Automatic Transaxle System (A5HF1): Other Hyundai Azera I

Automatic Trans 28 illustrations ~1609 words

CLUTCHES AND BRAKES FOR EACH RANG

UD ClutchOD Clutch2ND BrakeLR BrakeREV ClutchRED BrakeDIR ClutchOWC 1OWC 2
POO
ROOO
NOO
D1stOOO(1)(1)
2ndOOO(1)
3rdOOO(1)
4thOOO(1)
5thOOO
(1) (: Locked when driving)
(1)(: Locked when driving)

CLUTCHES AND BRAKES FOR RANG

FUNCTIONS OF CLUTCHES AND BRAKE

ElementSignFunction
Underdrive clutchUDConnect the input shaft with the underdrive sun gear
Reverse clutchREVConnect the input shaft with the reverse sun gear
Overdrive clutchODConnect the input shaft with the overdrive carrier
Direct clutchDIRConnect the direct sun gear with the direct carrier
Low & Reverse brakeLRFix the planetary gear and the overdrive carrier
2nd brake2NDFix the reverse sun gear
Reduction brakeREDFix the direct sun gear
One way clutch 1OWC 1Control the rotational direction of the low & reverse ring gear
One way clutch 2OWC 2Control the rotational direction of the direct sun gear

CLUTCHES AND BRAKE FUNCTIONS

Scheme 134

Scheme 134: P/N

Scheme 135

Scheme 135: D (1 RANGE)

Scheme 136

Scheme 136: D (2 RANGE)

Scheme 137

Scheme 137: D (3 RANGE)

Scheme 138

Scheme 138: D (4 RANGE)

Scheme 139

Scheme 139: D (5 RANGE)

Scheme 140

Scheme 140: R RANGE

VERIFICATION OF VEHICLE REPAIR

After a repair, it is essential to verify that the fault has been corrected.

  1. Connect scantool and select "Diagnostic Trouble Codes (DTCs)" mode.
  2. Using a scantool, Clear DTC.
  3. Operate the vehicle within DTC Enable conditions in General information.
  4. Are any DTCs present? YES Go to the applicable troubleshooting procedure. NO System performing to specification at this time.

MONITOR SCANTOOL DATA

Refer to DTC P0707 .

Refer to DTC P0707 .

Scheme 141

Scheme 141: COMPONENT LOCATION

After a repair, it is essential to verify that the fault has been corrected.

  1. Connect scantool and select "Diagnostic Trouble Codes (DTCs)" mode.
  2. Using a scantool, Clear DTC.
  3. Operate the vehicle within DTC Enable conditions in General information.
  4. Are any DTCs present? YES Go to the applicable troubleshooting procedure. NO System performing to specification at this time.

Refer to DTC P0712 .

Refer to DTC P0712 .

Scheme 142

Scheme 142: COMPONENT LOCATION

After a repair, it is essential to verify that the fault has been corrected.

  1. Connect scan tool and select "Diagnostic Trouble Codes (DTCs)" mode.
  2. Using a scan tool, Clear DTC.
  3. Operate the vehicle within DTC Enable conditions in General information.
  4. Is resistance within specification? YES Go to the applicable troubleshooting procedure. NO System performing to specification at this time.

Refer to DTC P0717 .

Scheme 143

Scheme 143: COMPONENT LOCATION

After a repair, it is essential to verify that the fault has been corrected.

  1. Connect scantool and select "Diagnostic Trouble Codes (DTCs)" mode.
  2. Using a scantool, Clear DTC.
  3. Operate the vehicle within DTC Enable conditions in General information.
  4. Are any DTCs present? YES Go to the applicable troubleshooting procedure. NO System performing to specification at this time.

Scheme 144

Scheme 144: COMPONENT LOCATION

Refer to DTC P0731 .

Scheme 145

Scheme 145: COMPONENT LOCATION

Refer to DTC P0731 .

Scheme 146

Scheme 146: COMPONENT LOCATION

* It is difficult to "STALL TEST" in 4th gear, therefore Go to " SIGNAL CIRCUIT INSPECTION " procedure.

