DTC P0113: IAT Sensor Circuit High Voltage Honda Element YH2 рестайлинг 2

Testing & Diagnostics 5 illustrations ~573 words

Note. Before you troubleshoot, record all freeze data and any on-board snapshot, and review the general troubleshooting information (see GENERAL TROUBLESHOOTING INFORMATION ).

Scheme 375

Scheme 375: DTC P0113: IAT Sensor Circuit High Voltage

Scheme 376

Scheme 376

Scheme 377

Scheme 377

Scheme 378

Scheme 378

Scheme 379

Scheme 379
  1. Turn the ignition switch to ON (II).
  2. Check the IAT SENSOR in the DATA LIST with the HDS. Is about -40°F (-40°C) or less, or 4.90 V or more indicated? YES -Go to step 3. NO -Intermittent failure, the system is OK at this time. Check for poor connections or loose terminals at the MAF sensor/IAT sensor and the ECM/PCM.
  3. Turn the ignition switch to LOCK (0).
  4. Disconnect the MAF sensor/IAT sensor 5P connector.
  5. Connect MAF sensor/IAT sensor 5P connector terminals No. 4 and No. 5 with a jumper wire.
  6. Turn the ignition switch to ON (II).
  7. Check the IAT SENSOR in the DATA LIST with the HDS. Is about -40°F (-40°C) or less, or 4.90 V or more indicated? YES -Go to step 8. NO -Go to step 18 .
  8. Turn the ignition switch to LOCK (0).
  9. Remove the jumper wire from the MAF sensor/IAT sensor 5P connector.
  10. Turn the ignition switch to ON (II).
  11. Measure the voltage between MAF sensor/IAT sensor 5P connector terminal No. 5 and body ground. Is there about 5 V? YES -Go to step 12. NO -Go to step 17 .
  12. Turn the ignition switch to LOCK (0).
  13. Jump the SCS line with the HDS.
  14. Disconnect ECM/PCM connector A (31P).
  15. Connect MAF sensor/IAT sensor 5P connector terminal No. 4 to body ground with a jumper wire.
  16. Check for continuity between ECM/PCM connector terminal A23 and body ground. Is there continuity? YES -Go to step 26 . NO -Repair open in the wire between the ECM/PCM (A23) and the MAF sensor/IAT sensor, then go to step 20 .
  17. Measure the voltage between ECM/PCM connector terminal B17 and body ground. Is there about 5 V? YES -Repair open in the wire between the ECM/PCM (B17) and the MAF sensor/IAT sensor, then go to step 20 . NO -Go to step 25 .
  18. Turn the ignition switch to LOCK (0).
  19. Replace the MAF sensor/IAT sensor (see «MAF SENSOR/IAT SENSOR REPLACEMENT»(ref-355245-S33598592802010012100000) ).
  20. Reconnect all connectors.
  21. Turn the ignition switch to ON (II).
  22. Reset the ECM/PCM with the HDS.
  23. Do the ECM/PCM idle learn procedure (see «ECM/PCM IDLE LEARN PROCEDURE»(ref-290807-S02808252682008072200000) ).
  24. Check for Temporary DTCs or DTCs with the HDS. Is DTC P0113 indicated? YES -Check for poor connections or loose terminals at the MAF sensor/IAT sensor and the ECM/PCM, then go to step 1 . NO -Troubleshooting is complete. If any other Temporary DTCs or DTCs are indicated, go to the indicated DTCs troubleshooting.
  25. Turn the ignition switch to LOCK (0).
  26. Reconnect all connectors.
  27. Update the ECM/PCM if it does not have the latest software (see «ECM/PCM UPDATE»(ref-355245-S27182940282010012100000) ), or substitute a known-good ECM/PCM (see «SUBSTITUTING THE ECM/PCM»(ref-290833-S34742010492008072200000) ).
  28. Check for Temporary DTCs or DTCs with the HDS. Is DTC P0113 indicated? YES -Check for poor connections or loose terminals at the MAF sensor/IAT sensor and the ECM/PCM. If the ECM/PCM was updated, substitute a known-good ECM/PCM (see «SUBSTITUTING THE ECM/PCM»(ref-290833-S34742010492008072200000) ), then recheck. If the ECM/PCM was substituted, go to step 1 . NO -If the ECM/PCM was updated, troubleshooting is complete. If the ECM/PCM was substituted, replace the original ECM/PCM (see «ECM/PCM REPLACEMENT»(ref-355245-S09328189752010012100000) ). If any other Temporary DTCs or DTCs are indicated, go to the indicated DTCs troubleshooting.
