NG OK >> GO TO 4 . NG >> GO TO 3.
3. DETECT MALFUNCTIONING ITEM Check the following items. Power supply. Refer to "COMBINATION METERS ". Manual mode switch. Refer to " «COMPONENT INSPECTION»(ref-181179-S27117521462005080100000) ". Pin terminals for damage or loose connection with harness connector. Open circuit or short to ground or short to power in harness or connector for A/T device (manual mode switch). OK or NG OK >> GO TO 4. NG >> Repair or replace damaged parts.
4. CHECK DTC Perform DTC confirmation procedure. Refer to " «DTC CONFIRMATION PROCEDURE»(ref-181179-S26057912252005080100000) ". OK or NG OK >> INSPECTION END NG >> Replace the control device assembly.

1. This is not an OBD-II self-diagnostic item.
2. Diagnostic trouble code "ATF PRES SW 1/CIRC" with CONSULT-II is detected, when TCM detects that actual gear ratio is normal, and relation between gear position and condition of ATF pressure switch 1 is irregular during depressing accelerator pedal. (Other than during shift change)

Note. If "DTC Confirmation Procedure" has been previously conducted, always turn ignition switch "OFF" and wait at least 10 seconds before conducting the next test.

After the repair, perform the following procedure to confirm the malfunction is eliminated.

Scheme 152

1. Start engine.
2. Accelerate vehicle to maintain the following condition. ACCELE POS: 1.5/8 - 2.0/8 Selector lever: "D" position Gear position: 3rd => 4th Gear (FR/B ON/OFF)
3. Perform step " 2 " again.
4. Turn ignition switch to "OFF" position, then perform step "1" to "3" again.
5. Check "SELF-DIAG RESULTS" mode for "A/T" with CONSULT-II. If DTC (P1841) is detected, go to " «DIAGNOSTIC PROCEDURE»(ref-181179-S16178161742005080100000) ". If DTC (P1757) is detected, go to " «DIAGNOSTIC PROCEDURE»(ref-181179-S04370644802005080100000) ".

Scheme 153

TCM terminal and data are reference value. Measured between each terminal and ground.

Scheme 154

Scheme 155

Scheme 156

Scheme 157

Scheme 158

Scheme 159

Scheme 160

Scheme 161

1. CHECK INPUT SIGNALS (WITH CONSULT-II) With CONSULT-II Start engine. Select "ECU INPUT SIGNALS" or "MAIN SIGNALS" in "DATA MONITOR" mode for "A/T" with CONSULT-II. Accelerate vehicle in the "D" position (3rd => 4th gear), and confirm the ON/OFF actuation of the "ATF PRES SW 1". OK or NG OK >> GO TO 5 . NG >> GO TO 3 .
2. CHECK INPUT SIGNALS (WITHOUT CONSULT-II) Without CONSULT-II Start engine. Accelerate vehicle in the "D" position (3rd => 4th gear). OK or NG OK >> GO TO 5 . NG >> GO TO 3.
3. CHECK POWER SOURCE CIRCUIT Turn ignition switch to "OFF" position. Disconnect TCM connector. Check continuity between A/T unit assembly harness connector and TCM connector. If OK, check harness for short to ground and short to power. Reinstall any part removed. OK or NG OK >> GO TO 4. NG >> Repair open circuit or short to ground or short to power in harness or connectors.
4. CHECK TERMINAL CORD ASSEMBLY Remove oil pan. Refer to " «Control Valve Assembly»(ref-181179-S41631355262005080100000) ". Disconnect A/T unit assembly harness connector and control valve assembly harness connector. Check continuity between A/T unit assembly harness connector and control valve assembly harness connector. If OK, check harness for short to ground and short to power. OK or NG OK >> Replace control valve assembly. Refer to " «Control Valve Assembly»(ref-181179-S41631355262005080100000) ". NG >> Repair open circuit or short to ground or short to power in harness or connectors.
5. CHECK DTC Perform DTC confirmation procedure. Refer to " «DTC CONFIRMATION PROCEDURE»(ref-181179-S33212895722005080100000) ". OK or NG OK >> INSPECTION END NG >> GO TO 6.
6. PERFORM TCM INSPECTION Perform TCM input/output signal inspection. If NG, recheck TCM pin terminals for damage or loose connection with harness connector. OK or NG OK >> Replace control valve assembly. Refer to " «CONTROL VALVE ASSEMBLY»(ref-181179-S41631355262005080100000) ". NG >> Repair or replace damaged parts.