GEAR POSITIONELEMENT
L/R BRAKE2ND BRAKEU/D CLUTCHO/D CLUTCHRED BRAKEDIR CLUTCHREV CLUTCHOWC1OWC2
1stOOO
2ndOOO
3rdOOO
4thOOO
5thOOO
REVOOO
N, POO

OPERATING ELEMENT OF EACH SHIFTING RANGE

Low & Reverse Brake is released When the vehicle speed over the 5 MPH (7 km/h)

Scheme 147

Scheme 147: SIGNAL CIRCUIT INSPECTION
  1. Connect Scantool.
  2. Engine "ON".
  3. Monitor the "INPUT & OUTPUT SPEED SENSOR" parameter on the scantool.
  4. Accelerate the Engine speed until about 2000 RPM in the 4th gear. Specification: INPUT SPEED - (OUTPUT SPEED x GEAR RATIO) < or = 200 RPM
  5. Is "INPUT & OUTPUT SPEED SENSOR" within specifications? YES Go to " «COMPONENT INSPECTION»(ref-287147-S07310324572008060600000) " procedure. NO Check for electrical noise of circuit in INPUT & OUTPUT SPEED SENSOR or Replace INPUT & OUTPUT SPEED SENSOR. Repair as necessary and Go to " «VERIFICATION OF VEHICLE REPAIR»(ref-287147-S17745002092008060600000) " procedure.

Scheme 148

Scheme 148: COMPONENT INSPECTION
  1. Connect oil pressure gauge to "2ND" and "OD" and "RED" port.
  2. Engine "ON".
  3. Drive a car with gear position 4 in "SPORTS MODE".
  4. Compare it with reference data as below. Specification: refer to Standard Oil Pressure Table as below OIL PRESSURE SPECIFICATION LEVER POSITION INPUT SPEED VFS CURRENT SOLENOID VALVE DUTY (%) ELEMENT P(MPa) LR DCC 2ND UD OD RED (1) D 2500rpm 200mA 0 0 100 0 100 0 LR 1.03±0.02 ↑ ↑ ↑ 60 ↑ ↑ ↑ ↑ ↑ 0.45±0.04 ↑ ↑ ↑ 75 ↑ ↑ ↑ ↑ ↑ 0.19±0.04 ↑ ↑ ↑ 100 ↑ ↑ ↑ ↑ ↑ 0 ↑ ↑ ↑ 100 ↑ 0 0 100 0 2ND 1.03±0.02 ↑ ↑ ↑ ↑ ↑ 60 ↑ ↑ ↑ 0.50±0.05 ↑ ↑ ↑ ↑ ↑ 75 ↑ ↑ ↑ 0.20±0.05 ↑ ↑ ↑ ↑ ↑ 100 ↑ ↑ ↑ 0 ↑ ↑ ↑ 100 ↑ 100 0 0 0 OD 1.02±0.02 ↑ ↑ ↑ ↑ ↑ ↑ ↑ 60 ↑ 0.46±0.04 ↑ ↑ ↑ ↑ ↑ ↑ ↑ 75 ↑ 0.19±0.04 ↑ ↑ ↑ ↑ ↑ ↑ ↑ 100 ↑ 0 ↑ ↑ ↑ 100 ↑ 100 0 0 0 UD 1.03±0.02 ↑ ↑ ↑ ↑ ↑ ↑ 60 ↑ ↑ 0.44±0.05 ↑ ↑ ↑ ↑ ↑ ↑ 75 ↑ ↑ 0.18±0.04 ↑ ↑ ↑ ↑ ↑ ↑ 100 ↑ ↑ 0 ↑ ↑ ↑ 100 ↑ 0 100 0 0 RED (1) 1.03±0.02 ↑ ↑ ↑ ↑ ↑ ↑ ↑ ↑ 60 0.49±0.04 ↑ ↑ ↑ ↑ ↑ ↑ ↑ ↑ 75 0.24±0.04 ↑ ↑ ↑ ↑ ↑ ↑ ↑ ↑ 100 0 ↑ ↑ ↑ 100 ↑ 0 100 0 100 DIR (1) 0 ↑ ↑ ↑ 75 ↑ ↑ ↑ ↑ ↑ 0.25±0.04 ↑ ↑ ↑ 60 ↑ ↑ ↑ ↑ ↑ 0.51±0.04 ↑ ↑ ↑ 0 ↑ ↑ ↑ ↑ ↑ 1.03±0.02 R ↑ 250mA 0 ↑ 100 100 100 0 LR 1.55±025 (1) The values are subject to change according to vehicle model or condition.
  5. Is oil pressure value within specifications? YES Repair AUTO TRANSAXLE (Clutch or Brake) as necessary and Go to " «VERIFICATION OF VEHICLE REPAIR»(ref-287147-S17745002092008060600000) " procedure. NO Replace AUTO TRANSAXLE (BODY CONTROL VALVE faulty) as necessary and Go to " «VERIFICATION OF VEHICLE REPAIR»(ref-287147-S17745002092008060600000) " procedure.

