Vtec/vtc: Overview Honda CR-V II рестайлинг

Testing & Diagnostics 12 illustrations ~1683 words

Scheme 226

Scheme 226: Component Location Index
Scheme 226: Component Location Index

Scheme 227

Scheme 227: DTC P0010: VTC Oil Control Solenoid Valve Malfunction
Scheme 227: DTC P0010: VTC Oil Control Solenoid Valve Malfunction

Scheme 228

Scheme 228
Scheme 228

Scheme 229

Scheme 229
Scheme 229

Scheme 230

Scheme 230
Scheme 230

Scheme 231

Scheme 231
Scheme 231
  1. Turn the ignition switch ON (II).
  2. Clear the DTC with the HDS.
  3. Start the engine. Hold the engine speed at 3,000 RPM without load (in Park or neutral) until the radiator fan comes on, then let it idle.
  4. Do the VTC TEST in the INSPECTION MENU with the HDS.
  5. Check for Temporary DTCs or DTCs with the HDS. Is DTC P0010 indicated? YES - Go to step 6. NO - Intermittent failure, system is OK at this time. Check for poor connections or loose terminals at the VTC oil control solenoid valve and the ECM/PCM.
  6. Turn the ignition switch OFF.
  7. Disconnect the VTC oil control solenoid valve 2P connector.
  8. Measure resistance between VTC oil control solenoid valve 2P connector terminals No. 1 and No. 2. Is there 6.75-8.25 ohms at room temperature? YES - Go to step 9. NO - Go to step 15 .
  9. Check for continuity between VTC oil control solenoid valve 2P connector terminal No. 1 and body ground. Is there continuity? YES - Go to step 10. NO - Repair open in the wire between the VTC oil control solenoid valve and G101, then go to step 16 .
  10. Jump the SCS line with the HDS.
  11. Disconnect ECM/PCM connector B (24P).
  12. Check for continuity between ECM/PCM connector terminal B1 and body ground. Is there continuity? YES - Repair short in the wire between the ECM/PCM (B1) and the VTC oil control solenoid valve, then go to step 16 . NO - Go to step 13.
  13. Connect VTC oil control solenoid valve 2P connector terminal No. 2 to body ground with a jumper wire.
  14. Check for continuity between ECM/PCM connector terminal B1 and body ground. Is there continuity? YES - Go to step 23 . NO - Repair open in the wire between the ECM/PCM (B1) and the VTC oil control solenoid valve, then go to step 16 .
  15. Replace the VTC oil control solenoid valve (see «VTC OIL CONTROL SOLENOID VALVE REMOVAL/TEST/INSTALLATION»(ref-219373-S03001614932006021400000) ).
  16. Reconnect all connectors.
  17. Turn the ignition switch ON (II).
  18. Reset the ECM/PCM with the HDS.
  19. Do the ECM/PCM idle learn procedure (see «ECM/PCM IDLE LEARN PROCEDURE»(ref-219374-S42320443812006021400000) ).
  20. Do the VTC TEST in the INSPECTION MENU with the HDS.
  21. Check for Temporary DTCs or DTCs with the HDS. Are any Temporary DTCs or DTCs indicated? YES - If DTC P0010 is indicated, check for poor connections or loose terminals at the VTC oil control solenoid valve and the ECM/PCM, then go to step 1 . If any other Temporary DTCs or DTCs are indicated, go to the indicated DTC's troubleshooting . NO - Go to step 22.
  22. Monitor the OBD STATUS for DTC P0010 in the DTCs MENU with the HDS. Does the screen indicate PASSED? YES - Troubleshooting is complete. NO - If the screen indicates FAILED, go to step 1 . and recheck. If the screen indicates NOT COMPLETED, go to step 20 . and recheck.
  23. Update the ECM/PCM if it does not have the latest software, or substitute a known-good ECM/PCM (see «ECM/PCM UPDATING AND SUBSTITUTION FOR TESTING»(ref-219370-S15199960282006021400000) ).
  24. Do the VTC TEST in the INSPECTION MENU with the HDS.
  25. Check for Temporary DTCs or DTCs with the HDS. Are any Temporary DTCs or DTCs indicated? YES - If DTC P0010 is indicated, check for poor connections or loose terminals at the VTC oil control solenoid valve and the ECM/PCM, then go to step 1 . If any other Temporary DTCs or DTCs are indicated, go to the indicated DTC's troubleshooting. NO - If the ECM/PCM was updated, troubleshooting is complete. If the ECM/PCM was substituted, replace the original ECM/PCM (see «ECM/PCM REPLACEMENT»(ref-219371-S37179676622006021400000) ).