1. This is not an OBD-II self-diagnostic item.
2. Diagnostic trouble code "ATF PRES SW 3/CIRC" with CONSULT-II is detected, when TCM detects that actual gear ratio is normal, and relation between gear position and condition of ATF pressure switch 3 is irregular during depressing accelerator pedal. (Other than during shift change)

Note. If "DTC Confirmation Procedure" has been previously conducted, always turn ignition switch "OFF" and wait at least 10 seconds before conducting the next test.

After the repair, perform the following procedure to confirm the malfunction is eliminated.

Scheme 162

1. Start engine.
2. Accelerate vehicle to maintain the following condition. ACCELE POS: 1.5/8 - 2.0/8 Selector lever: "D" position Gear position: 3rd => 4th Gear (I/C ON/OFF)
3. Perform step " 2 " again.
4. Turn ignition switch to "OFF" position, then perform step "1" to "3" again.
5. Check "SELF-DIAG RESULTS" mode for "A/T" with CONSULT-II. If DTC (P1843) is detected, go to " «DIAGNOSTIC PROCEDURE»(ref-181179-S08168365552005080100000) ". If DTC (P1752) is detected, go to " «DIAGNOSTIC PROCEDURE»(ref-181179-S35921951332005080100000) ".

Scheme 163

TCM terminals and data are reference value.

Scheme 164

Scheme 165

Scheme 166

Scheme 167

Scheme 168

Scheme 169

1. CHECK INPUT SIGNALS With CONSULT-II Start engine. Select "ECU INPUT SIGNALS" or "MAIN SIGNALS" in "DATA MONITOR" mode for "A/T" with CONSULT-II. Accelerate vehicle in the "D" position (3rd => 4th gear), and confirm the ON/OFF actuation of the "ATF PRES SW 3". OK or NG OK >> GO TO 4 . NG >> GO TO 2.
2. CHECK HARNESS BETWEEN TCM AND A/T UNIT ASSEMBLY HARNESS CONNECTOR Turn ignition switch to "OFF" position. Disconnect TCM connector. Check continuity between A/T unit assembly harness connector and TCM connector. If OK, check harness for short to ground and short to power. Reinstall any part removed. OK or NG OK >> GO TO 3. NG >> Repair open circuit or short to ground or short to power in harness or connectors.
3. CHECK TERMINAL CORD ASSEMBLY Remove oil pan. Refer to " «Control Valve Assembly»(ref-181179-S41631355262005080100000) ". Disconnect A/T unit assembly harness connector and control valve assembly harness connector. Check continuity between A/T unit assembly harness connector and control valve assembly harness connector. If OK, check harness for short to ground and short to power. OK or NG OK >> Replace the control valve assembly. Refer to " «Control Valve Assembly»(ref-181179-S41631355262005080100000) ". NG >> Repair open circuit or short to ground or short to power in harness or connectors.
4. CHECK DTC Perform DTC confirmation procedure. Refer to " «DTC CONFIRMATION PROCEDURE»(ref-181179-S14963660392005080100000) ". OK or NG OK >> INSPECTION END NG >> GO TO 5.
5. PERFORM TCM INSPECTION Perform TCM input/output signal inspection. If NG, recheck TCM pin terminals for damage or loose connection with harness connector. OK or NG OK >> Replace the control valve assembly. Refer to " «Control Valve Assembly»(ref-181179-S41631355262005080100000) ". NG >> Repair or replace damaged parts.

1. This is not an OBD-II self-diagnostic item.
2. Diagnostic trouble code "ATF PRES SW 5/CIRC" with CONSULT-II is detected, when TCM detects that actual gear ratio is normal, and relation between gear position and condition of ATF pressure switch 5 is irregular during depressing accelerator pedal. (Other than during shift change)

Note. If "DTC Confirmation Procedure" has been previously conducted, always turn ignition switch "OFF" and wait at least 10 seconds before conducting the next test.

