Heating, Ventilation & Air Conditioning: Component Locations Hyundai Azera I

Automatic HVAC System 3 illustrations ~342 words

SPECIAL TOOLS

SPECIAL TOOLS REFERENCE CHART Tool (Number and name) Illustration Use 09977-29000 Disc & hub assembly bolt remover Removal and installation of disc & hub assembly

Scheme 186

Scheme 186: SPECIAL TOOLS
Scheme 186: SPECIAL TOOLS

Scheme 187

Scheme 187: WHEN HANDLING REFRIGERANT
Scheme 187: WHEN HANDLING REFRIGERANT
  1. R-134a liquid refrigerant is highly volatile. A drop on the skin of your hand could result in localized frostbite. When handling the refrigerant, be sure to wear gloves.
  2. It is standard practice to wear goggles or glasses to protect your eyes, and gloves to protect your hands. If the refrigerant splashes into your eyes, wash them with clean water immediately.
  3. The R-134a container is highly pressurized. Never leave it in a hot place, and check that the storage temperature is below 52°C (126°F)
  4. An electronic leak detector should be used to check the system for refrigerant leakage. Bear in mind that the R-134a, upon coming into contact with flame, produces phosgene, a highly toxic gas.
  5. Use only recommended the lubricant for R-134a systems. If lubricants other than the recommended one used, system failure may occur.
  6. PAG lubricant absorbs moisture from the atmosphere at a rapid rate, therefore the following precautions must be observed: When removing refrigerant components from a vehicle, cap immediately the components to prevent from the entry of moisture. When installing refrigerant components to a vehicle, do not remove the cap until just before connecting the components. Complete the connection of all refrigerant tubes and hoses without delay to prevent the A/C system from taking on moisture. Use the recommended lubricant from a sealed container only.
  7. If an accidental discharge in the system occurs, ventilate the work area before resuming service.

Scheme 188

Scheme 188: WHEN REPLACING PARTS ON A/C SYSTEM
Scheme 188: WHEN REPLACING PARTS ON A/C SYSTEM
  1. Never open or loosen a connection before discharging the system.
  2. Seal the open fittings of components with a cap or plug immediately to prevent intrusion of moisture or dust.
  3. Do not remove the sealing caps from a replacement component until it is ready to be installed.
  4. Before connecting an open fitting, always install a new sealing ring. Coat the fitting and seal with refrigerant oil before making the connection.
