Electronic Throttle Control System: Diagnosis Honda CR-V II рестайлинг

Testing & Diagnostics 21 illustrations ~2252 words

DTC Troubleshooting

DTCDescription
DTC P0122TP Sensor A Circuit Low Voltage
DTC P0123TP Sensor A Circuit High Voltage
DTC P0222TP Sensor B Circuit Low Voltage
DTC P0223TP Sensor B Circuit High Voltage
DTC P1683Throttle Valve Default Position Spring Performance Problem
DTC P1684Throttle Valve Return Spring Performance Problem
DTC P2101Throttle Actuator System Malfunction
DTC P2108Throttle Actuator Control Module Problem
DTC P2118Throttle Actuator Current Range/Performance Problem
DTC P2122APP Sensor A (Throttle Position Sensor D) Circuit Low Voltage
DTC P2123APP Sensor A (Throttle Position Sensor D) Circuit High Voltage
DTC P2127APP Sensor B (Throttle Position Sensor E) Circuit Low Voltage
DTC P2128APP Sensor B (Throttle Position Sensor E) Circuit High Voltage
DTC P2135TP Sensor A/B Voltage Incorrect Correlation
DTC P2138APP Sensor A/B (Throttle Position Sensor D/E) Incorrect Voltage Correlation
DTC P2176Throttle Actuator Control System Idle Position Not Learned
DTC P2552Throttle Actuator Control Module Relay Malfunction
DTC U0107Lost Communication With Throttle Actuator Control Module

DTC INDEX

Scheme 159

Scheme 159: DTC P0122: TP Sensor A Circuit Low Voltage
Scheme 159: DTC P0122: TP Sensor A Circuit Low Voltage

Scheme 160

Scheme 160
Scheme 160

Scheme 161

Scheme 161
Scheme 161

Scheme 162

Scheme 162
Scheme 162
  1. Turn the ignition switch ON (II).
  2. Clear the DTC with the HDS.
  3. Check TP SENSOR A in the DATA LIST with the HDS. Is there about 0.3 V or less? YES - Go to step 4. NO - Intermittent failure, system is OK at this time. Check for poor connections or loose terminals at the throttle body and the throttle actuator control module.
  4. Check for Temporary DTCs or DTCs with the HDS. Are DTC P0122 and P0222 indicated at the same time? YES - Go to step 9 . NO - Go to step 5.
  5. Turn the ignition switch OFF.
  6. Disconnect the throttle body 6P connector.
  7. Disconnect the throttle actuator control module 16P connector.
  8. Check for continuity between throttle body 6P connector terminal No. 1 and body ground. Is there continuity? YES - Repair short in the wire between the throttle body and the throttle actuator control module (TPSA line), then go to step 17 . NO - Substitute a known-good throttle actuator control module (see «THROTTLE ACTUATOR CONTROL MODULE REPLACEMENT»(ref-219372-S15416086612006021400000) ), then go to step 17 . If DTC P0122 is indicated, go to step 15 .
  9. Measure voltage between throttle body 6P connector terminal No. 2 and body ground. Is there about 5 V? YES - Go to step 15 . NO - Go to step 10.
  10. Turn the ignition switch OFF.
  11. Disconnect the throttle actuator control module 16P connector (see «THROTTLE ACTUATOR CONTROL MODULE REPLACEMENT»(ref-219372-S15416086612006021400000) ).
  12. Disconnect the throttle body 6P connector.
  13. Connect throttle body 6P connector terminal No. 2 to body ground with a jumper wire.
  14. Check for continuity between throttle actuator control module 16P connector terminal No. 11 and body ground. Is there continuity? YES - Substitute a known-good throttle actuator control module (see «THROTTLE ACTUATOR CONTROL MODULE REPLACEMENT»(ref-219372-S15416086612006021400000) ), then go to step 17 . If DTC P0122 is indicated, go to step 15. NO - Repair open in the wire between the throttle body and the throttle actuator control module (VCC line), then go to step 17 .
  15. Turn the ignition switch OFF.
  16. Replace the throttle body (see «THROTTLE BODY REMOVAL/INSTALLATION»(ref-219376-S30644524212006021400000) ).
  17. Reconnect all connectors.
  18. Turn the ignition switch ON (II).
  19. Reset the ECM/PCM with the HDS.
  20. Do the ECM/PCM idle learn procedure (see «ECM/PCM IDLE LEARN PROCEDURE»(ref-219374-S42320443812006021400000) ).
  21. Check for Temporary DTCs or DTCs with the HDS. Are any Temporary DTCs or DTCs indicated? YES - If DTC P0122 is indicated, check for poor connections or loose terminals at the throttle body and the throttle actuator control module, then go to step 1 . If any other Temporary DTCs or DTCs are indicated, go to the indicated DTC's troubleshooting. NO - Troubleshooting is complete.