Scheme 232

Scheme 232: DTC P0011: VTC System Malfunction
Scheme 232: DTC P0011: VTC System Malfunction
  1. Turn the ignition switch ON (II).
  2. Clear the DTC with the HDS.
  3. Start the engine.
  4. Watch the low oil pressure indicator with the engine running. Is the low oil pressure Indicator on? YES - Check the oil pressure (see «OIL PRESSURE TEST»(ref-219366-S32779369672006021400000) ), make any needed repairs, then go to step 15 . NO - Go to step 5.
  5. Do the VTC TEST in the INSPECTION MENU with the HDS. Is the result OK? YES - Go to step 6. NO - Go to step 9 .
  6. Test-drive at a steady speed between 19-38 mph (30-60 km/h) for 10 minutes.
  7. Check the VTC STATUS in the DATA LIST with the HDS. Does it indicate ON? YES - Go to step 8. NO - Go to step 6 . and recheck.
  8. Monitor the OBD STATUS for DTC P0011 in the DTCs MENU with the HDS. Does the screen indicate FAILED? YES - Go to step 9. NO - If the screen indicates PASSED, intermittent failure, system is OK at this time. Check for poor connections or loose terminals at the VTC oil control solenoid valve and the ECM/PCM. If the screen indicates NOT COMPLETED, go to step 5 . and recheck.
  9. Turn the ignition switch OFF.
  10. Remove the auto-tensioner (see «DRIVE BELT REPLACEMENT»(ref-219361-S01895169962006021400000) ).
  11. Remove the VTC strainer (A), and check it for clogging. Is the strainer OK? YES - Go to step 12. NO - Clean the VTC strainer, replace the engine oil filter and the engine oil, then go to step 14 .
  12. Test the VTC oil control solenoid valve (see «VTC OIL CONTROL SOLENOID VALVE REMOVAL/TEST/INSTALLATION»(ref-219373-S03001614932006021400000) ). Is the VTC oil control solenoid valve OK? YES - Go to step 13. NO - Replace the VTC oil control solenoid valve (see «VTC OIL CONTROL SOLENOID VALVE REMOVAL/TEST/INSTALLATION»(ref-219373-S03001614932006021400000) ), then go to step 14 .
  13. Inspect the VTC actuator (see «VTC ACTUATOR INSPECTION»(ref-219364-S37148837872006021400000) ). Is the VTC actuator OK? YES - Go to step 14. NO - Replace the VTC actuator (see «VTC ACTUATOR, EXHAUST CAMSHAFT SPROCKET REMOVE»(ref-219364-S22834485982006021400000) ), then go to step 14.
  14. Turn the ignition switch ON (II).
  15. Reset the ECM/PCM with the HDS.
  16. Clear the CKP pattern with the HDS.
  17. Do the ECM/PCM idle learn procedure (see «ECM/PCM IDLE LEARN PROCEDURE»(ref-219374-S42320443812006021400000) ).
  18. Do the CKP pattern learn procedure (see «CKP PATTERN CLEAR/CKP PATTERN LEARN»(ref-219370-S22235184282006021400000) ).
  19. Do the VTC TEST in the INSPECTION MENU with the HDS.
  20. Check for Temporary DTCs or DTCs with the HDS. Are any Temporary DTCs or DTCs indicated? YES - If DTC P0011 is indicated, check for poor connections or loose terminals at the VTC oil control solenoid valve and the ECM/PCM, then go to step 1 . If any other Temporary DTCs or DTCs are indicated, go to the indicated DTC's troubleshooting. NO - Go to step 21.
  21. Monitor the OBD STATUS for DTC P0011 in the DTCs MENU with the HDS. Does the screen indicate PASSED? YES - Troubleshooting is complete. NO - If the screen indicates FAILED, check for poor connections or loose terminals at the VTC oil control solenoid valve and the ECM/PCM, then go to step 1 . If the screen indicates NOT COMPLETED, go to step 19 . and recheck.

