General Type

CAUTIONPut on gloves to protect your hands.

Information

  1. When prying with a flat-tip screwdriver, wrap it with protective tape, and apply protective tape around the related parts, to prevent damage.
  2. Take care not to scratch the body surface.

Scheme 65

Scheme 65
  1. Remove the roof rack front cover (A) and roof rack rear cover (B).
  2. Remove the roof rack center cover (C).
  3. After loosening the mounting nuts, then remove the roof rack assembly (D).
  4. Remove the roof front molding (E) and roof rear molding (F).
  5. Using a screwdriver or remover, remove the roof molding (G).
  6. Install in the reverse order of removal. Information Replace any damaged clips.

Panorama sunroof Type

CAUTIONPut on gloves to protect your hands.

Information

  1. When prying with a flat-tip screwdriver, wrap it with protective tape, and apply protective tape around the related parts, to prevent damage.
  2. Take care not to scratch the body surface.

Scheme 66

Scheme 66
  1. Remove the roof rack front cover (A) and roof rack rear cover (B).
  2. Remove the roof rack center cover (C).
  3. After loosening the mounting nuts, then remove the roof rack assembly (D).
  4. Using a screwdriver or remover, remove the roof molding (E).
  5. Install in the reverse order of removal. Information Replace any damaged clips.

Replacement

CAUTIONPut on gloves to protect your hands.

Note. When prying with a flat-tip screwdriver, wrap it with protective tape, and apply protective tape around the related parts, to prevent damage. Take care not to scratch the body surface.

Scheme 67

Scheme 67
  1. Using a screwdriver or remove the delta garnish (A).
  2. Install in the reverse order of removal. Information Replace any damaged clips.
CAUTIONPut on gloves to protect your hands.

Note. When prying with a flat-tip screwdriver, wrap it with protective tape, and apply protective tape around the related parts, to prevent damage. Take care not to scratch the body surface.

Scheme 68

Scheme 68

Scheme 69

Scheme 69

Scheme 70

Scheme 70
  1. Remove the tail gate upper trim. Refer to «TAIL GATE TRIM»(/hyundai/santa-fe/iii-2012-2016/remont/exterior-body-panels/#tail-gate)
  2. Disconnect the washer nozzle (A) and high mounted stop lamp connector (B).
  3. Loosen the rear spoiler mounting nuts (A). Tightening torque: 5.9 ~ 6.4 N.m (0.6 ~ 0.65 kgf.m, 4.3 ~ 4.7 lb-ft)
  4. Remove the rear spoiler (A).
  5. Install in the reverse order of removal. Information Make sure the connector is connected properly. Replace any damaged clips.
CAUTIONPut on gloves to protect your hands.

Note. When prying with a flat-tip screwdriver, wrap it with protective tape, and apply protective tape around the related parts, to prevent damage. Take care not to scratch the body surface.

Scheme 71

Scheme 71
  1. Loosen the fender garnish mounting screws.
  2. Using a screwdriver or remover, remove the fender garnish (A).
  3. Install in the reverse order of removal. Information Replace any damaged clips.
CAUTIONPut on gloves to protect your hands.

Note. When prying with a flat-tip screwdriver, wrap it with protective tape, and apply protective tape around the related parts, to prevent damage. Take care not to scratch the body surface.

Scheme 72

Scheme 72
  1. Using a screwdriver or remove the quarter garnish (A).
  2. Install in the reverse order of removal. Information Replace any damaged clips.
CAUTIONPut on gloves to protect your hands.

Note. When prying with a flat-tip screwdriver, wrap it with protective tape, and apply protective tape around the related parts, to prevent damage. Take care not to scratch the body surface.

Scheme 73

Scheme 73
  1. Remove the front door module. Refer to «FRONT DOOR MODULE»(/hyundai/santa-fe/iii-2012-2016/remont/exterior-body-panels/#front-door)
  2. Remove the rear door module. Refer to «REAR DOOR MODULE»(/hyundai/santa-fe/iii-2012-2016/remont/exterior-body-panels/#rear-door)
  3. After loosening the mounting nuts, then remove the front door garnish (A) and rear door garnish (B).
  4. Install in the reverse order of removal. Information Replace any damaged clips.
CAUTIONPut on gloves to protect your hands.

Note. When prying with a flat-tip screwdriver, wrap it with protective tape, and apply protective tape around the related parts, to prevent damage. Take care not to scratch the body surface.

Scheme 74

Scheme 74
  1. Remove the front tire.
  2. After loosening the mounting clips and screws, then remove the front wheel guard (A).
  3. Install in the reverse order of removal. Information Replace any damaged clips.
CAUTIONPut on gloves to protect your hands.

Note. When prying with a flat-tip screwdriver, wrap it with protective tape, and apply protective tape around the related parts, to prevent damage. Take care not to scratch the body surface.

Scheme 75

Scheme 75
  1. Remove the rear tire.
  2. After loosening the mounting clips and nut, then remove the rear wheel guard (A).
  3. Install in the reverse order of removal. Information Replace any damaged clips.
CAUTIONPut on gloves to protect your hands.

Note. When prying with a flat-tip screwdriver, wrap it with protective tape, and apply protective tape around the related parts, to prevent damage. Take care not to scratch the body surface.

Scheme 76

Scheme 76
  1. After loosening the mounting clip and screws, then remove the front mud guard (A).
  2. Install in the reverse order of removal. Information Replace any damaged clips.
CAUTIONPut on gloves to protect your hands.

Note. When prying with a flat-tip screwdriver, wrap it with protective tape, and apply protective tape around the related parts, to prevent damage. Take care not to scratch the body surface.

Scheme 77

Scheme 77
  1. After loosening the mounting clip and screws, then remove the rear mud guard (A).
  2. Install in the reverse order of removal. Information Replace any damaged clips.
CAUTIONPut on gloves to protect your hands.

Note. When prying with a flat-tip screwdriver, wrap it with protective tape, and apply protective tape around the related parts, to prevent damage. Take care not to scratch the body surface.

Scheme 78

Scheme 78
  1. Loosen the side sill molding mounting screws.
  2. Using a screwdriver or remover, remove the side sill molding (A).
  3. Install in the reverse order of removal. Information Replace any damaged clips.
