Engine Control System - Hev: Specifications Hyundai Sonata VI

Testing & Diagnostics 18 illustrations ~180 words

Specification

Pressure (kPa)Output Voltage (V)
20.00.79
46.71.84
101.34.0

PRESSURE AND OUTPUT VOLTAGE SPECIFICATIONS

Scheme 50

Scheme 50
Scheme 50

Scheme 51

Scheme 51: Waveform
Scheme 51: Waveform

Scheme 52

Scheme 52: Circuit Diagram
Scheme 52: Circuit Diagram
Temperature [°C(°F)]Resistance (kohms)
40(-40)40.93 ~ 48.35
20(-4)13.89 ~ 16.03
0(32)5.38 ~ 6.09
10(50)3.48 ~ 3.90
20(68)2.31 ~ 2.57
40(104)1.08 ~ 1.21
50(122)1.56 ~ 1.74
60(140)0.54 ~ 0.62
80(176)0.29 ~ 0.34

TEMPERATURE AND RESISTANCE SPECIFICATIONS

Scheme 53

Scheme 53
Scheme 53

Scheme 54

Scheme 54: Circuit Diagram
Scheme 54: Circuit Diagram
TemperatureResistance (kohms)
°C°F
404048.14
20414.13 ~ 16.83
0325.79
20682.31 ~ 2.59
401041.15
601400.59
801760.32

TEMPERATURE AND RESISTANCE SPECIFICATIONS

Scheme 55

Scheme 55: Circuit Diagram
Scheme 55: Circuit Diagram
ItemSpecification
Capacitance (pF)850 ~ 1,150

CAPACITANCE SPECIFICATIONS

Scheme 56

Scheme 56: Circuit Diagram
Scheme 56: Circuit Diagram

Scheme 57

Scheme 57: Removal
Scheme 57: Removal

Scheme 58

Scheme 58
Scheme 58
  1. Turn the ignition switch OFF and disconnect the battery negative (-) cable.
  2. Drain the engine coolant (Refer to " «COOLING SYSTEM»(ref-419395) " in EM group).
  3. Remove the radiator upper hose (Refer to " «COOLING SYSTEM»(ref-419395) " in EM group).
  4. Disconnect the knock sensor connector (A).
  5. Remove the intake manifold (Refer to " «INTAKE AND EXHAUST SYSTEM»(/hyundai/sonata/vi-2009-2014/remont/exhaust/#engine-intake-system-and-exhaust-system-hev) " in EM group).
  6. Remove the installation bolt (A), and then remove the sensor from the cylinder block.
Accelerator PositionOutput Voltage (V)
APS1APS2
C.T0.7 ~ 0.80.29 ~ 0.46
W.O.T3.85 ~ 4.351.93 ~ 2.18

OUTPUT VOLTAGE SPECIFICATIONS

Scheme 59

Scheme 59
Scheme 59

Scheme 60

Scheme 60: Circuit Diagram
Scheme 60: Circuit Diagram
ItemSpecification
Coil Resistance (ohms)13.8 ~ 15.2 [20°C(68°F)]

RESISTANCE SPECIFICATIONS

Scheme 61

Scheme 61: Circuit Diagram
Scheme 61: Circuit Diagram
ItemSpecification
Coil Resistance (ohms)19.0 ~ 22.0 [20°C(68°F)]

RESISTANCE SPECIFICATIONS

Scheme 62

Scheme 62: Circuit Diagram
Scheme 62: Circuit Diagram
ItemSpecification
Coil Resistance (ohms)6.9 ~ 7.9 [20°C(68°F)]

RESISTANCE SPECIFICATIONS

Scheme 63

Scheme 63: Circuit Diagram
Scheme 63: Circuit Diagram
ItemCurrent (mA)
Switch openSwitch close
Power supplyApprox. 2.0Approx. 3.0
Data lineApprox. 10.0

CURRENT SPECIFICATIONS

Scheme 64

Scheme 64: Waveform
Scheme 64: Waveform

Scheme 65

Scheme 65: Circuit Diagram
Scheme 65: Circuit Diagram

Scheme 66

Scheme 66: Removal
Scheme 66: Removal

Scheme 67

Scheme 67
Scheme 67
  1. Turn the ignition switch OFF and disconnect the battery negative (-) cable.
  2. Disconnect the NVLD connector (A).
  3. Disconnect the ventilation hoses (B, C).
  4. Remove the NVLD after removing 3 bolts.
