Automatic Transaxle: Specifications Infiniti M45 II

Automatic Trans 12 illustrations

Torque Converter Clutch Solenoid

  1. The solenoid is switched "OFF" to release the lock-up.

General Specifications

Applied modelVK45DE engine
Automatic transmission modelRE5R05A
Transmission model code number90X69, 91X14
Stall torque ratio2.0: 1
Transmission gear ratio1st3.540
2nd2.264
3rd1.472
4th1.000
5th0.834
Reverse2.370
Recommended fluidNissan Matic Fluid J
Fluid capacity10.3 liter (10--7/8 US qt, 9--1/8 lmp qt)
CAUTION: Use only Nissan Genuine ATF Matic Fluid J. Do not mix with other fluid. Using automatic transmission fluid other than Nissan Genuine ATF Matic Fluid J will deteriorate in driveability and automatic transmission durability, and may damage the automatic transmission, which is not covered by the warranty.
CAUTION
Use only Nissan Genuine ATF Matic Fluid J. Do not mix with other fluid. Using automatic transmission fluid other than Nissan Genuine ATF Matic Fluid J will deteriorate in driveability and automatic transmission durability, and may damage the automatic transmission, which is not covered by the warranty.

Service Data Specifications

CAUTIONUse only Nissan Genuine ATF Matic Fluid J. Do not mix with other fluid. Using automatic transmission fluid other than Nissan Genuine ATF Matic Fluid J will deteriorate in driveability and automatic transmission durability, and may damage the automatic transmission, which is not covered by the warranty.

Scheme 20

Scheme 20: Vehicle Speed When Shifting Gears
Scheme 20: Vehicle Speed When Shifting Gears
  1. At half throttle, the accelerator opening is 4/8 of the full opening.

Scheme 21

Scheme 21: Vehicle Speed When Performing and Releasing Complete Lock-up
Scheme 21: Vehicle Speed When Performing and Releasing Complete Lock-up
  1. At closed throttle, the accelerator opening is less than 1/8.
  2. At half throttle, the accelerator opening is 4/8 of the full opening.

Scheme 22

Scheme 22: Vehicle Speed When Performing and Releasing Slip Lock-up
Scheme 22: Vehicle Speed When Performing and Releasing Slip Lock-up
  1. At closed throttle, the accelerator opening is less than 1/8.

Scheme 23

Scheme 23: Stall Speed
Scheme 23: Stall Speed

Scheme 24

Scheme 24: Line Pressure
Scheme 24: Line Pressure

Scheme 25

Scheme 25: Solenoid Valves
Scheme 25: Solenoid Valves

Scheme 26

Scheme 26: A/T Fluid Temperature Sensor
Scheme 26: A/T Fluid Temperature Sensor

Scheme 27

Scheme 27: Turbine Revolution Sensor
Scheme 27: Turbine Revolution Sensor

Scheme 28

Scheme 28: Revolution Sensor
Scheme 28: Revolution Sensor

Scheme 29

Scheme 29: Reverse brake
Scheme 29: Reverse brake

Scheme 30

Scheme 30: Total End Play
Scheme 30: Total End Play

Scheme 31

Scheme 31: BEARING RACE FOR ADJUSTING TOTAL END PLAY
Scheme 31: BEARING RACE FOR ADJUSTING TOTAL END PLAY
