Overhaul - CD4E: Specifications Ford Probe II

Automatic Trans 1 illustration

No Torque Converter Clutch

Check valve body and torque converter.

Torque Converter Clutch Always Engaged

Check valve body, oil pump assembly, torque converter and transaxle case.

TURBINE TORQUE CHECK

Install End Play Checking Tool (T81P-7902-D) with sleeve into turbine splines in converter. Using torque wrench, measure turbine turning torque. Replace converter is torque exceeds 53 INCH lbs. (6 N.m).

Scheme 95

Scheme 95: TURBINE TORQUE CHECK

TRANSAXLE SPECIFICATIONS

ApplicationIn. (mm)
Direct Clutch Pack Clearance.020-.044 (.52-1.12)
Forward/Coast Clutch Pack Clearance.020-.043 (.50-1.09)
Reverse Clutch Pack Clearance.012-.035 (.33-.89)
Low/Inter. Planetary Thrust Clearance.006-.028 (.15-.72)
Oil Pump Drive Gear Clearance.001-.002 (.027-.060)
Oil Pump Driven Gear Clearance.001-.002 (.027-.060)
Reverse/OD Planetary Thrust Clearance.006-.028 (.15-.72)
INCH lbs. (N.m)
Oil Pump Rotating Torque2 (.3 N.m)

TRANSAXLE SPECIFICATIONS

TORQUE SPECIFICATIONS

ApplicationFt Lbs. (N.m)
Axle Nut174-235 (235-319)
Drain Plug20 (27)
Dynamic Damper Bolt31-46 (42-62)
Main Control Cover Bolt15 (20)
Manual Control Lever Bolt18 (25)
Stabilizer Link Nut27-40 (36-54)
Steering Knuckle Clamp Bolt25-42 (34-57)
Transaxle Case Bolt19 (26)
Transmission Speed Sensor Bolt11 (15)
Wheel Lug Nut65-87 (88-118)
INCH Lbs. (N.m)
Accumulator-To-Transfer Plate Bolt89 (10)
Control Valve-To-Transfer Plate Bolt89 (10)
Manual Valve Lever Ball Stud Nut106 (12)
Oil Level Control Valve Bolt106 (12)
Oil Pump Bolt115 (13)
Pressure Tap Plate Bolt71 (8)
Valve Body-To-Transaxle Case Bolt89 (10)
Vehicle Speed Sensor Bolt43 (5)

TORQUE SPECIFICATIONS
