DTC P1684: Throttle Valve Return Spring Performance Problem Honda CR-V II рестайлинг

Testing & Diagnostics 3 illustrations ~759 words
CAUTIONDo not insert your fingers into the installed throttle body when you turn the ignition switch ON (II) or while the ignition switch is ON (II). If you do, you will seriously injure your finger if the throttle valve is activated.

Scheme 181

Scheme 181
Scheme 181
  1. Turn the ignition switch ON (II).
  2. Clear the DTC with the HDS.
  3. Start the engine. Hold the engine speed at 3,000 rpm without load (in Park or neutral) until the radiator fan comes on, then let it idle.
  4. Turn the ignition switch OFF, and wait 10 seconds.
  5. Turn the ignition switch ON (II).
  6. Check for Temporary DTCs or DTCs with the HDS. Is DTC P1683 indicated? YES - Go to step 7. NO - Intermittent failure, system is OK at this time. Check for poor connections or loose terminals at the throttle body and the throttle actuator control module.
  7. Turn the ignition switch OFF.
  8. Disconnect the intake air duct from the throttle body.
  9. Push the throttle valve closed as shown.
  10. Release the throttle valve. Does the throttle valve return? YES - Clean the throttle body (see «THROTTLE BODY TEST»(ref-219376-S21134135652006021400000) ), then go to step 12 . NO - Go to step 11.
  11. Replace the throttle body (see «THROTTLE BODY REMOVAL/INSTALLATION»(ref-219376-S30644524212006021400000) ).
  12. Turn the ignition switch ON (II).
  13. Reset the ECM/PCM with the HDS.
  14. Do the ECM/PCM idle learn procedure (see «ECM/PCM IDLE LEARN PROCEDURE»(ref-219374-S42320443812006021400000) ).
  15. Turn the ignition switch OFF, and wait 10 seconds.
  16. Turn the ignition switch ON (II).
  17. Check for Temporary DTCs or DTCs with the HDS. Are any Temporary DTCs or DTCs indicated? YES - If DTC P1684 is indicated, check for poor connections or loose terminals at the throttle body and the throttle actuator control module, then go to step 1 . If any other Temporary DTCs or DTCs are indicated, go to the indicated DTC's troubleshooting. NO - Troubleshooting is complete.

Scheme 182

Scheme 182: DTC P2101: Throttle Actuator System Malfunction
Scheme 182: DTC P2101: Throttle Actuator System Malfunction

Scheme 183

Scheme 183
Scheme 183
  1. Record all freeze data and any on-board snapshot with the HDS.
  2. Clear the DTC with the HDS.
  3. Do the ETCS TEST in the INSPECTION MENU with the HDS.
  4. Check for Temporary DTCs or DTCs with the HDS. Is DTC P2101 indicated? YES - Go to step 7 . NO - Go to step 5.
  5. Test-drive the vehicle for several minutes in the range of these recorded freeze data parameters: Engine speed Vehicle speed Accelerator position
  6. Check for Temporary DTCs or DTCs with the HDS. Is DTC P2101 indicated? YES - Go to step 7. NO - Intermittent failure, system is OK at this time. Check for poor connections or loose terminals the throttle body and the throttle actuator control module, then clean the throttle body (see «THROTTLE BODY TEST»(ref-219376-S21134135652006021400000) ).
  7. Turn the ignition switch OFF.
  8. Disconnect the intake air duct from the throttle body.
  9. Turn the ignition switch ON (II).
  10. Clear the DTC with the HDS.
  11. Do the ETCS TEST in the INSPECTION MENU with the HDS.
  12. Visually check the throttle valve operation. NOTE: Be careful not to pinch a finger during the check. Does the throttle valve operate smoothly? YES - Clean the throttle body (see «THROTTLE BODY TEST»(ref-219376-S21134135652006021400000) ), then go to step 20 and recheck. If DTC P2101 is indicated, then go to step 18 . NO - Go to step 13.
  13. Turn the ignition switch OFF.
  14. Disconnect the throttle body 6P connector.
  15. Disconnect the throttle actuator control module 16P connector (see «THROTTLE ACTUATOR CONTROL MODULE REPLACEMENT»(ref-219372-S15416086612006021400000) ).
  16. Connect throttle body 6P connector terminals No. 5 and No. 6 with a jumper wire.
  17. Check for continuity between throttle actuator control module 16P connector terminals No. 1 and No. 8. Is there continuity? YES - Substitute a known-good throttle actuator control module (see «THROTTLE ACTUATOR CONTROL MODULE REPLACEMENT»(ref-219372-S15416086612006021400000) ), then go to step 20 . If DTC P2101 is indicated, go to step 18. NO - Repair open in the wires between the throttle body and the throttle actuator control module (motor drive lines), then go to step 20 .
  18. Turn the ignition switch OFF.
  19. Replace the throttle body (see «THROTTLE BODY REMOVAL/INSTALLATION»(ref-219376-S30644524212006021400000) ).
  20. Reconnect all connectors.
  21. Turn the ignition switch ON (II).
  22. Reset the ECM/PCM with the HDS.
  23. Do the ECM/PCM idle learn procedure (see «ECM/PCM IDLE LEARN PROCEDURE»(ref-219374-S42320443812006021400000) ).
  24. Test-drive the vehicle for several minutes in the range of these recorded freeze data parameters: Engine speed Vehicle speed Accelerator position
  25. Check for Temporary DTCs or DTCs with the HDS. Are any Temporary DTCs or DTCs indicated? YES - If DTC P2101 is indicated, check for poor connections or loose terminals at the throttle body and the throttle actuator control module, clean the throttle body (see «THROTTLE BODY TEST»(ref-219376-S21134135652006021400000) ), then go to step 1 . If any other Temporary DTCs or DTCs are indicated, go to the indicated DTC's troubleshooting. NO - Troubleshooting is complete.
