TORQUE SPECIFICATIONS
| Description | Nm |
|---|---|
| Floor shift selector lever nuts | 11 |
| Floor shift selector lever bolts | 11 |
| Steering column bracket nuts | 15 |
| Shift cable to manual control lever nut | 20 |
| LH instrument panel trim screws | 7 |
TORQUE SPECIFICATIONS
External Controls - Column Shift
Scheme 1
External Controls - Floor Shift
Scheme 2
The transaxle shift control linkage consists of
- a steering column or floor-mounted transaxle range selector lever.
- a shift cable connecting the steering column to the transaxle range selector lever.
- an ignition/shifter interlock cable on floor-shift vehicles which connects the transaxle range selector lever to the steering column lock assembly.
- an ignition/shift interlock actuator that is integral to the ignition/shift interlock cable.
The ignition/shifter interlock cable
- locks the transaxle range selector lever in the PARK position when the ignition switch is in the LOCK position.
- requires the transaxle range selector lever to be in the PARK position to turn the ignition switch to the LOCK position.
Refer to SHIFT INTERLOCK for schematic and connector information.
