Mobile Telemetics System (mts) Hyundai Santa Fe III

Scheme 11

Hyundai motor companies are now faced with the task of shifting their paradigm from vehicle-centered services to customer value centered services, with the ultimate goal of securing global leadership in the field of vehicle IT and telematics.

Hyundai Motor plans to achieve this by realizing a terminal platform flexible to changes in IT technology, cooperating with global IT companies, creating an eco-system and providing the latest contents & services based on an open environment.

Blue Link is a dynamic, telematics technology that allows Hyundai vehicles to send---and receive---important and useful information.

The system uses an enhanced cellular network, with automatic roaming, that optimizes connections and prioritizes emergency requests.

With Blue Link you get...

1. Automatic emergency assistance, in the unfortunate event of a collision.
2. The convenience of point-of-interest search and navigation assistance, as well as the ability to remotely operate various vehicle features.
3. The peace of mind of self-diagnostic vehicle reports, and more.

Main Features

1. TMU Concept: Registered driver request the Service from Call Center (Safety and Security, TBT service, etc.)
2. GPS & CDMA Communication: Connect the Call Center by CDMA. Use Simple Navigation System by GPS & CDMA (Only Audio type).
3. Integrate a Voice Recognition & Communication: User can operate the service by Speech Recognition (only Audio) User can use downloaded POI Data by CDMA (only AVN).
4. Control BCM by Call Center Service: Door Lock/Unlock, Horn/Light, Remote Start/Stop be operate by Service.

Scheme 12

Scheme 13

Using procedures

1. Enrolling in Blue Link After the enrollment process, you can use to access your Blue Link preferences. NOTE: For more detail procedure, please refer to the Blue Link owner's manual.
2. Subscribe the Blue Link Packages Blue Link services come in three groupings, or packages: Assurance Automatic Collision Notification and Assistance SOS Emergency Assist Enhanced Roadside Assist Monthly Vehicle Report Essentials Convenience: Remote Door Lock Remote Door Unlock Remote Horn/Lights Remote Vehicle Start* Quick Tips Location Sharing Voice Text Messaging Vehicle Self Diagnostics: Automatic Diagnostics Trouble Code Notification Maintenance Alert Recall Advisor Service Link Safeguard: Stolen Vehicle Recovery Stolen Vehicle Slowdown Vehicle Immobilization Valet Alert Panic Notification Alarm Notification Geo-Fence Speed Alert Curfew Alert Guidance Point of Interest Search by Advanced Voice Recognition Point of Interest Web Search & Download Turn-by-Turn Navigation** Daily Route Guidance with Traffic Conditions Traffic Gas Station Locations & Gas Prices Eco-Coach Restaurant Ratings & Locations Weather Owners can subscribe to Blue Link packages in the following groupings; Assurance Assurance + Essentials Assurance + Essentials + Guidance
3. Setting Blue Link preferences Many Blue Link features, reports, or alerts require setup, with input from you. NOTE: For more detail procedure, please refer to the Blue Link owner's manual.
4. Accessing Blue Link preferences Smart Phone Mobile Application You can download the Blue Link mobile app to your compatible smart phone. For more detail procedure, please refer to the Blue Link owner's manual. In-car Application Controls for Blue Link in-vehicle voice-response use are located on the rearview mirror. NOTE: For more detail procedure, please refer to the Blue Link owner's manual. Web Application Many Blue Link features can be customized, activated, or accessed at www.MyHyundai.com. This is your important link to getting the most out of your Blue Link system. NOTE: For more detail procedure, please refer to the Blue Link owner's manual.