Scheme 163

Scheme 163: DTC P0123: TP Sensor A Circuit High Voltage
Scheme 163: DTC P0123: TP Sensor A Circuit High Voltage

Scheme 164

Scheme 164
Scheme 164

Scheme 165

Scheme 165
Scheme 165

Scheme 166

Scheme 166
Scheme 166

Scheme 167

Scheme 167
Scheme 167
  1. Turn the ignition switch ON (II).
  2. Clear the DTC with the HDS.
  3. Check TP SENSOR A in the DATA LIST with the HDS. Is there about 4.8 V or more? YES - Go to step 4. NO - Intermittent failure, system is OK at this time. Check for poor connections or loose terminals at the throttle body and the throttle actuator control module.
  4. Check for Temporary DTCs or DTCs with the HDS. Are DTC P0123 and P0223 indicated at the same time? YES - Go to step 11 . NO - Go to step 5.
  5. Measure voltage between throttle body 6P connector terminal No. 1 and body ground. Is there about 5 V? YES - Go to step 16 . NO - Go to step 6.
  6. Turn the ignition switch OFF.
  7. Disconnect the throttle actuator control module 16P connector (see «THROTTLE ACTUATOR CONTROL MODULE REPLACEMENT»(ref-219372-S15416086612006021400000) ).
  8. Disconnect the throttle body 6P connector.
  9. Connect throttle body 6P connector terminal No. 1 to body ground with a jumper wire.
  10. Check for continuity between throttle actuator control module 16P connector terminal No. 10 and body ground. Is there continuity? YES - Substitute a known-good throttle actuator control module (see «THROTTLE ACTUATOR CONTROL MODULE REPLACEMENT»(ref-219372-S15416086612006021400000) ), then go to step 18 . If DTC P0123 is indicated, go to step 16 . NO - Repair open in the wire between the throttle body and the throttle actuator control module (TPSA line), then go to step 18 .
  11. Turn the ignition switch OFF.
  12. Disconnect the throttle body 6P connector.
  13. Disconnect the throttle actuator control module 16P connector (see «THROTTLE ACTUATOR CONTROL MODULE REPLACEMENT»(ref-219372-S15416086612006021400000) ).
  14. Connect throttle body 6P connector terminal No. 4 to body ground with a jumper wire.
  15. Check for continuity between throttle actuator control module 16P connector terminal No. 9 and body ground. Is there continuity? YES - Substitute a known-good throttle actuator control module (see «THROTTLE ACTUATOR CONTROL MODULE REPLACEMENT»(ref-219372-S15416086612006021400000) ), then go to step 18 . If DTC P0123 is indicated, go to step 16. NO - Repair open in the wire between the throttle body and the throttle actuator control module (SG line), then go to step 18 .
  16. Turn the ignition switch OFF.
  17. Replace the throttle body (see «THROTTLE BODY REMOVAL/INSTALLATION»(ref-219376-S30644524212006021400000) ).
  18. Reconnect all connectors.
  19. Turn the ignition switch ON (II).
  20. Reset the ECM/PCM with the HDS.
  21. Do the ECM/PCM idle learn procedure (see «ECM/PCM IDLE LEARN PROCEDURE»(ref-219374-S42320443812006021400000) ).
  22. Check for Temporary DTCs or DTCs with the HDS. Are any Temporary DTCs or DTCs indicated? YES - If DTC P0123 is indicated, check for poor connections or loose terminals at the throttle body and the throttle actuator control module, then go to step 1 . If any other Temporary DTCs or DTCs are indicated, go to the indicated DTC's troubleshooting. NO - Troubleshooting is complete.

Scheme 168

Scheme 168: DTC P0222: TP Sensor B Circuit Low Voltage
Scheme 168: DTC P0222: TP Sensor B Circuit Low Voltage

