ECM Problem Inspection Procedure

1. TEST ECM GROUND CIRCUIT: Measure resistance between ECM and chassis ground using the backside of ECM harness connector as ECM side check point. If the problem is found, repair it. Specification: Below 1ohms
2. TEST ECM CONNECTOR: Disconnect the ECM connector and visually check the ground terminals on ECM side and harness side for bent pins or poor contact pressure. If the problem is found, repair it.
3. If problem is not found in Step 1 and 2 , the ECM could be faulty. If so, make sure there were no DTC's before swapping the ECM with a new one, and then check the vehicle again. If DTC's were found, examine this first before swapping ECM.
4. RE-TEST THE ORIGINAL ECM: Install the original ECM (may be broken) into a known-good vehicle and check the vehicle. If the problem occurs again, replace the original ECM with a new one. If problem does not occur, this is intermittent problem (Refer to "Intermittent Problem Inspection Procedure" in «BASIC INSPECTION PROCEDURE»(ref-424829-S06621203132011100100000) ).

Inspection

Throttle Position Sensor (TPS)

1. Connect the GDS on the Data Link Connector (DLC).
2. Start the engine and measure the output voltage of TPS 1 and 2 at C.T. and W.O.T. Specification: Refer to " «SPECIFICATION»(ref-424830-S01469509252011100100000) "
3. Turn the ignition switch OFF and disconnect the scantool from the DLC.
4. Disconnect the ETC module connector and measure the resistance between the ETC module terminals 1 and 2. Specification: Refer to «SPECIFICATION»(ref-424830-S01469509252011100100000)

ETC Motor

1. Turn the ignition switch OFF.
2. Disconnect the ETC module connector.
3. Measure resistance between the ETC module terminals 3 and 6.
4. Check that the resistance is within the specification. Specification: Refer to " «SPECIFICATION»(ref-424830-S01469509252011100100000) "

Scheme 414

1. Turn the ignition switch OFF and disconnect the battery negative (-) cable.
2. Remove the resonator and the air intake hose (Refer to " «INTAKE AND EXHAUST SYSTEM»(ref-424823) " ).
3. Disconnect the ETC module connector.
4. Disconnect the coolant hoses (B).
5. Remove the installation bolts (A), and then remove the ETC module from the engine.

1. Connect the GDS on the Data Link Connector (DLC).
2. Measure the output voltage of the MAPS at idle and IG ON. Specification: Refer to " «SPECIFICATION»(ref-424830-S12049944572011100100000) "

Scheme 415

Scheme 416

1. Turn the ignition switch OFF and disconnect the battery negative (-) cable.
2. Disconnect the manifold absolute pressure sensor connector (A).
3. Remove the installation bolts (B), and then remove the sensor from the surge tank. [MAPS #1] [MAPS #2]

1. Turn the ignition switch OFF.
2. Disconnect the IATS connector.
3. Measure resistance between the IATS terminals 3 and 4.
4. Check that the resistance is within the specification. Specification: Refer to " «SPECIFICATION»(ref-424830-S04069962222011100100000) "

1. Turn the ignition switch OFF.
2. Remove the ECTS (Refer to " «REMOVAL»(ref-424830-S18589933842011100100000) ").
3. After immersing the thermistor of the sensor into engine coolant, measure resistance between the ECTS terminals 3 and 4.
4. Check that the resistance is within the specification. Specification: Refer to " «SPECIFICATION»(ref-424830-S16129774682011100100000) "

Scheme 417

Scheme 418

1. Turn the ignition switch OFF and disconnect the battery negative (-) cable.
2. Disconnect the engine coolant temperature sensor connector (A).
3. Remove the spring clip (A), and then pull the sensor from the water temperature control assembly. CAUTION: Note that engine coolant may be flowed out from the water temperature control assembly when removing the sensor.
4. Supplement the engine coolant (Refer to " «COOLING SYSTEM»(ref-424821) " ).

1. Check the signal waveform of the CMPS and CKPS using the GDS. Specification: Refer to " «WAVE FORM»(ref-424830-S10649458392011100100000) "

Scheme 419

Scheme 420

Scheme 421

1. Turn the ignition switch OFF and disconnect the battery negative (-) cable.
2. Disconnect the crankshaft position sensor connector (A).
3. Remove the protector (A).
4. Remove the installation bolt (A), and then remove the crankshaft position sensor.

1. Check the signal waveform of the CMPS and CKPS using the GDS. Specification: Refer to " «WAVE FORM»(ref-424830-S16655081442011100100000) "

1. Turn the ignition switch OFF.
2. Disconnect the HO2S connector.
3. Measure resistance between the HO2S terminals 4 and 5 [B1/S1].
4. Measure resistance between the HO2S terminals 3 and 4 [B1/S2].
5. Check that the resistance is within the specification. Specification: Refer to " «SPECIFICATION»(ref-424830-S32251950362011100100000) "

Scheme 422

Scheme 423

Scheme 424

Scheme 425

1. Turn the ignition switch OFF and disconnect the battery negative (-) cable.
2. Disconnect the connector (A), and then remove the sensor (B). NOTE: Note that the SST (Part No.: 09392-2H100) is useful when removing the heated oxygen sensor. [Bank 1/Sensor 1] [Bank 1/Sensor 2]

1. Connect the GDS on the Data Link Connector (DLC).
2. Measure the output voltage of the RPS at idle and various engine speed. VOLTAGE SPECIFICATION CHART Condition Output Voltage (V) Idle Approx. 1.2 1,500 rpm 2.0 ~ 2.2 6,300 rpm Approx. 2.8

Scheme 426

1. Turn the ignition switch OFF and disconnect the battery negative (-) cable.
2. Release the residual pressure in fuel line (Refer to " «RELEASE RESIDUAL PRESSURE IN FUEL LINE»(ref-424831-S30652370042011100100000) " ). CAUTION: When removing the fuel pump relay, a Diagnostic Trouble Code (DTC) may occur. Delete the code with the GDS after completion of "Release Residual Pressure in Fuel Line" work.
3. Remove the intake manifold (Refer to " «INTAKE AND EXHAUST SYSTEM»(ref-424823) " ).
4. Disconnect the rail pressure sensor connector (A), and then remove the sensor (B) from the delivery pipe.