Service List

1. Safety and Security Service Name Service Trigger Auto Collision Notification In the event of an accident or air bag deployment, ACN notification will be triggered automatically. SOS - Emergency Assistance It will be triggered by manually pressing the SOS button on the inside mirror. It will connect you to emergency assistance helper. Alarm/Panic Notification when the vehicle alarm system is activated, it will be automatically triggered and inform to owner. If the customer push the panic button of key FOB near the vehicle, it will be triggered and notify that driver or vehicle occupant may be in danger Enhanced roadside Push the Interactive Voice Recognition (IVR) button on the inside mirror and ask the operator for help. Speed Alert Customer can setup notification limit of vehicle speed on the web or by asking operator using IVR call. Remote Door Control - Lock Customer can ask for Remote Door Lock service by using the Smart Phone application or on the web (CWP) or asking the operator by IVR call. Remote Door Control - Unlock Customer can ask for Remote Door Unlock service by using the Smart Phone application or on the web (CWP) or asking the operator by IVR call. Remote Horn and Lights Customer can ask Horn&Light or Light Only services by using the Smart Phone application or on the web (CWP) or asking the operator by IVR call. Stolen Vehicle Recovery In the event your vehicle or reported stolen, to law enforcement authorities, the BlueLink Customer Care Center can use the GPS system to help pinpoint the exact location of the vechicle and assist in its recovery. The customer can ask stolen vehicle recovery by using phone, or on the web. Vehicle Immobilization/Slowdown This service can be triggered on request by police only Curfew Alert The customer can setup notification time interval that vehicle being used on the web or by asking operator using IVR call. Vehicle Remote Start The customer can ask remote start service by using the Smart Phone application or on the web (CWP) or asking to operator by IVR call. (Automatic transmission only)
2. Voice Recognition Module (VRM) Service Name Service Trigger Eco Coach Showing the eco-coach window. The customer can see the average efficiency curve of fuel consumption by selecting eco-coach software button into the Info menu (AVN) or saying "eco-coach on" using PTT button on the inside mirror. (Audio) AVN TMU Selecting eco-coach button Audio TMU Saying "Eco-coach on" menu: Press PTT button on the inside mirror, after heard "Please say command" sound, say "Eco- coach on" See the fuel consumption on the web. Refer to the telematics web service manual for detail information. Maintenance Alert Notification Refer the telematics web service manual for detail information about setup mile triggered to diagnostic service Automated DTC notification If the vehicle has identified a problem, this information will be sent for server automatically. Recall and campaign advisor When any recall or campaign notification for his vehicle is sent by HMC, it will be shown in the illustration on the screen. The customer can hear notification by using IVR call, after the notification, the popup will be removed automatically. Web- Based Diagnostics The customer can check the status of vehicle using telematics web server. Refer to the telematics web service manual for more information. Scheduled Diagnostics There are two kinds of scheduled diagnostic options. Please see telematics web service manual for more information.
3. Geographic Information System (GIS) Service Name Service Trigger Traffic Flow Accident Construction Control The customer can hear construction or accident condition on the driving road flow using IVR call. Please ask operator after IVR call connected. Daily Route Guide with Traffic The customer can hear traffic comparison between several road using IVR call. Please ask Operator after IVR call connected. Before listen this service, the customer should establish the routes on the web. Refer to ttelematics web service manual for more information. Gas Station Location and Fuel Prices The customer can hear Gas station location and Fuel prices using IVR call, Point of Interests (POI) information can be downloaded on the vehicle. Geo-Fence The customer can setup valid boundary of vehicle driving. It can be used for V alert geo-fence or normal geofence. Both can be setup by web or by asking operator using IVR call. Operator Navigation The customer can hear navigation using IVR call. POI by Guided IVR with Operator Backup POI download can be requested via IVR call. POI Download via Web Portal POI download can be requested using web portal. POI Searching by IVR (TMU and Phone) POI download can be requested via IVR call. Location Sharing For this service, the customer should pre-register a friend information on the web. When your friend asks inform he's/she's location to you, it can will be download by a kinds of POI.
4. Operator Service & ETC Service Name Service Trigger IVR Owner's Manual The Customer can hear how to using about any kinds of vehicle Manual. Please ask operator on the IVR call. Operator Assisted Owner's Manual The Customer can hear how to use any Manual. Please ask operator on the IVR call. Q-feedback This is a diagnostic services. When customer hear any unusual noise on the vehicle, customer can ask to check the vehicle using IVR call. Service Name Service Trigger Voice Text Messaging Pair a Bluetooth phone to the vehicle's Bluetooth system. Use the vehicle's Bluetooth system to call, toll-free, 877-730-2896 Provisioning In case of being powered on for the first time at the Hyundai Factory for North American or US Port. TMU Disable Mode "blueLink not active. Please call xxx-xxx-xxxx" will be displayed when any button is pushed. TMU Swap The Proper TMU (TeleMatics Unit) should be installed on the vehicle. "Incorrect Telematics Unit Contact Dealer" will be displayed if incorrect TMU is installed.

Scheme 14

[Audio type]

[AVN type]

Scheme 15

Scheme 16

Scheme 17

1. Disconnect the negative (-) battery terminal.
2. Remove the glove box housing. Refer to «GLOVE BOX HOUSING»(/hyundai/santa-fe/iii-2012-2016/remont/gauges-instrument-panels/#crash-pad) .
3. Disconnect the cables and connector (A) from the MTS unit. [Audio type] [AVN type]
4. Remove the MTS unit after loosening the nuts (2EA) and a bolt.

Installation

1. Connect the connector and cables.
2. Install the MTS unit.
3. Install the glove box housing.
4. Connect the negative (-) battery terminal.

Inspection

1. After replacing the TMU, connect to "call center" by pushing the Blue Link button.
2. If Blue Link service connected successfully, and then technician can hear the "Welcome to Hyundai Bluelink" sound. NOTE: After replacing the TMU, the TMU automatically read the Vehicle Identity Number (VIN) and send it to Blue Link service center. In this reason, technician have to test that Blue Link connect normally.

Scheme 18

Removal

1. Remove the Electro chromic Inside rear view mirror. (Refer to «REPLACEMENT»(/hyundai/santa-fe/iii-2012-2016/remont/mirrors/#mirror) Electro Chromic Inside Rear View Mirror)

1. Install the Electro chromic Inside rear view mirror. (Refer to «REPLACEMENT»(/hyundai/santa-fe/iii-2012-2016/remont/mirrors/#mirror) Electro Chromic Inside Rear View Mirror)

Scheme 19

1. Remove the roof antenna. (Refer to " «ANTENNA»(/hyundai/santa-fe/iii-2012-2016/remont/entertainment-systems/#audio-system) ") (Refer to " «ROOF ANTENNA»(/hyundai/santa-fe/iii-2012-2016/remont/entertainment-systems/#audiovideonavigation-system) ")

1. Install the roof antenna. (Refer to " «ANTENNA»(/hyundai/santa-fe/iii-2012-2016/remont/entertainment-systems/#audio-system) ") (Refer to " «ROOF ANTENNA»(/hyundai/santa-fe/iii-2012-2016/remont/entertainment-systems/#audiovideonavigation-system) ")