Scheme 169

Scheme 169
Scheme 169

Scheme 170

Scheme 170
Scheme 170

Scheme 171

Scheme 171
Scheme 171
  1. Turn the ignition switch ON (II).
  2. Clear the DTC with the HDS.
  3. Check TP SENSOR B in the DATA LIST with the HDS. Is there about 0.3 V or less? YES - Go to step 4. NO - Intermittent failure, system is OK at this time. Check for poor connections or loose terminals at the throttle body and the throttle actuator control module.
  4. Check for Temporary DTCs or DTCs with the HDS. Are DTC P0122 and P0222 indicated at the same time? YES - Go to step 9 . NO - Go to step 5.
  5. Turn the ignition switch OFF.
  6. Disconnect the throttle body 6P connector.
  7. Disconnect the throttle actuator control module 16P connector (see «THROTTLE ACTUATOR CONTROL MODULE REPLACEMENT»(ref-219372-S15416086612006021400000) ).
  8. Check for continuity between throttle body 6P connector terminal No. 3 and body ground. Is there continuity? YES - Repair short in the wire between the throttle body and the throttle actuator control module (TPSB line), then go to step 17 . NO - Substitute a known-good throttle actuator control module (see «THROTTLE ACTUATOR CONTROL MODULE REPLACEMENT»(ref-219372-S15416086612006021400000) ), then go to step 17 . If DTC P0222 is indicated, go to step 15 .
  9. Measure voltage between throttle body 6P connector terminal No. 2 and body ground. Is there about 5 V? YES - Go to step 15 . NO - Go to step 10.
  10. Turn the ignition switch OFF.
  11. Disconnect the throttle actuator control module 16P connector (see «THROTTLE ACTUATOR CONTROL MODULE REPLACEMENT»(ref-219372-S15416086612006021400000) ).
  12. Disconnect the throttle body 6P connector.
  13. Connect throttle body 6P connector terminal No. 2 to body ground with a jumper wire.
  14. Check for continuity between throttle actuator control module 16P connector terminal No. 11 and body ground. Is there continuity? YES - Substitute a known-good throttle actuator control module (see «THROTTLE ACTUATOR CONTROL MODULE REPLACEMENT»(ref-219372-S15416086612006021400000) ), then go to step 17 . If DTC P0222 is indicated, go to step 15. NO - Repair open in the wire between the throttle body and the throttle actuator control module (VCC line), then go to step 17 .
  15. Turn the ignition switch OFF.
  16. Replace the throttle body (see «THROTTLE BODY REMOVAL/INSTALLATION»(ref-219376-S30644524212006021400000) ).
  17. Reconnect all connectors.
  18. Turn the ignition switch ON (II).
  19. Reset the ECM/PCM with the HDS.
  20. Do the ECM/PCM idle learn procedure (see «ECM/PCM IDLE LEARN PROCEDURE»(ref-219374-S42320443812006021400000) ).
  21. Check for Temporary DTCs or DTCs with the HDS. Are any Temporary DTCs or DTCs indicated? YES - If DTC P0222 is indicated, check for poor connections or loose terminals at the throttle body and the throttle actuator control module, then go to step 1 . If any other Temporary DTCs or DTCs are indicated, go to the indicated DTC's troubleshooting. NO - Troubleshooting is complete.

Scheme 172

Scheme 172: DTC P0223: TP Sensor B Circuit High Voltage
Scheme 172: DTC P0223: TP Sensor B Circuit High Voltage