Refer to DTC P0731 .

Scheme 149

Scheme 149: COMPONENT LOCATION

* It is difficult to "STALL TEST" in 5th gear, so that Go to " SIGNAL CIRCUIT INSPECTION " procedure

GEAR POSITIONELEMENT
L/R BRAKE2ND BRAKEU/D CLUTCHO/D CLUTCHRED BRAKEDIR CLUTCHREV CLUTCHOWC1OWC2
1stOOO
2ndOOO
3rdOOO
4thOOO
5thOOO
REVOOO
N, POO

OPERATING ELEMENT OF EACH SHIFTING RANGE

Low & Reverse Brake is released When the vehicle speed over the 5 MPH (7 km/h)

Scheme 150

Scheme 150: SIGNAL CIRCUIT INSPECTION
  1. Connect Scan tool.
  2. Engine "ON".
  3. Monitor the "INPUT & OUTPUT SPEED SENSOR" parameter on the scan tool.
  4. Accelerate the Engine speed until about 2000 RPM in the 5th gear. Specification: INPUT SPEED - (OUTPUT SPEED x GEAR RATIO) < or = 200 RPM
  5. Does "INPUT & OUTPUT SPEED SENSOR" follow the reference data? YES Go to " «COMPONENT INSPECTION»(ref-287147-S20862914562008060600000) " procedure. NO Check for electrical noise of circuit in INPUT & OUTPUT SPEED SENSOR or Replace INPUT & OUTPUT SPEED SENSOR. Repair as necessary and Go to " «VERIFICATION OF VEHICLE REPAIR»(ref-287147-S27665667522008060600000) " procedure.

