Engine Controls - Self-Diagnostics - Testing - I30: Diagnosis Infiniti I30 I

Testing & Diagnostics 1 illustration ~116 words

DIAGNOSTIC MODES

Self-diagnostic system can detect ECCS malfunctions and store related trouble codes. Intermittent codes are also stored. All codes are stored until cleared from memory. If an intermittent DTC does not reoccur 3 complete drive cycles, it will be cleared from memory.

Mode 3: Diagnostic Trouble Codes (DTCs)

This is self-diagnostic mode for retrieving DTCs stored in ECM memory.

DIAGNOSTIC TROUBLE CODE DEFINITIONS

Note. To identify ECM connector terminals, see WIRING DIAGRAMS article.

Scan Tester DTCScan Tester MIL DTCSystem AffectedProbable Cause
P00000505No MalfunctionNormal Condition
P01000102Mass Airflow Sensor CircuitOpen/Shorted Circuit
P0105 (1)—Absolute Pressure SensorOpen/Shorted Circuit
P01100401Intake Air Temp. SensorOpen/Shorted Circuit
P01150103Engine Coolant Temperature SensorOpen/Shorted Circuit
P01200403Throttle Position SensorOpen/Shorted Circuit
P01250908Engine Coolant Temperature SensorFaulty Sensor
P01300307/0503Right Front HO2SOpen/Shorted Circuit/High HO2S Signal
P01350901Right Front HO2SOpen/Shorted Circuit
P01360707Rear HO2SOpen/Shorted Circuit/High HO2S Signal
P01410902Rear HO2S HeaterOpen/Shorted Circuit
P01500303/0308Left Front HO2SOpen/Shorted Circuit
P01551001Left Front HO2SOpen/Shorted Circuit/Faulty Sensor
P01710115Right Side Fuel System FailureFuel System/MAF Sensor
P01720114Right Side Fuel System FailureFuel System/MAF Sensor
P01740210Left Side Fuel System FailureFuel System/MAF Sensor
P01750209Left Side Fuel System FailureFuel System/MAF Sensor
P01800402Fuel Tank Temp SensorOpen/Shorted Circuit
P03000701Random Cyl. MisfireIgnition System
P03010608No. 1 Cyl. MisfireIgnition System
P03020607No. 2 Cyl. MisfireIgnition System
P03030606No. 3 Cyl. MisfireIgnition System
P03040605No. 4 Cyl. MisfireIgnition System
P03050604No. 5 Cyl. MisfireIgnition System
P03060603No. 6 Cyl. MisfireIgnition System
P0325 (2)0304Knock SensorOpen/Shorted Circuit
P03350802Crankshaft Position SensorIncorrect Crank Signal
P03400101Camshaft Position SensorNo Crank Signal
P04000302EGR FunctionNo EGR Operation
P04020306EGR Control/Backpressure Transducer ValveN/A
P04200702Three-Way Catalyst MalfunctionRestricted Exhaust
P04430807EVAP Purge Control FailureOpen/Shorted Circuit/Faulty Vacuum Signal
P04460903Vent Control ValveN/A
P04500704EVAP System Pressure SensorN/A
P05000104Vehicle Speed Sensor (VSS)No VSS Signal
P05050205Idle Air Control (IAC) ValveIncorrect Idle Speed
P0600 (3)0504A/T Communication Signal(4) A/T Control Unit Signal Error
P06050301ECMSignals Not Normal
P07051003/1101Park/Neutral Position SwitchOpen/Shorted Circuit/Faulty Switch
P07101208Fluid Temperature Sensor(4) A/T Module Does Not Receive Correct Voltage Signal From Sensor
P07201102Vehicle Speed Sensor(4) A/T Module Does Not Receive Correct Voltage Signal From Sensor
P07251207Engine Speed Signal(4) A/T Module Does Not Receive Correct Voltage Signal From ECM
P07311103Incorrect Shift To 1st Gear(4) Check A/T Module
P07321104Incorrect Shift To 2nd Gear(4) Check A/T Module
P07331105Incorrect Shift To 3rd Gear(4) Check A/T Module
P07341106Incorrect Shift To 4th Gear(4) Check A/T Module
P07401204TCC Solenoid Valve(4) A/T Module Does Not Receive Correct Voltage Signal From Solenoid
P07441107A/T TCC SignalN/A
P07451205Line Pressure Solenoid Valve(4) A/T Module Does Not Receive Correct Voltage Signal From Solenoid
P07501108Shift Solenoid Valve A(4) A/T Module Does Not Receive Correct Voltage Signal From Solenoid
P07551201Shift Solenoid Valve B(4) A/T Module Does Not Receive Correct Voltage Signal From Solenoid
P11051302MAP/BARO Switch Solenoid ValveN/A
P12201305FPCMN/A
P13200201Ignition Signal CircuitOpen/Shorted Circuit
P13350407Crankshaft Position Sensor (Reference)N/A
P13360905Crankshaft Position Sensor (COG)Chipped Flywheel Tooth
P14001005EGRC SolenoidOpen/Shorted Circuit/Faulty Solenoid
P14010305EGR Temperature SensorOpen/Shorted Circuit
P14410801VC/V Bypass ValveN/A
P14451008Purge Volume Control ValveN/A
P14470111EVAP Purge Flow MonitorN/A
P16050804A/T Communication Signal(4) A/T Control Unit Signal Error
P17051206Throttle Position Sensor(4) A/T Module Does Not Receive Correct Voltage Signal From Sensor
P17601203Overrun Clutch Solenoid Valve B(4) A/T Module Does Not Receive Correct Voltage Signal From Solenoid
P19001308Cooling Fan CircuitCooling System Fault
(1) MIL DTC is not available. (2) Freeze frame data will not be stored in the ECM for the knock sensor. The MIL will not light for a knock sensor malfunction. (3) In case of the diagnostic item, the freeze frame data will not be stored in the ECM. This diagnosis does not have 2 trip detection logic, and will not light up the MIL. (4) See TRANSMISSION section for test procedures.
(1)MIL DTC is not available.
(2)Freeze frame data will not be stored in the ECM for the knock sensor. The MIL will not light for a knock sensor malfunction.
(3)In case of the diagnostic item, the freeze frame data will not be stored in the ECM. This diagnosis does not have 2 trip detection logic, and will not light up the MIL.
(4)See TRANSMISSION section for test procedures.

DIAGNOSTIC TROUBLE CODE (DTC) IDENTIFICATION

Scheme 1

Scheme 1
Scheme 1

DIAGNOSTIC TESTS

Note. In the following DTC testing, when instructed to perform "FINAL CHECK", see FINAL CHECK in SELF DIAGNOSTICS section.
