Automatic Transaxle System (A5HF1): Component Locations Hyundai Azera I

SPECIAL TOOLS

SPECIAL TOOLS SPECIFICATION Tool (Number and name) Illustration Use 09200-38001 Engine support fixture Removal and installation of transaxle 09624-38000 Crossmember supporter Supporting of the crossmember

Scheme 130

Scheme 131

Scheme 132

Scheme 133

1. Structure & Technical highlights
2. Variable Line Pressure Control Description Form the most suitable line pressure according to the vehicle driving condition Special Features VFS (Variable Force Solenoid) valve (For varying line pressure) Reducing valve added (Stabilize control pressure in shirtings) Effects Improved power transmission efficiency and fuel consumption
3. Gear durability improvement and less-noisy gear development Description Optimal gear transmission ratio design from analyzing gears Special Features Apply High-strength gear material Gear teeth width increased Planetary gear (3 pinions --> 4 pinions) Less-noisy gear development Effects Durability improvement Reduction of noise level
4. Case/Housing intensity reinforced Description Case/Housing intensity reinforced Special Features Converter hosing intensity reinforced (Ribs added and thickness increased) Most suitable stiff reinforcement through analyzing Effects Intensity increased and banding vibration decreased NVH Performance improvement
5. New frictional material Description Apply new frictional material for capacity and durability improvement Special Features SSP (Single Sided Plate) applied only on overdrive clutch and 2nd brake Apply the next generation frictional material (BWA 6100/D 0880-88) Effects Thermal absorption capacity improvement Energy capacity and durability improvement

COMPONENT LOCATION

Refer to DTC P0707 .

Refer to DTC P0712 .

Refer to DTC P0717 .

Refer to DTC P0885 .

Refer to DTC P0885 .
