Scheme 1: Components

Scheme 2

Scheme 2: Console rear complete assembly

Scheme 3

Scheme 3: Console front complete assembly

Console Rear Complete Assembly

CAUTIONPut on gloves to protect your hands.

Note. When prying with a flat-tip screwdriver, wrap it with protective tape, and apply protective tape around the related parts, to prevent damage. Use a plastic panel removal tool to remove interior trim pieces to protect from marring the surface. Take care not to bend or scratch the trim and panels.

Scheme 4

Scheme 4

Scheme 5

Scheme 5

Scheme 6

Scheme 6

Scheme 7

Scheme 7

Scheme 8

Scheme 8

Scheme 9

Scheme 9

Scheme 10

Scheme 10
  1. Remove the gear boots (B) and gear knob (A).
  2. Using a screwdriver or remover, remove the console upper cover (A).
  3. Disconnect the connectors (A).
  4. Remove the console armrest tray (A).
  5. Remove the console tray mat (A).
  6. After loosening the mounting screws and bolts, then remove the console rear complete assembly (A).
  7. Disconnect the power outlet connector (A).
  8. Install in the reverse order of removal. Information Make sure the connector is connected properly. Replace any damaged clips.

Console Front Complete Assembly

CAUTIONPut on gloves to protect your hands.

Note. When prying with a flat-tip screwdriver, wrap it with protective tape, and apply protective tape around the related parts, to prevent damage. Use a plastic panel removal tool to remove interior trim pieces to protect from marring the surface. Take care not to bend or scratch the trim and panels.

Scheme 11

Scheme 11

Scheme 12

Scheme 12

Scheme 13

Scheme 13

Scheme 14

Scheme 14

Scheme 15

Scheme 15
  1. Remove the console rear complete assembly. (Refer to " «FLOOR CONSOLE ASSEMBLY»(/hyundai/santa-fe/iii-2012-2016/remont/exteriorinterior-trim/#floor-console) ")
  2. Using a screwdriver or remover, remove the front console garnish (A).
  3. Using a screwdriver or remover, remove the console side cover (A). [LH] [RH]
  4. Disconnect the connectors (A).
  5. After loosening the mounting screws, then remove the console front complete assembly (A).
  6. Install in the reverse order of removal. Information Make sure the connector is connected properly. Replace any damaged clips.

Scheme 16

Scheme 16: Component Location

Replacement

CAUTIONPut on gloves to protect your hands.

Note. When prying with a flat-tip screwdriver, wrap it with protective tape, and apply protective tape around the related parts, to prevent damage. Use a plastic panel removal tool to remove interior trim pieces to protect from marring the surface. Take care not to bend or scratch the trim and panels.

Scheme 17

Scheme 17

Scheme 18

Scheme 18
  1. Using a screwdriver or remover, remove the rear console cover (A).
  2. Disconnect the power outlet connector (A).
  3. Install in the reverse order of removal. Information Make sure the connector is connected properly. Replace any damaged clips.

Scheme 19

Scheme 19: Component Location
CAUTIONPut on gloves to protect your hands.

Note. When prying with a flat-tip screwdriver, wrap it with protective tape, and apply protective tape around the related parts, to prevent damage. Use a plastic panel removal tool to remove interior trim pieces to protect from marring the surface. Take care not to bend or scratch the trim and panels.

Scheme 20

Scheme 20

Scheme 21

Scheme 21
  1. After loosening the mounting screws, then remove the console armrest cover (A).
  2. After loosening the mounting screws, then remove the console armrest (A).
  3. Install in the reverse order of removal. Information Replace any damaged clips.
