Interior Trim Hyundai Santa Fe III

Scheme 22

Scheme 23

Replacement

Note. When prying with a flat-tip screwdriver, wrap it with protective tape, and apply protective tape around the related parts, to prevent damage. Use a plastic panel removal tool to remove interior trim pieces to protect from marring the surface. Take care not to bend or scratch the trim and panels.

Scheme 24

Scheme 25

1. Using a screwdriver or remover, remove the front door scuff tirm (A). [Front]
2. Using a screwdriver or remover, remove the rear door scuff trim (A). [Rear]
3. Install in the reverse order of removal. Information Replace any damaged clips.

Scheme 26

Note. When prying with a flat-tip screwdriver, wrap it with protective tape, and apply protective tape around the related parts, to prevent damage. Use a plastic panel removal tool to remove interior trim pieces to protect from marring the surface. Take care not to bend or scratch the trim and panels.

Scheme 27

1. Remove the front door scuff trim. Refer to «DOOR SCUFF TRIM»(/hyundai/santa-fe/iii-2012-2016/remont/exteriorinterior-trim/#interior-trim) .
2. Remove the hood latch release handle. Refer to «HOOD LATCH RELEASE HANDLE»(/hyundai/santa-fe/iii-2012-2016/remont/exterior-body-panels/#hood) .
3. Slightly remove the front door body side weatherstrip.
4. Using a screwdriver or remover, remove the cowl side trim (A).
5. Install in the reverse order of removal. Information Replace any damaged clips.

Scheme 28

Note. When prying with a flat-tip screwdriver, wrap it with protective tape, and apply protective tape around the related parts, to prevent damage. Use a plastic panel removal tool to remove interior trim pieces to protect from marring the surface. Take care not to bend or scratch the trim and panels.

Scheme 29

1. Using a screwdriver or remover, remove the front pillar trim (A).
2. Install in the reverse order of removal. Information Replace any damaged clips.

Scheme 30

(Driver's)

Note. When prying with a flat-tip screwdriver, wrap it with protective tape, and apply protective tape around the related parts, to prevent damage. Use a plastic panel removal tool to remove interior trim pieces to protect from marring the surface. Take care not to bend or scratch the trim and panels.

Scheme 31

Scheme 32

1. Remove the front door scuff trim. Refer to «DOOR SCUFF TRIM»(/hyundai/santa-fe/iii-2012-2016/remont/exteriorinterior-trim/#interior-trim) .
2. Remove the rear door scuff trim. Refer to «DOOR SCUFF TRIM»(/hyundai/santa-fe/iii-2012-2016/remont/exteriorinterior-trim/#interior-trim) .
3. Slighty remove the front door body side weatherstrip.
4. Slighty remove the rear door body side weatherstrip.
5. Remove the seat belt lower anchor cover (A).
6. After loosening the mounting bolt, then remove the seat belt lower anchor (B). Tightening torque: 39.2 ~ 53.9 N.m (4.0 ~ 5.5 kgf.m, 28.8 ~ 39.8 lb-ft)
7. Using a screwdriver or remover, remove the center pillar lower trim (A).
8. Install in the reverse order of removal. Information Replace any damaged clips.

(Passenger's)

Note. When prying with a flat-tip screwdriver, wrap it with protective tape, and apply protective tape around the related parts, to prevent damage. Use a plastic panel removal tool to remove interior trim pieces to protect from marring the surface. Take care not to bend or scratch the trim and panels.

Scheme 33

Scheme 34

1. Remove the front door scuff trim. Refer to «DOOR SCUFF TRIM»(/hyundai/santa-fe/iii-2012-2016/remont/exteriorinterior-trim/#interior-trim) .
2. Remove the rear door scuff trim. Refer to «DOOR SCUFF TRIM»(/hyundai/santa-fe/iii-2012-2016/remont/exteriorinterior-trim/#interior-trim) .
3. Slighty remove the front door body side weatherstrip.
4. Slighty remove the rear door body side weatherstrip.
5. To remove the locking mechanism (A), using a (-) driver (B) turn it counter clockwise. from the EFD (Emergency Fastening Device) system (C).
6. Using a screwdriver or remover, remove the center pillar lower trim (A).
7. Install in the reverse order of removal. Information Replace any damaged clips.