Scheme 173

Scheme 173
Scheme 173

Scheme 174

Scheme 174
Scheme 174

Scheme 175

Scheme 175
Scheme 175

Scheme 176

Scheme 176
Scheme 176
  1. Turn the ignition switch ON (II).
  2. Clear the DTC with the HDS.
  3. Check TP SENSOR B in the DATA LIST with the HDS. Is there about 4.8 V or more? YES - Go to step 4. NO - Intermittent failure, system is OK at this time. Check for poor connections or loose terminals at the throttle body and the throttle actuator control module.
  4. Check for Temporary DTCs or DTCs with the HDS. Are DTC P0123 and P0223 indicated at the same time? YES - Go to step 11 . NO - Go to step 5.
  5. Measure voltage between throttle body 6P connector terminal No. 3 and body ground. Is there about 5 V? YES - Go to step 16 . NO - Go to step 6.
  6. Turn the ignition switch OFF.
  7. Disconnect the throttle actuator control module 16P connector (see «THROTTLE ACTUATOR CONTROL MODULE REPLACEMENT»(ref-219372-S15416086612006021400000) ).
  8. Disconnect the throttle body 6P connector.
  9. Connect throttle body 6P connector terminal No. 3 to body ground with a jumper wire.
  10. Check for continuity between throttle actuator control module 16P connector terminal No. 12 and body ground. Is there continuity? YES - Substitute a known-good throttle actuator control module (see «THROTTLE ACTUATOR CONTROL MODULE REPLACEMENT»(ref-219372-S15416086612006021400000) ), then go to step 18 . If DTC P0223 is indicated, go to step 16 . NO - Repair open in the wire between the throttle body and the throttle actuator control module (TPSB line), then go to step 18 .
  11. Turn the ignition switch OFF.
  12. Disconnect the throttle body 6P connector.
  13. Disconnect the throttle actuator control module 16P connector (see «THROTTLE ACTUATOR CONTROL MODULE REPLACEMENT»(ref-219372-S15416086612006021400000) ).
  14. Connect throttle body 6P connector terminal No. 4 to body ground with a jumper wire.
  15. Check for continuity between throttle actuator control module 16P connector terminal No. 9 and body ground. Is there continuity? YES - Substitute a known-good throttle actuator control module (see «THROTTLE ACTUATOR CONTROL MODULE REPLACEMENT»(ref-219372-S15416086612006021400000) ), then go to step 18 . If DTC P0223 is indicated, go to step 16. NO - Repair open in the wire between the throttle body and the throttle actuator control module (SG line), then go to step 18 .
  16. Turn the ignition switch OFF.
  17. Replace the throttle body (see «THROTTLE BODY REMOVAL/INSTALLATION»(ref-219376-S30644524212006021400000) ).
  18. Reconnect all connectors.
  19. Turn the ignition switch ON (II).
  20. Reset the ECM/PCM with the HDS.
  21. Do the ECM/PCM idle learn procedure (see «ECM/PCM IDLE LEARN PROCEDURE»(ref-219374-S42320443812006021400000) ).
  22. Check for Temporary DTCs or DTCs with the HDS. Are any Temporary DTCs or DTCs indicated? YES - If DTC P0223 is indicated, check for poor connections or loose terminals at the throttle body and the throttle actuator control module, then go to step 1 . If any other Temporary DTCs or DTCs are indicated, go to the indicated DTC's troubleshooting. NO - Troubleshooting is complete.

APP Sensor Signal Inspection

Note. This procedure is to inspect the abnormalities of the APP sensor full closed position. Other failures than full closed position will store a DTC, therefore the steps to inspect them are not included in this procedure. Check for Temporary DTCs or DTCs with the HDS before this procedure. If there are any DTCs indicated, troubleshoot them first, then do this procedure. Press the accelerator pedal several times, and check the operation. If it does not operate properly, check the accelerator pedal, the throttle cable, and the APP sensor individually. If you find a problem in one of them, replace the parts that caused the problem.

Scheme 177

Scheme 177: APP Sensor Signal Inspection
Scheme 177: APP Sensor Signal Inspection
  1. Connect the HDS to the data link connector (DLC) (A) located under the driver's side of the dashboard.
  2. Turn the ignition switch ON (II).
  3. Make sure the accelerator pedal is not pressed and check the APP SENSOR in the DATA LIST with the HDS. If it is below 2%, the APP sensor is OK. If it is above 2%, adjust the throttle cable (see «THROTTLE CABLE ADJUSTMENT»(ref-219376-S32747651472006021400000) ), then go to step 4.
  4. Make sure the accelerator pedal is not pressed and check the APP SENSOR in the DATA LIST with the HDS. If it is below 2%, the APP sensor is OK. If it is above 2%, update the ECM/PCM if it does not have the latest software, or substitute a known-good ECM/PCM (see «ECM/PCM UPDATING AND SUBSTITUTION FOR TESTING»(ref-219370-S15199960282006021400000) ), then go to step 5.
  5. Make sure the accelerator pedal is not pressed and check the APP SENSOR in the DATA LIST with the HDS. If it is below 2%, the APP sensor is OK. If it is above 2%, replace the APP sensor (see «APP SENSOR REPLACEMENT»(ref-219372-S23656013552006021400000) ), then go to step 1 .

Scheme 178

Scheme 178: APP Sensor Replacement
Scheme 178: APP Sensor Replacement
  1. Remove the throttle cable (see «THROTTLE CABLE REMOVAL/INSTALLATION»(ref-219376-S38563131442006021400000) ).
  2. Disconnect the accelerator pedal position (APP) sensor 6P connector (A).
  3. Remove the bolts (B), and the APP sensor (C).
  4. Install the sensor in the reverse order of removal.

Scheme 179

Scheme 179: Throttle Actuator Control Module Replacement
Scheme 179: Throttle Actuator Control Module Replacement
  1. Remove the glove box (see «GLOVE BOX REMOVAL/INSTALLATION»(ref-219396-S24335219802006021400000) ).
  2. Push the tab (A), and disconnect the throttle actuator control module 16P connector (B).
  3. Remove the bolts (C), and the throttle actuator control module (D).
  4. Install the control module in the reverse order of removal.