After the repair, perform the following procedure to confirm the malfunction is eliminated.

Scheme 170

1. Start engine.
2. Accelerate vehicle to maintain the following condition. ACCELE POS: 1.5/8 - 2.0/8 Selector lever: "D" position Gear position: 1st => 2nd Gear (D/C ON/OFF)
3. Perform step " 2 " again.
4. Turn ignition switch to "OFF" position, then perform step "1" to "3" again.
5. Check "SELF-DIAG RESULTS" mode for "A/T" with CONSULT-II. If DTC (P1845) is detected, go to " «DIAGNOSTIC PROCEDURE»(ref-181179-S28268091402005080100000) ". If DTC (P1762) is detected, go to " «DIAGNOSTIC PROCEDURE»(ref-181179-S30453178052005080100000) ".

Scheme 171

TCM terminals and data are reference value.

Scheme 172

Scheme 173

Scheme 174

Scheme 175

Scheme 176

Scheme 177

1. CHECK INPUT SIGNALS with CONSULT-II Start engine. Select "ECU INPUT SIGNALS" or "MAIN SIGNALS" in "DATA MONITOR" mode for "A/T" with CONSULT-II. Accelerate vehicle in the "D" position (1st => 2nd gear), and confirm the ON/OFF actuation of the "ATF PRES SW 5". OK or NG OK >> GO TO 4 . NG >> GO TO 2.
2. CHECK HARNESS BETWEEN TCM AND A/T UNIT ASSEMBLY HARNESS CONNECTOR Turn ignition switch to "OFF" position. Disconnect TCM connector. Check continuity between A/T unit assembly harness connector and TCM connector. If OK, check harness for short to ground and short to power. Reinstall any part removed. OK or NG OK >> GO TO 3. NG >> Repair open circuit or short to ground or short to power in harness or connectors.
3. CHECK TERMINAL CORD ASSEMBLY Remove oil pan. Refer to " «Control Valve Assembly»(ref-181179-S41631355262005080100000) ". Disconnect A/T unit assembly harness connector and control valve assembly harness connector. Check continuity between A/T unit assembly harness connector and control valve assembly harness connector. If OK, check harness for short to ground and short to power. OK or NG OK >> Replace the control valve assembly. Refer to " «Control Valve Assembly»(ref-181179-S41631355262005080100000) ". NG >> Repair open circuit or short to ground or short to power in harness or connectors.
4. CHECK DTC Perform DTC confirmation procedure. Refer to " «DTC CONFIRMATION PROCEDURE»(ref-181179-S18625052332005080100000) ". OK or NG OK >> INSPECTION END NG >> GO TO 5.
5. PERFORM TCM INSPECTION Perform TCM input/output signal inspection. If NG, recheck TCM pin terminals for damage or loose connection with harness connector. OK or NG OK >> Replace the control valve assembly. Refer to " «Control Valve Assembly»(ref-181179-S41631355262005080100000) ". NG >> Repair or replace damaged parts.

1. This is not an OBD-II self-diagnostic item.
2. Diagnostic trouble code "ATF PRES SW 6/CIRC" with CONSULT-II is detected, when TCM detects that actual gear ratio is normal, and relation between gear position and condition of ATF pressure switch 6 is irregular during depressing accelerator pedal. (Other than during shift change)

Note. If "DTC Confirmation Procedure" has been previously conducted, always turn ignition switch "OFF" and wait at least 10 seconds before conducting the next test.

After the repair, perform the following procedure to confirm the malfunction is eliminated.

Scheme 178

1. Start engine.
2. Accelerate vehicle to maintain the following condition. ACCELE POS: 1.5/8 - 2.0/8 Selector lever: "D" position Gear position: 2nd => 3rd Gear (HLR/C ON/OFF)
3. Perform step " 2 " again.
4. Turn ignition switch to "OFF" position, then perform step " 1 " to " 3 " again.
5. Check "SELF-DIAG RESULTS" mode for "A/T" with CONSULT-II. If DTC (P1846) is detected, go to " «DIAGNOSTIC PROCEDURE»(ref-181179-S26646558722005080100000) ". If DTC (P1767) is detected, go to " «DIAGNOSTIC PROCEDURE»(ref-181179-S13447833902005080100000) ".

