Engine Ignition System - 3.0L (4V): Other Ford Taurus IV рестайлинг

Material

TORQUE SPECIFICATIONS

Scheme 7

1. Disconnect the electrical connector from the ignition coils.
2. Remove the bolts and the ignition coils.
3. To install, reverse the removal procedure. Apply a light film of Silicone Brake Caliper Grease and Dielectric compound D7AZ-19A331-A or equivalent meeting Ford specifications ESE-M1C171-A to the inside of the coil boots before installation.

TORQUE SPECIFICATIONS

Scheme 8

1. Remove the upper intake manifold. For additional information, refer to «ENGINE - 3.0L (4V)»(ref-233692) .
2. Disconnect the electrical connectors from the ignition coils.
3. Remove the bolts and the ignition coils.
4. To install, reverse the removal procedure. Apply a light film of Silicone Brake Caliper Grease and Dielectric compound D7AZ-19A331-A or equivalent meeting Ford specifications ESE-M1C171-A to the inside of the coil boots before installation.
