DTC P1298: ELD Circuit High Voltage Honda Element YH2 рестайлинг 2

Note. Before you troubleshoot, record all freeze data and any on-board snapshot, and review the general troubleshooting information (see GENERAL TROUBLESHOOTING INFORMATION ).

Scheme 490

Scheme 491

Scheme 492

Scheme 493

1. Start the engine, and let it idle.
2. Check the ELD in the DATA LIST with the HDS. Is 0.2 A or less indicated? YES -Go to step 3. NO -Intermittent failure, the system is OK at this time. Check for poor connections or loose terminals at the ELD and the ECM/PCM.
3. Turn the ignition switch to LOCK (0).
4. Disconnect the ELD 3P connector.
5. Turn the ignition switch to ON (II).
6. Measure the voltage between ELD 3P connector terminal No. 1 and body ground. Is there battery voltage? YES -Go to step 7. NO -Check the No. 4 ACG (10 A) fuse in the under-dash fuse/relay box. If the fuse is OK, repair open in the wire between the No. 4 ACG (10 A) fuse and the ELD, then go to step 14 .
7. Turn the ignition switch to LOCK (0).
8. Connect ELD 3P connector terminal No. 3 to body ground with a jumper wire.
9. Jump the SCS line with the HDS.
10. Disconnect ECM/PCM connector E (31P).
11. Check for continuity between ECM/PCM connector terminal E15 and body ground. Is there continuity? YES -Go to step 12. NO -Repair open in the wire between the ECM/PCM (E15) and the ELD, then go to step 14 .
12. Check for continuity between ELD 3P connector terminal No. 2 and body ground. Is there continuity? YES -Go to step 13. NO -Repair open in the wire between the ELD and G301, then go to step 14 .
13. Replace the ELD (see «ELD REPLACEMENT»(ref-355245-S34563935892010012100000) ).
14. Reconnect all connectors.
15. Turn the ignition switch to ON (II).
16. Reset the ECM/PCM with the HDS.
17. Do the ECM/PCM idle learn procedure (see «ECM/PCM IDLE LEARN PROCEDURE»(ref-290807-S02808252682008072200000) ).
18. Check for Temporary DTCs or DTCs with the HDS. Is DTC P1298 indicated? YES -Go to step 19. NO -Troubleshooting is complete. If any other Temporary DTCs or DTCs are indicated, go to the indicated DTCs troubleshooting.
19. Update the ECM/PCM if it does not have the latest software (see «ECM/PCM UPDATE»(ref-355245-S27182940282010012100000) ), or substitute a known-good ECM/PCM (see «SUBSTITUTING THE ECM/PCM»(ref-290833-S34742010492008072200000) ).
20. Check for Temporary DTCs or DTCs with the HDS. Is DTC P1298 indicated? YES -Check for poor connections or loose terminals at the ELD and the ECM/PCM. If the ECM/PCM was updated, substitute a known-good ECM/PCM (see «SUBSTITUTING THE ECM/PCM»(ref-290833-S34742010492008072200000) ), then recheck. If the ECM/PCM was substituted, go to step 1 . NO -If the ECM/PCM was updated, troubleshooting is complete. If the ECM/PCM was substituted, replace the original ECM/PCM (see «ECM/PCM REPLACEMENT»(ref-355245-S09328189752010012100000) ). If any other Temporary DTCs or DTCs are indicated, go to the indicated DTCs troubleshooting.