Scheme 179

TCM terminal and data are reference value. Measured between each terminal and ground.

Scheme 180

Scheme 181

Scheme 182

Scheme 183

Scheme 184

Scheme 185

Scheme 186

Scheme 187

1. CHECK INPUT SIGNALS (WITH CONSULT-II) With CONSULT-II Start engine. Select "ECU INPUT SIGNALS" or "MAIN SIGNALS" in "DATA MONITOR" mode for "A/T" with CONSULT-II. Accelerate vehicle in the "D" position (2nd >> 3rd gear), and confirm the ON/OFF actuation of the "ATF PRES SW 6". OK or NG OK >> GO TO 5 . NG >> GO TO 3.
2. CHECK INPUT SIGNALS (WITHOUT CONSULT-II) Without CONSULT-II Start engine. Accelerate vehicle in the "D" position (2nd => 3rd gear). OK or NG OK >> GO TO 5 . NG >> GO TO 3.
3. CHECK POWER SOURCE CIRCUIT Turn ignition switch to "OFF" position. Disconnect TCM connector. Check continuity between A/T unit assembly harness connector and TCM connector. If OK, check harness for short to ground and short to power. Reinstall any part removed. OK or NG OK >> GO TO 4. NG >> Repair open circuit or short to ground or short to power in harness or connectors.
4. CHECK TERMINAL CORD ASSEMBLY Remove oil pan. Refer to " «Control Valve Assembly»(ref-181179-S41631355262005080100000) ". Disconnect A/T unit assembly harness connector and control valve assembly harness connector. Check continuity between A/T unit assembly harness connector and control valve assembly harness connector. If OK, check harness for short to ground and short to power. OK or NG OK >> Replace the control valve assembly. Refer to " «Control Valve Assembly»(ref-181179-S41631355262005080100000) ". NG >> Repair open circuit or short to ground or short to power in harness or connectors.
5. CHECK DTC Perform DTC confirmation procedure. Refer to " «DTC CONFIRMATION PROCEDURE»(ref-181179-S08739910192005080100000) ". OK or NG OK >> INSPECTION END NG >> GO TO 6.
6. PERFORM TCM INSPECTION Perform TCM input/output signal inspection. If NG, recheck TCM pin terminals for damage or loose connection with harness connector. OK or NG OK >> Replace the control valve assembly. Refer to " «Control Valve Assembly»(ref-181179-S41631355262005080100000) ". NG >> Repair or replace damaged parts.

