General Information (Fuel System) - 2.4L - Except Hev: Specifications Hyundai Sonata VI

Testing & Diagnostics 1 illustration ~351 words

SPECIFICATIONS

Fuel Delivery System

ItemsSpecification
Fuel TankCapacity70 lit. (18.5 U.S.gal., 74.0 U.S.qt., 61.6 lmp.qt.)
Fuel FilterTypePaper type
Fuel PressureLow Pressure Fuel Line445 ~ 455 kPa (4.5 ~ 4.6 kgf/cm 2 , 64.5 ~ 66.0 psi)
High Pressure Fuel Line5.0 ~ 12.0 MPa (51.0 ~ 122.4 kgf/cm 2 , 725.2 ~ 1740.5 psi)
Fuel PumpTypeElectrical, in-tank type
Driven byElectric motor
High Pressure Fuel PumpTypeMechanical type
Driven byCamshaft

FUEL DELIVERY SYSTEM SPECIFICATION CHART

Sensors

Manifold Absolute Pressure Sensor (MAPS) #1

  1. Type: Piezo-resistive pressure sensor type
  2. Specification
Pressure [kPa (kgf/cm 2 , psi)]Output Voltage (V)
20.0 (0.20, 2.9)0.79
46.7 (0.47, 6.77)1.84
101.3 (1.03, 14.7)4.0

MAPS SPECIFICATION CHART

Intake Air Temperature Sensor a (IATS)

  1. Type: Thermistor type
  2. Specification
TemperatureResistance (kohms)
°C°F
404040.93 ~ 48.35
20413.89 ~ 16.03
0325.38 ~ 6.09
10503.48 ~ 3.90
20682.31 ~ 2.57
401041.08 ~ 1.21
501221.56 ~ 1.74
601400.54 ~ 0.62
801760.29 ~ 0.34

IATS SPECIFICATION CHART

Manifold Absolute Pressure Sensor (MAPS) #2

  1. Type: Piezo-resistive pressure sensor type
  2. Specification
Pressure [kPa (kgf/cm 2 , psi)]Output Voltage (V)
20.0 (0.20, 2.9)0.79
46.7 (0.47, 6.77)1.84
101.3 (1.03, 14.7)4.0

MAPS SPECIFICATION CHART

Engine Coolant Temperature Sensor (ECTS)

  1. Type: Thermistor type
  2. Specification
TemperatureResistance (kohms)
°C°F
404048.14
20414.13 ~ 16.83
0325.79
20682.31 ~ 2.59
401041.15
601400.59
801760.32

ECTS SPECIFICATION CHART

Throttle Position Sensor (TPS) [integrated into ETC Module]

  1. Type: Variable resistor type
  2. Specification
Throttle Angle (°)Output Voltage (V)
TPS1TPS2
005.0
100.484.52
200.954.05
301.433.57
401.903.10
502.382.62
602.862.14
703.331.67
803.811.19
904.290.71
1004.760.24
1055.00
C.T (6~15°)0.29 ~ 0.714.29 ~ 4.71
W.O.T (93~102°)4.43 ~ 4.860.14 ~ 0.57

TPS SPECIFICATION CHART

ItemResistance (kohms)
TPS10.875 ~ 1.625 [20°C (68°F)]
TPS20.875 ~ 1.625 [20°C (68°F)]

TPS SPECIFICATION CHART

Crankshaft Position Sensor (CKPS)

  1. Type: Hall effect type

Camshaft Position Sensor (CMPS)

  1. Type: Hall effect type

Knock Sensor (KS)

  1. Type: Piezo-electricity type
  2. Specification
ItemSpecification
Capacitance (pF)850 ~ 1,150

KNOCK SENSOR SPECIFICATION CHART

Heated Oxygen Sensor (HO2S) [Bank 1/Sensor 1]

  1. Type: Zirconia (ZrO2) [Linear] Type
  2. Specification
ItemSpecification
Heater Resistance (ohms)2.5 ~ 4.0 [20°C (69.8°F)]

HEATED OXYGEN SENSOR SPECIFICATION CHART

Heated Oxygen Sensor (HO2S) [Bank 1/Sensor 2]

  1. Type: Zirconia (ZrO2) [Binary] Type
  2. Specification
A/F Ratio (lambda)Output Voltage (V)
RICHApprox. 0.9
LEANApprox. 0.04

HEATED OXYGEN SENSOR SPECIFICATION CHART

ItemSpecification
Heater Resistance (ohms)3.3 ~ 4.1 [21°C (69.8°F)]

HEATED OXYGEN SENSOR SPECIFICATION CHART

Rail Pressure Sensor (RPS)

Scheme 173

Scheme 173
  1. Type: Piezo-electricity type
  2. Specification

EWGA Position Sensor [integrated into Electric Waste Gate Actuator (EWGA)]

  1. Type: Hall effect, NON-Contact type
  2. Specification
PositionOutput Voltage [V]Operating Angle[°]Range of Rod [mm], reference
Mechanical Close end stop Position (MCP)4.800
Electrical Close end stop Position (ECP)4.2121.8
Electrical Open end stop Position (EOP)17916
Mechanical Open end stop Position (MOP)0.59018

EWGA POSITION SENSOR SPECIFICATION CHART

CVVT Oil Temperature Sensor (OTS)

  1. Type: Thermistor type
  2. Specification
Temperature [°C(°F)]Resistance (kohms)
40(-40)52.15
20(-4)16.52
0(32)6
20(68)2.45
40(104)1.11
60(140)0.54
80(176)0.29