Scheme 151

Scheme 151: COMPONENT INSPECTION
  1. Connect oil pressure gauge to "OD" and "2nd" and "DIR" port.
  2. Engine "ON".
  3. Drive a car with gear position "5".
  4. Compare it with reference data as below. Specification: refer to Standard Oil Pressure Table as below OIL PRESSURE SPECIFICATION LEVER POSITION INPUT SPEED VFS CURRENT SOLENOID VALVE DUTY (%) ELEMENT P(MPa) LR DCC 2ND UD OD RED (1) D 2500rpm 200mA 0 0 100 0 100 0 LR 1.03±0.02 ↑ ↑ ↑ 60 ↑ ↑ ↑ ↑ ↑ 0.45±0.04 ↑ ↑ ↑ 75 ↑ ↑ ↑ ↑ ↑ 0.19±0.04 ↑ ↑ ↑ 100 ↑ ↑ ↑ ↑ ↑ 0 ↑ ↑ ↑ 100 ↑ 0 0 100 0 2ND 1.03±0.02 ↑ ↑ ↑ ↑ ↑ 60 ↑ ↑ ↑ 0.50±0.05 ↑ ↑ ↑ ↑ ↑ 75 ↑ ↑ ↑ 0.20±0.05 ↑ ↑ ↑ ↑ ↑ 100 ↑ ↑ ↑ 0 ↑ ↑ ↑ 100 ↑ 100 0 0 0 OD 1.02±0.02 ↑ ↑ ↑ ↑ ↑ ↑ ↑ 60 ↑ 0.46±0.04 ↑ ↑ ↑ ↑ ↑ ↑ ↑ 75 ↑ 0.19±0.04 ↑ ↑ ↑ ↑ ↑ ↑ ↑ 100 ↑ 0 ↑ ↑ ↑ 100 ↑ 100 0 0 0 UD 1.03±0.02 ↑ ↑ ↑ ↑ ↑ ↑ 60 ↑ ↑ 0.44±0.05 ↑ ↑ ↑ ↑ ↑ ↑ 75 ↑ ↑ 0.18±0.04 ↑ ↑ ↑ ↑ ↑ ↑ 100 ↑ ↑ 0 ↑ ↑ ↑ 100 ↑ 0 100 0 0 RED (1) 1.03±0.02 ↑ ↑ ↑ ↑ ↑ ↑ ↑ ↑ 60 0.49±0.04 ↑ ↑ ↑ ↑ ↑ ↑ ↑ ↑ 75 0.24±0.04 ↑ ↑ ↑ ↑ ↑ ↑ ↑ ↑ 100 0 ↑ ↑ ↑ 100 ↑ 0 100 0 100 DIR (1) 0 ↑ ↑ ↑ 75 ↑ ↑ ↑ ↑ ↑ 0.25±0.04 ↑ ↑ ↑ 60 ↑ ↑ ↑ ↑ ↑ 0.51±0.04 ↑ ↑ ↑ 0 ↑ ↑ ↑ ↑ ↑ 1.03±0.02 R ↑ 250mA 0 ↑ 100 100 100 0 LR 1.55±0.25 (1) The values are subject to change according to vehicle model or condition.
  5. Is oil pressure value within specification? YES Repair AUTO TRANSAXLE (Clutch or Brake) as necessary and Go to " «VERIFICATION OF VEHICLE REPAIR»(ref-287147-S27665667522008060600000) " procedure. NO Replace AUTO TRANSAXLE (BODY CONTROL VALVE faulty) as necessary and Go to " «VERIFICATION OF VEHICLE REPAIR»(ref-287147-S27665667522008060600000) " procedure.

Refer to DTC P0731 .

After a repair, it is essential to verify that the fault has been corrected.

  1. Connect scantool and select "Diagnostic Trouble Codes (DTCs)" mode.
  2. Using a scantool, Clear DTC.
  3. Operate the vehicle within DTC Enable conditions in General information.
  4. Are any DTCs present? YES Go to the applicable troubleshooting procedure. NO System performing to specification at this time.

Refer to DTC P0741 .

Scheme 152

Scheme 152: COMPONENT LOCATION

Refer to DTC P0741 .

Scheme 153

Scheme 153: COMPONENT LOCATION

Refer to DTC P0741 .

Scheme 154

Scheme 154: COMPONENT LOCATION

After a repair, it is essential to verify that the fault has been corrected.

  1. Connect scantool and select "Diagnostic Trouble Codes (DTCs)" mode.
  2. Using a scantool, Clear DTC.
  3. Operate the vehicle within DTC Enable conditions in General information.
  4. Are any DTCs present? YES Go to the applicable troubleshooting procedure. NO System performing to specification at this time.

Scheme 155

Scheme 155: COMPONENT LOCATION

Refer to DTC P0750 .

Scheme 156

Scheme 156: COMPONENT LOCATION

Refer to DTC P0750 .

Scheme 157

Scheme 157: COMPONENT LOCATION

Refer to DTC P0750 .

Scheme 158

Scheme 158: COMPONENT LOCATION

Refer to DTC P0750 .

Scheme 159

Scheme 159: COMPONENT LOCATION

After a repair, it is essential to verify that the fault has been corrected.

  1. Connect scantool and select "Diagnostic Trouble Codes (DTCs)" mode.
  2. Using a scantool, Clear DTC.
  3. Operate the vehicle within DTC Enable conditions in General information.
  4. Are any DTCs present? YES Go to the applicable troubleshooting procedure. NO System performing to specification at this time.

Refer to DTC P0885 .

Refer to DTC P0885 .

Refer to DTC P0885 .

Refer to DTC P0885 .

Scheme 160

Scheme 160: COMPONENTS

Scheme 161

Scheme 161
