Automatic Transaxle System (A5HF1): Wiring Hyundai Azera I

Automatic Trans 10 illustrations ~544 words

SCHEMATIC DIAGRAM

Refer to DTC P0707 .

Refer to DTC P0712 .

Refer to DTC P0743 .

Scheme 120

Scheme 120: SIGNAL WAVEFORM

Scheme 121

Scheme 121: MONITOR SCANTOOL DATA
  1. Connect scantool to data link connector (DLC).
  2. Engine "ON".
  3. Monitor the "PRESS CONTROL SOL. VALVE" parameter on the scantool.
  4. Shift gear at each position.
  5. Does "PRESS CONTROL SOL DUTY" follow the reference data? YES Fault is intermittent caused by poor contact in the sensor's and/or TCM (PCM)'s connector or was repaired and TCM (PCM) memory was not cleared. Thoroughly check connectors for looseness, poor connection, bending, corrosion, contamination, deterioration or damage. Repair or replace as necessary and go to " «VERIFICATION OF VEHICLE REPAIR»(ref-287147-S05403628452008060600000) " procedure. NO Go to " «TERMINAL & CONNECTOR INSPECTION»(ref-287147-S07533564572008060600000) " procedure.

Refer to DTC P0750 .

Scheme 122

Scheme 122: SIGNAL WAVEFORM

Scheme 123

Scheme 123: MONITOR SCANTOOL DATA
  1. Connect scantool to data link connector (DLC)
  2. Engine "ON".
  3. Monitor the "UD SOL. VALVE" parameter on the scantool.
  4. Shift gear at each position.
  5. Does "UD SOLENOID DUTY" follow the reference data? YES Fault is intermittent caused by poor contact in the sensor's and/or TCM (PCM)'s connector or was repaired and TCM (PCM) memory was not cleared. Thoroughly check connectors for looseness, poor connection, bending, corrosion, contamination, deterioration or damage. Repair or replace as necessary and go to " «VERIFICATION OF VEHICLE REPAIR»(ref-287147-S35331199322008060600000) " procedure. NO Go to " «TERMINAL & CONNECTOR INSPECTION»(ref-287147-S29530338972008060600000) " procedure.

Refer to DTC P0750 .

Scheme 124

Scheme 124: SIGNAL WAVEFORM

Scheme 125

Scheme 125: MONITOR SCANTOOL DATA
  1. Connect scantool to data link connector (DLC).
  2. Engine "ON".
  3. Monitor the "2nd SOL. VALVE" parameter on the scantool.
  4. Shift gear at each position.
  5. Does "2nd SOLENOID DUTY" follow the reference data? YES Fault is intermittent caused by poor contact in the sensor's and/or TCM (PCM)'s connector or was repaired and TCM (PCM) memory was not cleared. Thoroughly check connectors for looseness, poor connection, bending, corrosion, contamination, deterioration or damage. Repair or replace as necessary and go to " «VERIFICATION OF VEHICLE REPAIR»(ref-287147-S37025888652008060600000) " procedure. NO Go to " «TERMINAL & CONNECTOR INSPECTION»(ref-287147-S15086437852008060600000) " procedure.

Refer to DTC P0750 .

Scheme 126

Scheme 126: SIGNAL WAVEFORM

Scheme 127

Scheme 127: MONITOR SCANTOOL DATA
  1. Connect scantool to data link connector (DLC).
  2. Engine "ON".
  3. Monitor the "OD SOL. VALVE" parameter on the scantool.
  4. Shift gear at each position.
  5. Does "OD SOLENOID DUTY" follow the reference data? YES Fault is intermittent caused by poor contact in the sensor's and/or TCM (PCM)'s connector or was repaired and TCM (PCM) memory was not cleared. Thoroughly check connectors for looseness, poor connection, bending, corrosion, contamination, deterioration or damage. Repair or replace as necessary and go to " «VERIFICATION OF VEHICLE REPAIR»(ref-287147-S17893071922008060600000) " procedure. NO Go to " «TERMINAL & CONNECTOR INSPECTION»(ref-287147-S41115803202008060600000) " procedure.

Refer to DTC P0750 .

Scheme 128

Scheme 128: SIGNAL WAVEFORM

Scheme 129

Scheme 129: MONITOR SCANTOOL DATA
  1. Connect scantool to data link connector (DLC).
  2. Engine "ON".
  3. Monitor the "RED SOL. VALVE" parameter on the scantool.
  4. Shift gear at each position.
  5. Does "RED SOLENOID DUTY" follow the reference data? YES Fault is intermittent caused by poor contact in the sensor's and/or TCM (PCM)'s connector or was repaired and TCM (PCM) memory was not cleared. Thoroughly check connectors for looseness, poor connection, bending, corrosion, contamination, deterioration or damage. Repair or replace as necessary and go to " «VERIFICATION OF VEHICLE REPAIR»(ref-287147-S28469739562008060600000) " procedure. NO Go to " «TERMINAL & CONNECTOR INSPECTION»(ref-287147-S25520633792008060600000) " procedure.

Refer to DTC P0885 .

Refer to DTC P0885 .
