Automatic Transmission External Controls: Adjustments Ford Taurus IV рестайлинг

Automatic Trans 10 illustrations ~272 words

Selector Lever Cable Adjustment - Floor Shift

Note. The shift control cable adjustment procedure must be performed in the order shown.

Scheme 3

Scheme 3: Selector Lever Cable Adjustment - Floor Shift

Scheme 4

Scheme 4
  1. Position the transaxle range selector lever in OVERDRIVE.
  2. Loosen the manual control lever-to-shift control cable nut.
  3. Position the manual control lever in OVERDRIVE. Tighten the nut.
  4. Check the operation of the transaxle in each transaxle range selector lever position.

Selector Lever Cable Adjustment - Column Shift

Note. The shift control adjustment procedure must be performed in the order shown.

  1. Position the transaxle range selector lever in OVERDRIVE. Hang a 1.4 kg (3 lb) weight on the lever.
  2. Loosen the manual control lever-to-shift control cable nut.
  3. Position the manual control lever in OVERDRIVE. Tighten the manual control lever-to-shift control cable nut.
  4. Remove the 1.4 kg (3 lb) weight. Check the operation of the transaxle in each transaxle range selector lever position.

Scheme 5

Scheme 5: Removal

Scheme 6

Scheme 6

Scheme 7

Scheme 7

Scheme 8

Scheme 8

Scheme 9

Scheme 9

Scheme 10

Scheme 10

Scheme 11

Scheme 11
  1. Depower the supplemental restraint system (SRS). For additional information, refer to «SUPPLEMENTAL RESTRAINT SYSTEM»(ref-233728) .
  2. Remove the center console. For additional information, refer to «INSTRUMENT PANEL AND CONSOLE»(ref-233744) .
  3. Remove the ignition/shifter interlock cable from the floor shift. Disconnect the cable from the bracket. Disconnect the cable from the shift cam.
  4. Remove the LH lower instrument panel trim.
  5. Disconnect four electrical connectors.
  6. Remove the steering column support bracket. Remove the diagnostic electrical connector bolts. Remove the steering column support bracket bolts.
  7. Remove the nuts and lower the steering column.
  8. Disconnect the shift interlock electrical connector.
  9. Remove the bolts.
  10. Remove the ignition/shifter interlock cable and actuator assembly.

Scheme 12

Scheme 12
