There is no hands free jack. This system supports Bluetooth (wireless system).
General Features
- This audio system supports Bluetooth® hands-free and stereo-headset features. HANDS-FREE feature: Making or receiving calls wirelessly. STEREO-HEADSET feature: Playing music from cellular phones (that supports A2DP feature) wirelessly. NOTE: The phone must be paired to the system before using Bluetooth® features. Only one selected (connected) cellular phone can be used with the system at a time. Some phones are not fully compatible with this system.
Scheme 2
Scheme 2: Circuit Diagram
Inspection
- Check for resistance between terminals in each switch position.
Scheme 3
Bluetooth
| Switch | Connector terminal | Resistance (± 5%) |
|---|
| End | 2-5 | 12.1 kohms |
| Send | 2-5 | 34.1 kohms |
Bluetooth + Voice
| Switch | Connector terminal | Resistance (± 5%) |
|---|
| Voice | 2-5 | 3.9 kohms |
| End | 2-5 | 12.1 kohms |
| Send | 2-5 | 34.1 kohms |
Scheme 4
Scheme 5
Scheme 6
- Disconnect the negative (-) battery terminal.
- Remove the driver airbag module. (Refer to " «DRIVER AIRBAG (DAB) MODULE AND CLOCK SPRING»(/hyundai/santa-fe/iii-2012-2016/remont/airbag/#airbag-modules-clock-spring) ")
- Remove the steering wheel. (Refer to " «STEERING COLUMN AND SHAFT»(/hyundai/santa-fe/iii-2012-2016/remont/electronic-steering/#electric-power-steering) ")
- Remove the steering wheel cover (A) after loosening the screws.
- Loosen the screws after disconnecting the steering wheel remote control switch connector (A).
- Remove the handsfree remote control switches (A).
Scheme 7
Installation
- Install the remote control switch on the steering wheel.
- Install the steering wheel.
- Reconnect the remote control switch connector and airbag connectors. NOTE: Make sure that the switch connector is plugged in properly.
- Install the driver airbag module.
- Connect the negative (-) battery terminal.
Scheme 8
Scheme 9
- Disconnect the negative (-) battery terminal.
- Separate the handsfree mic (A) from the roof trim.
- Remove the handsfree mic (B) after disconnecting the handsfree mic connector (A).
- Check the continuity of Mic between terminals.
Scheme 10
Troubleshooting
| Problem | Possible cause | Solution |
|---|
| Not pairing | Bluetooth device of Car is not discoverable mode | Enter Bluetooth pairing (searching) mode |
| User's phone is Bluetooth off mode | User's phone set Bluetooth on |
| Making an attempt pairing others bluetooth system | Check Bluetooth device name and address (12 word) to attempt paring Ex) 000B24FFF123 |
| Pass key error | Input the passkey displayed on the audio screen into the phone. |
| 5 phones have already been registered. | Delete paired phone list |
| Bluetooth system cannot communicate with the phone. | Refer to IOP sheet IOP: Inter-operability |
| Not connection | User's phone or Bluetooth device of Car dose not register Bluetooth device to connect | Retry pairing |
| Bluetooth system cannot communicate with the phone. | Waiting 1minute then Retry connection or phone power off/on. Refer to IOP sheet |
| Not redial | User phone system issue | Push the 2 times Send button |
| Not accept call | User phone system issue | Refer to IOP sheet |
| Not dialing | User's phone playing other menu (internet, mp3, game, etc..) | Stop other menu then set normal mode |
| Bluetooth system cannot communicate with the phone | Refer to IOP sheet |
