Engine Control System - 2.4L - Except Hev: Specifications Hyundai Sonata VI

Testing & Diagnostics 19 illustrations ~136 words

Specification

Pressure [kPa (kgf/cm 2 , psi)]Output Voltage (V)
20.0 (0.20, 2.9)0.79
46.7 (0.47, 6.77)1.84
101.3 (1.03, 14.7)4.0

MAPS SPECIFICATIONS CHART

Scheme 194

Scheme 194
Scheme 194

Scheme 195

Scheme 195: Circuit Diagram
Scheme 195: Circuit Diagram
TemperatureResistance (kohms)
°C°F
404040.93 ~ 48.35
20413.89 ~ 16.03
0325.38 ~ 6.09
10503.48 ~ 3.90
20682.31 ~ 2.57
401041.08 ~ 1.21
501221.56 ~ 1.74
601400.54 ~ 0.62
801760.29 ~ 0.34

IATS SPECIFICATIONS CHART

Scheme 196

Scheme 196: Circuit Diagram
Scheme 196: Circuit Diagram
TemperatureResistance (kohms)
°C°F
404048.14
20414.13 ~ 16.83
0325.79
20682.31 ~ 2.59
401041.15
601400.59
801760.32

ECTS SPECIFICATIONS CHART

Scheme 197

Scheme 197: Circuit Diagram
Scheme 197: Circuit Diagram
ItemSpecification
Capacitance (pF)850 ~ 1,150

KNOCK SENSOR SPECIFICATIONS CHART

Scheme 198

Scheme 198: Circuit Diagram
Scheme 198: Circuit Diagram

Scheme 199

Scheme 199: Removal
Scheme 199: Removal
  1. Turn the ignition switch OFF and disconnect the battery negative (-) cable.
  2. Remove the intake manifold (Refer to " «INTAKE AND EXHAUST SYSTEM»(/hyundai/sonata/vi-2009-2014/remont/exhaust/#engine-intake-system-and-exhaust-system-24l-except-hev) " ).
  3. Disconnect the injector connector (A).
  4. Remove the installation bolt (B), and then remove the sensor from the cylinder block.
Accelerator PositionOutput Voltage (V)
APS1APS2
C.T0.7 ~ 0.80.29 ~ 0.46
W.O.T3.85 ~ 4.351.93 ~ 2.18

APS SPECIFICATIONS CHART

Scheme 200

Scheme 200
Scheme 200

Scheme 201

Scheme 201: Circuit Diagram
Scheme 201: Circuit Diagram
Pressure [kPa (kgf/cm 2 , in H2O)Output Voltage (V)
6.67 (-0.068, -26.8)0.5
02.5
+6.67 (0.068, 26.8)4.5

FTPS SPECIFICATIONS CHART

Scheme 202

Scheme 202
Scheme 202

Scheme 203

Scheme 203: Circuit Diagram
Scheme 203: Circuit Diagram
ItemSpecification
Coil Resistance (ohms)1.18 ~ 1.31 [20°C (68°F)]

INJECTOR SPECIFICATIONS CHART

Scheme 204

Scheme 204: Signal Waveform
Scheme 204: Signal Waveform

Scheme 205

Scheme 205
Scheme 205

Scheme 206

Scheme 206: Circuit Diagram
Scheme 206: Circuit Diagram
ItemSpecification
Coil Resistance (ohms)19.0 ~ 22.0 [20°C (68°F)]

PCSV SPECIFICATIONS CHART

Scheme 207

Scheme 207: Circuit Diagram
Scheme 207: Circuit Diagram
ItemSpecification
Coil Resistance (ohms)6.9 ~ 7.9 [20°C (68°F)]

CVVT SPECIFICATIONS CHART

Scheme 208

Scheme 208: Circuit Diagram
Scheme 208: Circuit Diagram
ItemSpecification
Coil resistance (ohms)30.0 ~ 35.0 [20°C (68°F)]

VIS SPECIFICATIONS CHART

Scheme 209

Scheme 209: Circuit Diagram
Scheme 209: Circuit Diagram
ItemSpecification
Coil Resistance (ohms)0.5 [20°C (68°F)

FPRV SPECIFICATIONS CHART

Scheme 210

Scheme 210: Signal Waveform
Scheme 210: Signal Waveform

Scheme 211

Scheme 211: SCHEMATIC DIAGRAMS
Scheme 211: SCHEMATIC DIAGRAMS
ItemSpecification
Coil Resistance (ohms)19.9 ~ 22.9 [20°C (68°F)

CCV SPECIFICATIONS CHART

Scheme 212

Scheme 212: Circuit Diagram
Scheme 212: Circuit Diagram