Scheme 188

Scheme 189

Scheme 190

Scheme 191

Scheme 192

1. CHECK PNP SWITCH CIRCUIT With CONSULT-II Turn ignition switch to "ON" position. (Do not start engine.) Select "MAIN SIGNALS" in "DATA MONITOR" mode for "A/T" with CONSULT-II. Read out "N.P", "R" and "D" position switches moving selector lever to each position. OK or NG OK >> GO TO 3 . NG >> GO TO 2.
2. DETECT MALFUNCTIONING ITEM Check the following items. Disconnection or short-circuit in the harness between TCM and PNP switch 1, 2, 3, 4. Disconnection or short-circuit in the harness between the PNP switch 3 monitor and TCM. PNP switch. Refer to " «DTC P0705: PARK/NEUTRAL POSITION SWITCH»(ref-181179-S40613915482005080100000) ". OK or NG OK >> GO TO 3. NG >> Repair or replace damaged parts.
3. CHECK MANUAL MODE SWITCH CIRCUIT With CONSULT-II Turn ignition switch to "ON" position. (Do not start engine.) Select "ECU INPUT SIGNALS" in "DATA MONITOR" mode for "A/T" with CONSULT-II. Read out ON/OFF switching action of the "MANU MODE SW", "NON M-MODE SW", "UP SW LEVER", "DOWN SW LEVER". OK or NG OK >> GO TO 5 . NG >> GO TO 4.
4. DETECT MALFUNCTIONING ITEM Check the following items: Manual mode switch. Refer to " «DTC P1815: MANUAL MODE SWITCH»(ref-181179-S09340547462005080100000) ". Check the connector housing for missing, loosening, bending or falling down of any terminal. OK or NG OK >> GO TO 5. NG >> Repair or replace damaged parts.
5. CHECK BRAKE SWITCH CIRCUIT With CONSULT-II Turn ignition switch to "ON" position. (Do not start engine.) Select "ECU INPUT SIGNALS" in "DATA MONITOR" mode for "A/T" with CONSULT-II. Read out ON/OFF switching action of the "BRAKE SW". OK or NG OK >> GO TO 6. NG >> Check the following items: Stop lamp switch. Refer to "BRAKE PEDAL ". Combination meter. Refer to "COMBINATION METERS "
6. CHECK THROTTLE POSITION SIGNAL CIRCUIT With CONSULT-II Turn ignition switch to "ON" position. (Do not start engine.) Select "ECU INPUT SIGNALS" in "DATA MONITOR" mode for "A/T" with CONSULT-II. Depress accelerator pedal and read out the value of "CLSD THL POS" and "W/O THL POS". Perform the self-diagnosis for "ENGINE" with CONSULT-II. OK or NG OK >> GO TO 7. NG >> Repair or replace damaged parts.
7. CHECK DTC Perform SELF-DIAGNOSTIC PROCEDURE. Refer to " «CONSULT-II»(ref-181179-S30931068782005080100000) ". CAN Communication Line. Refer to «DTC U1000: CAN COMMUNICATION LINE»(ref-181179-S23641977552005080100000) . OK or NG OK >> INSPECTION END NG >> GO TO 8.
8. PERFORM TCM INSPECTION Perform TCM input/output signal inspection. If NG, recheck TCM pin terminals for damage or loose connection with harness connector. OK or NG OK >> INSPECTION END NG >> Repair or replace damaged parts.

1. CHECK SELF-DIAGNOSTIC RESULTS Execute self-diagnosis. Do the self-diagnostic results indicate torque converter clutch solenoid valve, engine speed signal, turbine revolution sensor, CAN communication? YES >> Check the malfunctioning system. Refer to " «DTC P0740: TORQUE CONVERTER CLUTCH SOLENOID VALVE»(ref-181179-S23522086152005080100000) ", " «DTC P0725: ENGINE SPEED SIGNAL»(ref-181179-S41086673882005080100000) ", " «DTC P1716: TURBINE REVOLUTION SENSOR»(ref-181179-S15711882632005080100000) ", " «DTC U1000: CAN COMMUNICATION LINE»(ref-181179-S23641977552005080100000) " NO >> GO TO 2.
2. CHECK SYMPTOM Check again. OK or NG OK >> INSPECTION END NG >> GO TO 3.
3. PERFORM TCM INSPECTION Perform TCM input/output signal inspection. If NG, recheck TCM pin terminals for damage or loose connection with harness connector. OK or NG OK >> INSPECTION END NG >> Repair or replace damaged parts.

1. MANUAL MODE SWITCH Check the manual mode switch. Refer to " «DTC P1815: MANUAL MODE SWITCH»(ref-181179-S09340547462005080100000) " OK or NG OK >> GO TO 2. NG >> Repair or replace damaged parts.
2. CHECK SELF-DIAGNOSTIC RESULTS Execute self-diagnosis. Do the self-diagnostic results indicate turbine revolution sensor? YES >> Check the malfunctioning system. Refer to " «DTC P1716: TURBINE REVOLUTION SENSOR»(ref-181179-S15711882632005080100000) ". NO >> INSPECTION END

SHIFT LOCK CONTROL UNIT INSPECTION TABLE

Note. Confirm that the pointer swings only momentarily because the output time is so short. If the inspection is done with an oscilloscope, it should be observed that the power source voltage lasts for 3.5 to 10 ms.

Scheme 193

INSPECTION

Installation and Inspection of Torque Converter

Scheme 194

1. After inserting a torque converter to a transmission, be sure to check dimension A to ensure it is within the reference value limit. Dimension A : 22.0 mm (0.87 in) or more

1. Check the following, and replace high and low reverse clutch assembly and mid sun gear assembly as a set if necessary.

1. Check the following, and replace direct clutch assembly if necessary.