Scheme 233

Scheme 233: DTC P0340: CMP Sensor A No Signal
Scheme 233: DTC P0340: CMP Sensor A No Signal

Scheme 234

Scheme 234
Scheme 234

Scheme 235

Scheme 235
Scheme 235

Scheme 236

Scheme 236
Scheme 236

Scheme 237

Scheme 237
Scheme 237
  1. Turn the ignition switch ON (II).
  2. Clear the DTC with the HDS.
  3. Start the engine.
  4. Check for Temporary DTCs or DTCs with the HDS. Is DTC P0340 indicated? YES - Go to step 5. NO - Intermittent failure, system is OK at this time. Check for poor connections or loose terminals at CMP sensor A and the ECM/PCM.
  5. Turn the ignition switch OFF.
  6. Disconnect the CMP sensor A 3P connector.
  7. Turn the ignition switch ON (II).
  8. Measure voltage between CMP sensor A 3P connector terminal No. 3 and body ground. Is there battery voltage? YES - Go to step 9. NO - Repair open in the wire between the No. 4 ACG (10 A) fuse in the under-dash fuse/relay box and CMP sensor A, then go to step 18 .
  9. Measure voltage between CMP sensor A 3P connector terminal No. 1 and body ground. Is there about 5 V? YES - Go to step 10. NO - Go to step 11 .
  10. Measure voltage between CMP sensor A 3P connector terminals No. 2 and No. 3. Is there battery voltage? YES - Go to step 16 . NO - Repair open in the wire between CMP sensor A and G101, then go to step 18 .
  11. Measure voltage between ECM/PCM connector terminal A19 and body ground. Is there about 5 V? YES - Repair open in the wire between the ECM/PCM (A19) and CMP sensor A, then go to step 18 . NO - Go to step 12.
  12. Turn the ignition switch OFF.
  13. Jump the SCS line with the HDS.
  14. Disconnect ECM/PCM connector A (31P).
  15. Check for continuity between ECM/PCM connector terminal A19 and body ground. Is there continuity? YES - Repair short in the wire between the ECM/PCM (A19) and CMP sensor A, then go to step 18 . NO - Go to step 24 .
  16. Turn the ignition switch OFF.
  17. Replace CMP sensor A (see «CMP SENSOR A REPLACEMENT»(ref-219373-S13788806462006021400000) ).
  18. Reconnect all connectors.
  19. Turn the ignition switch ON (II).
  20. Reset the ECM/PCM with the HDS.
  21. Do the ECM/PCM idle learn procedure (see «ECM/PCM IDLE LEARN PROCEDURE»(ref-219374-S42320443812006021400000) ).
  22. Start the engine.
  23. Check for Temporary DTCs or DTCs with the HDS. Are any Temporary DTCs or DTCs indicated? YES - If DTC P0340 is indicated, check for poor connections or loose terminals at CMP sensor A and the ECM/PCM, then go to step 1 . If any other Temporary DTCs or DTCs are indicated, go to the indicated DTC's troubleshooting. NO - Troubleshooting is complete.
  24. Update the ECM/PCM if it does not have the latest software, or substitute a known-good ECM/PCM (see «ECM/PCM UPDATING AND SUBSTITUTION FOR TESTING»(ref-219370-S15199960282006021400000) ).
  25. Check for Temporary DTCs or DTCs with the HDS. Are any Temporary DTCs or DTCs indicated? YES - If DTC P0340 is indicated, check for poor connections or loose terminals at CMP sensor A and the ECM/PCM, then go to step 1 . If any other Temporary DTCs or DTCs are indicated, go to the indicated DTC's troubleshooting. NO - If the ECM/PCM was updated, troubleshooting is complete. If the ECM/PCM was substituted, replace the original ECM/PCM (see «ECM/PCM REPLACEMENT»(ref-219371-S37179676622006021400000) ).
