DTC P0120: THROTTLE POSITION (TP) SENSOR Infiniti I30 I

Testing & Diagnostics 2 illustrations ~217 words
  1. Check Power Supply - Turn ignition off. Disconnect TP sensor harness connector. (Scheme 12) Turn ignition on. Measure voltage between TP sensor connector terminal No. 1 (Red wire) and ground. If voltage is about 5 volts, go to next step. If voltage is not as specified, repair harness or connectors as necessary.
  2. Check Ground Circuit - Turn ignition off. Verify harness continuity between TP sensor connector terminal No. 3 (Black wire) and engine ground. If continuity is present, go to next step. If continuity is not present, repair harness or connectors as necessary.
  3. Check Input Signal Circuit - Disconnect ECM harness connector. Verify harness continuity between TP sensor connector terminal No. 2 (White wire) and ECM connector terminal No. 23. see scheme 4 If continuity is present, go to next step. If continuity is not present, repair harness or connectors as necessary.
  4. Check Component - Leave TP sensor disconnected. While opening and closing throttle, check resistance across TP sensor connector terminal No. 2 (White wire) and No. 3 (Black wire). (Scheme 13) See THROTTLE POSITION SENSOR RESISTANCE table. If resistance is not as specified, adjust TP sensor. See «ADJUSTMENTS»(ref-18015) article. If resistance is still not as specified after adjustment, replace TP sensor.
Throttle PositionOhms
Fully ClosedAbout 500
Partially Opened500-4000
Fully OpenAbout 4000
(1) Ensure resistance changes when opening and closing throttle.
(1)Ensure resistance changes when opening and closing throttle.

THROTTLE POSITION SENSOR RESISTANCE (1)

Scheme 12

Scheme 12

Scheme 13