1. Turn the ignition switch OFF.
2. Disconnect the OTS connector.
3. Remove the OTS.
4. After immersing the thermistor of the sensor into engine coolant, measure resistance between the OTS terminals 1 and 2.
5. Check that the resistance is within the specification. Specification: Refer to " «SPECIFICATION»(ref-424830-S41805439402011100100000) "

Scheme 427

1. Turn the ignition switch OFF.
2. Disconnect the OTS connector (A).
3. Remove the OTS.

1. Connect the GDS on the Data Link Connector (DLC).
2. Turn the ignition switch ON.
3. Measure the output voltage of the APS 1 and 2 at C.T and W.O.T. Specification: Refer to " «SPECIFICATION»(ref-424830-S18224787512011100100000) "

1. Connect the GDS on the Data Link Connector (DLC).
2. Measure the output voltage of the FTPS. Specification: Refer to " «SPECIFICATION»(ref-424830-S14020647022011100100000) "

Scheme 428

Scheme 429

1. Turn the ignition switch OFF and disconnect the battery negative (-) cable.
2. Remove the fuel pump service cover (A) in the trunk.
3. Disconnect the fuel tank pressure sensor connector (A), and then remove the fuel tank pressure sensor.

1. Turn the ignition switch OFF.
2. Disconnect the injector connector.
3. Measure resistance between the injector terminals 1 and 2.
4. Check that the resistance is within the specification. Specification: Refer to " «SPECIFICATION»(ref-424830-S09480797462011100100000) "

1. Turn the ignition switch OFF.
2. Disconnect the PCSV connector.
3. Measure resistance between the PCSV terminals 1 and 2.
4. Check that the resistance is within the specification. Specification: Refer to " «SPECIFICATION»(ref-424830-S24181889912011100100000) "

Scheme 430

Scheme 431

1. Turn the ignition switch OFF and disconnect the battery negative (-) cable.
2. Disconnect the purge control solenoid valve connector (A).
3. Disconnect the vapor hoses (B) from the purge control solenoid valve.
4. Remove the valve from the bracket in the direction of the arrow.

1. Turn the ignition switch OFF.
2. Disconnect the OCV connector.
3. Measure resistance between the OCV terminals 1 and 2.
4. Check that the resistance is within the specification. Specification: Refer to " «SPECIFICATION»(ref-424830-S23150124882011100100000) "

1. Turn the ignition switch OFF and disconnect the battery negative (-) cable.
2. Disconnect the fuel pressure regulator valve connector.
3. Measure resistance between the fuel pressure regulator valve terminals 1 and 2.
4. Check that the resistance is within the specification. Specification: Refer to " «SPECIFICATION»(ref-424830-S31802172722011100100000) "

[Motor]

1. Turn ignition switch OFF.
2. Disconnect the EWGA connector.
3. Check that the EWGA is stuck by foreign material.
4. Measure resistance between motor (+) and (-) control terminals of the motor.
5. Check that the resistance is within the specification. Specification: Refer to " «SPECIFICATION»(ref-424830-S26154575412011100100000) " section.

[Position Sensor]

1. Turn ignition switch ON.
2. Connect the GDS to the data link connector (DLC).
3. Check the output voltage at each position of the EWGA position sensor on current data item within the specification. Specification: Refer to " «SPECIFICATION»(ref-424830-S26154575412011100100000) " section.

Scheme 432

Scheme 433

Scheme 434

1. Turn the ignition switch OFF and disconnect the battery negative (-) cable.
2. Disconnect the EWGA connector (A).
3. Remove the shaft link assembly (B) after removing the C-ring (A).
4. Remove the EWGA after removing the bolts (A). CAUTION: When carrying the turbo charger, do not hold the rod of the turbo charge to prevent bending the rod.

1. Turn the ignition switch OFF.
2. Disconnect the RCV control solenoid valve connector.
3. Measure resistance between the valve terminals 1 and 2.
4. Check that the resistance is within the specification. Specification: Refer to " «SPECIFICATION»(ref-424830-S16519527872011100100000) "

Scheme 435

1. Turn the ignition switch OFF and disconnect the battery negative (-) cable.
2. Remove the RCV control solenoid valve (A) after disconnect the connector, bolt and hose.

1. Turn the ignition switch OFF.
2. Disconnect the CCV connector.
3. Measure resistance between the CCV terminal 1 and 2.
4. Check that the resistance is within the specification. Specification: Refer to " «SPECIFICATION»(ref-424830-S29669955762011100100000) "
5. Disconnect the vapor hose connected with the canister from the CCV.
6. Connect a vacuum pump to the nipple.
7. Ground the CCV control line and apply battery voltage to the CCV power supply line.
8. Apply vacuum and check the valve operation. Specification: Vacuum maintained

Scheme 436

Scheme 437

1. Turn the ignition switch OFF and disconnect the battery negative (-) cable.
2. Disconnect the canister close valve connector (A).
3. Disconnect the ventilation tube quick connector (B).
4. Release the lever (C), and then remove the fuel tank air filter (D) after rotating it in the direction of the arrow in the figure.
5. Release the lever (E), and then remove the canister close valve (F) after rotating it in the direction of the arrow in the figure.