CVVT OIL TEMPERATURE SENSOR SPECIFICATION CHART

Accelerator Position Sensor (APS)

  1. Type: Variable resistor type
  2. Specification
Accelerator PositionOutput Voltage (V)
APS1APS2
C.T0.7 ~ 0.80.29 ~ 0.46
W.O.T3.85 ~ 4.351.93 ~ 2.18

APS SPECIFICATION CHART

Fuel Tank Pressure Sensor (FTPS)

  1. Type: Piezo - Resistivity type
  2. Specification
Pressure [kPa (kgf/cm 2 , in H2O)Output Voltage (V)
6.67 (-0.068, -26.8)0.5
02.5
+6.67 (0.068, 26.8)4.5

FTPS SPECIFICATION CHART

Actuators

Injector

  1. Specification
ItemSpecification
Coil Resistance (ohms)1.18 ~ 1.31 [20°C (68°F)]

INJECTOR SPECIFICATION CHART

ETC Motor [integrated into ETC Module]

  1. Specification
ItemSpecification
Coil Resistance (ohms)1.2 ~ 1.8 [20°C (68°F)]

ETC MOTOR SPECIFICATION CHART

Purge Control Solenoid Valve (PCSV)

  1. Specification
ItemSpecification
Coil Resistance (ohms)19.0 ~ 22.0 [20°C (68°F)]

PURGE CONTROL SOLENOID VALVE SPECIFICATION CHART

CVVT Oil Control Valve (OCV)

  1. Specification
ItemSpecification
Coil Resistance (ohms)6.9 ~ 7.9 [20°C (68°F)]

CVVT OIL CONTROL VALVE SPECIFICATION CHART

Fuel Pressure Regulator Valve

  1. Specification
ItemSpecification
Coil Resistance (ohms)0.5 [20°C (68°F)]

FUEL PRESSURE REGULATOR VALVE SPECIFICATION CHART

EWGA DC Motor [integrated into Electric Waste Gate Actuator (EWGA)]

  1. Specification
ItemSpecification
Coil Resistance (ohms)1.48 ~ 1.96 [21°C(69.8°F)]

EWGA DC MOTOR SPECIFICATION CHART

Ignition Coil

  1. Type: Stick type
  2. Specification
ItemSpecification
Primary Coil Resistance (ohms)0.62 ± 10[][20°C (68°F)]
Secendary Coil Resistance (kohms)7.0 ± 15[][20°C (68°F)]

IGNITION COIL SPECIFICATION CHART

RCV Control Solenoid Valve

  1. Specification
ItemSpecification
Coil Resistance (ohms)28.3 ~ 31.1 [20°C(68°F)]

RCV CONTROL SOLENOID VALVE SPECIFICATION CHART

Canister Close Valve (CCV)

  1. Specification
ItemSpecification
Coil Resistance (ohms)19.9 ~ 22.9 [20°C (68°F)]

CANISTER CLOSE VALVE SPECIFICATION CHART

TIGHTENING TORQUES

Engine Control System

ItemKgf.mN.m
ECM installation bolt1.0 ~ 1.29.8 ~ 11.8
ECM bracket installation bolt/nut1.0 ~ 1.29.8 ~ 11.8
Manifold absolute pressure sensor installation bolt1.0 ~ 1.29.8 ~ 11.8
Crankshaft position sensor installation bolt1.0 ~ 1.29.8 ~ 11.8
Crankshaft position sensor cover installation bolt (M6)1.0 ~ 1.29.8 ~ 11.8
Crankshaft position sensor cover installation bolt (M8)1.9 ~ 2.418.6 ~ 23.5
Camshaft position sensor (Bank 1/Intake) installation bolt1.0 ~ 1.29.8 ~ 11.8
Camshaft position sensor (Bank 1/Exhaust) installation bolt1.0 ~ 1.29.8 ~ 11.8
Knock sensor installation bolt1.9 ~ 2.418.6 ~ 23.5
Heated oxygen sensor (Bank 1/sensor 1) installation4.0 ~ 5.039.2 ~ 49.1
Heated oxygen sensor (Bank 1/sensor 2) installation4.0 ~ 5.039.2 ~ 49.1
Rail pressure sensor installation1.8 ~ 2.218.0 ~ 22.0
Electronic throttle body installation bolt0.8 ~ 1.27.8 ~ 11.8
Purge control solenoid valve bracket installation bolt1.0 ~ 1.29.8 ~ 11.8
CVVT oil control valve (Bank 1/Intake) installation bolt1.0 ~ 1.29.8 ~ 11.8
CVVT oil control valve (Bank 1/Exhaust) installation bolt1.0 ~ 1.29.8 ~ 11.8
Ignition coil installation bolt1.0 ~ 1.29.8 ~ 11.8

ENGINE CONTROL SYSTEM REFERENCE CHART

Fuel Delivery System

ItemKgf.mN.m
Fuel tank installation nut4.0 ~ 5.539.2 ~ 54.0
Filler-neck assembly bracket installation bolt0.4 ~ 0.63.9 ~ 5.9
Accelerator pedal module installation nut1.0 ~ 1.59.8 ~ 14.7
Accelerator pedal module installation bolt0.9 ~ 1.48.8 ~ 13.7
Delivery pipe installation bolt1.9 ~ 2.418.6 ~ 23.5
High pressure fuel pump installation bolt1.3 ~ 1.512.8 ~ 14.7
High pressure fuel pipe installation nut2.7 ~ 3.326.5 ~ 32.4
High pressure fuel pipe function block installation bolt0.8 ~ 1.27.8 ~ 11.8

FUEL DELIVERY SYSTEM REFERENCE CHART
