Engine Control System - 2.0L - Except Hev: Specifications Hyundai Sonata VI

Testing & Diagnostics 26 illustrations ~184 words

Specification

[Throttle Position Sensor (TPS)]

Throttle Angle (°)Output Voltage (V)
TPS1TPS2
00.05.0
100.484.52
200.954.05
301.433.57
401.903.10
502.382.62
602.862.14
703.331.67
803.811.19
904.290.71
1004.760.24
1055.00
C.T (6 ~ 15°)0.29 ~ 0.714.29 ~ 4.71
W.O.T (93 ~ 102°)4.43 ~ 4.860.14 ~ 0.57

VOLTAGE SPECIFICATION CHART

Scheme 350

Scheme 350
Scheme 350
ItemSensor Resistance (kohms)
TPS10.875 ~ 1.625 [20°C (68°F)]
TPS20.875 ~ 1.625 [20°C (68°F)]

ITEM RESISTANCE REFERENCE CHART

[ECT Motor]

ItemSpecification
Coil Resistance (ohms)1.2 ~ 1.8 [20°C (68°F)]

ITEM SPECIFICATION CHART

Scheme 351

Scheme 351: Circuit Diagram
Scheme 351: Circuit Diagram
Pressure [kPa (kgf/cm 2 , psi)]Output Voltage (V)
20.0 (0.20, 2.9)0.79
46.7 (0.47, 6.77)1.84
101.3 (1.03, 14.7)4.0

VOLTAGE SPECIFICATION CHART

Scheme 352

Scheme 352
Scheme 352

Scheme 353

Scheme 353: Circuit Diagram
Scheme 353: Circuit Diagram
TemperatureResistance (kohms)
°C°F
404040.93 ~ 48.35
20413.89 ~ 16.03
0325.38 ~ 6.09
10503.48 ~ 3.90
20682.31 ~ 2.57
401041.08 ~ 1.21
501221.56 ~ 1.74
601400.54 ~ 0.62
801760.29 ~ 0.34

TEMPERATURE RESISTANCE REFERENCE CHART

Scheme 354

Scheme 354: Circuit Diagram
Scheme 354: Circuit Diagram
TemperatureResistance (kohms)
°C°F
404048.14
20414.13 ~ 16.83
0325.79
20682.31 ~ 2.59
401041.15
601400.59
801760.32

TEMPERATURE RESISTANCE REFERENCE CHART

Scheme 355

Scheme 355: Circuit Diagram
Scheme 355: Circuit Diagram
ItemSpecification
Capacitance (pF)850 ~ 1,150

ITEM SPECIFICATION CHART

Scheme 356

Scheme 356: Circuit Diagram
Scheme 356: Circuit Diagram

Scheme 357

Scheme 357: Removal
Scheme 357: Removal
  1. Turn the ignition switch OFF and disconnect the battery negative (-) cable.
  2. Remove the intake manifold (Refer to " «INTAKE AND EXHAUST SYSTEM»(/hyundai/sonata/vi-2009-2014/remont/exhaust/#engine-intake-system-and-exhaust-system-20l-except-hev) " ).
  3. Disconnect the knock sensor connector (A).
  4. Remove the installation bolt (B), and then remove the sensor from the cylinder block.
Temperature [°C (°F)]Resistance (kohms)
40 (-40)52.15
20 (-4)16.52
0 (32)6.0
20 (68)2.45
40 (104)1.11
60 (140)0.54
80 (176)0.29

TEMPERATURE RESISTANCE REFERENCE CHART

Scheme 358

Scheme 358: Circuit Diagram
Scheme 358: Circuit Diagram
Accelerator PositionOutput Voltage (V)
APS1APS2
C.T0.7 ~ 0.80.29 ~ 0.46
W.O.T3.85 ~ 4.351.93 ~ 2.18

VOLTAGE SPECIFICATION CHART

Scheme 359

Scheme 359
Scheme 359

Scheme 360

Scheme 360: Circuit Diagram
Scheme 360: Circuit Diagram
Pressure [kPa (kgf/cm 2 , in H2O)Output Voltage (V)
6.67 (-0.068, -26.8)0.5
02.5
+6.67 (0.068, 26.8)4.5

VOLTAGE SPECIFICATION CHART

Scheme 361

Scheme 361
Scheme 361

Scheme 362

Scheme 362: Circuit Diagram
Scheme 362: Circuit Diagram
ItemSpecification
Coil Resistance (ohms)1.25 [20°C (68°F)]

ITEM SPECIFICATION CHART

Scheme 363

Scheme 363: Signal Waveform
Scheme 363: Signal Waveform

Scheme 364

Scheme 364
Scheme 364

Scheme 365

Scheme 365: Circuit Diagram
Scheme 365: Circuit Diagram
ItemSpecification
Coil Resistance (ohms)19.0 ~ 22.0 [20°C (68°F)]

ITEM SPECIFICATION CHART

Scheme 366

Scheme 366: Circuit Diagram
Scheme 366: Circuit Diagram
ItemSpecification
Coil Resistance (ohms)6.9 ~ 7.9 [20°C (68°F)]

ITEM SPECIFICATION CHART

Scheme 367

Scheme 367: Circuit Diagram
Scheme 367: Circuit Diagram
ItemSpecification
Coil Resistance (ohms)0.5 [20°C (68°F)

ITEM SPECIFICATION CHART

Scheme 368

Scheme 368: Signal Waveform
Scheme 368: Signal Waveform

Scheme 369

Scheme 369: Circuit Diagram
Scheme 369: Circuit Diagram

[EWGA Position Sensor]

PositionOutput Voltage[V]Operating Angle[°]Range of Rod [mm], reference
Mechanical Close end stop Position (MCP)4.800
Electrical Close end stop Position (ECP)4.2121.8
Electrical Open end stop Position (EOP)17916
Mechanical Open end stop Position (MOP)0.59018

VOLTAGE SPECIFICATION CHART

Scheme 370

Scheme 370
Scheme 370

Scheme 371

Scheme 371
Scheme 371

[EWGA DC Motor]

ItemSpecification
Coil Resistance (ohms)1.48 ~ 1.96 [21°C (69.8°F)]

ITEM SPECIFICATION CHART

Scheme 372

Scheme 372: Signal Waveform
Scheme 372: Signal Waveform

Scheme 373

Scheme 373: Circuit Diagram
Scheme 373: Circuit Diagram
ItemSpecification
Coil Resistance (ohms)28.3 ~ 31.1 [20°C (68°F)]

ITEM SPECIFICATION CHART

Scheme 374

Scheme 374: Circuit Diagram
Scheme 374: Circuit Diagram
ItemSpecification
Coil Resistance (ohms)19.9 ~ 22.9 [20°C (68°F)]

ITEM SPECIFICATION CHART

Scheme 375

Scheme 375: Circuit Diagram
Scheme 375: Circuit Diagram