[Center pillar upper trim]

Note. When prying with a flat-tip screwdriver, wrap it with protective tape, and apply protective tape around the related parts, to prevent damage. Use a plastic panel removal tool to remove interior trim pieces to protect from marring the surface. Take care not to bend or scratch the trim and panels.

Scheme 35

1. Remove the center pillar lower trim. Refer to «CENTER PILLAR TRIM»(/hyundai/santa-fe/iii-2012-2016/remont/exteriorinterior-trim/#interior-trim) .
2. After loosening the mounting bolt, then remove the center pillar upper trim (A).
3. Install in the reverse order of removal. Information Replace any damaged clips.

Scheme 36

Information

1. When prying with a flat-tip screwdriver, wrap it with protective tape, and apply protective tape around the related parts, to prevent damage.
2. Use a plastic panel removal tool to remove interior trim pieces to protect from marring the surface.
3. Take care not to bend or scratch the trim and panels.

Scheme 37

Scheme 38

1. After loosening the mounting screws, then remove the luggage floor box (A).
2. Using a screwdriver or remover, remove the rear transverse trim (A).
3. Install in the reverse order of removal. Information Replace any damaged clips.

Scheme 39

Note. When prying with a flat-tip screwdriver, wrap it with protective tape, and apply protective tape around the related parts, to prevent damage. Use a plastic panel removal tool to remove interior trim pieces to protect from marring the surface. Take care not to bend or scratch the trim and panels.

Scheme 40

Scheme 41

Scheme 42

Scheme 43

Scheme 44

Scheme 45

1. Push the second row seat towards the front of the vehicle as far as possible.
2. Open the folding cable connector cap (A).
3. Remove the folding cable connector (A) from the second row seat cable.
4. Remove the third row seat. Refer to «REAR SEAT ASSEMBLY»(/hyundai/santa-fe/iii-2012-2016/remont/seats/#rear-seat) .
5. Remove the second row seat. Refer to «REAR SEAT ASSEMBLY»(/hyundai/santa-fe/iii-2012-2016/remont/seats/#rear-seat) .
6. Remove the rear door scuff trim. Refer to «DOOR SCUFF TRIM»(/hyundai/santa-fe/iii-2012-2016/remont/exteriorinterior-trim/#interior-trim) .
7. Remove the rear transverse trim. Refer to «REAR TRANSVERSE TRIM»(/hyundai/santa-fe/iii-2012-2016/remont/exteriorinterior-trim/#interior-trim) .
8. Slighty remove the rear door body side weatherstrip.
9. Slighty remove the tail gate weatherstrip.
10. Remove the second row seat belt lower anchor cover (A).
11. After loosening the mounting bolt, then remove the second row seat belt lower anchor (B). Tightening torque: 39.2 ~ 53.9 N.m (4.0 ~ 5.5 kgf.m, 28.8 ~ 39.8 lb-ft)
12. After loosening the mounting bolt, then remove the third row seat belt lower anchor (A). Tightening torque: 39.2 ~ 53.9 N.m (4.0 ~ 5.5 kgf.m, 28.8 ~ 39.8 lb-ft)
13. Remove the seat remote folding housing (A).
14. After loosening the mounting screws, then remove the luggage side trim (A).
15. Install in the reverse order of removal. Information Replace any damaged clips.

Scheme 46

Note. When prying with a flat-tip screwdriver, wrap it with protective tape, and apply protective tape around the related parts, to prevent damage. Use a plastic panel removal tool to remove interior trim pieces to protect from marring the surface. Take care not to bend or scratch the trim and panels.

Scheme 47

1. Remove the luggage side trim. Refer to «LUGGAGE SIDE TRIM»(/hyundai/santa-fe/iii-2012-2016/remont/exteriorinterior-trim/#interior-trim) .
2. After loosening the mounting bolt, then remove the rear pillar trim (A).
3. Install in the reverse order of removal. Information Replace any damaged clips.
