INTERMEDIATE & OVERDRIVE SERVO
Note. Manufacturer does not recommend removal of intermediate and overdrive servo while transaxle is installed in vehicle. On-vehicle removal of servo cover is only recommended for fluid leakage repair.
No Forward Engagement, Reverse Okay
Check shift linkage, oil pump external or internal (support sealing rings) leakage, valve body malfunction (internal leak, stuck regulator valve and/or leaking forward accumulator), forward and coast clutch assembly, low one-way clutch, forward one-way clutch and low/intermediate planetary carrier.
No Reverse Engagement, Forward Okay
Check external and internal shift linkage, low line pressure, valve body (stuck valve), oil Pump internal leak (No. 6 and 7 sealing rings), reverse clutch assembly, low/reverse clutch assembly, forward/coast/direct clutch cylinder, case (oil passages cross leakage or porosity) and reverse/overdrive gear set.
Harsh Reverse &/Or Forward Engagement
Check fluid level, axle shafts and CV joints, engine/transaxle mounts, shift linkage, line pressure, restricted oil filter, valve body, forward clutch assembly, reverse clutch assembly, low/reverse clutch assembly and direct clutch assembly.
Delayed/Soft Reverse and/or Forward Engagement
Check fluid level, axle shafts and CV joints, engine/transaxle mounts, shift linkage, line pressure, restricted oil filter, valve body, forward clutch assembly, reverse clutch assembly, low/reverse clutch assembly and direct clutch assembly.
No Forward or Reverse Engagement
Check fluid level, shift linkage, line pressure, oil pump, restricted oil filter, valve body, torque converter, turbine shaft to forward/coast/direct clutch cylinder, chain and sprocket assembly, park pawl mechanism, axle shafts and CV joints, final drive assembly and planetary gear assemblies.
All Or Some Shifts Not Present
Check fluid level, shift linkage, speedometer drive/driven gear, valve body, band, low one-way clutch assembly, overdrive/reverse sun gear and shell, case, oil pump, direct clutch assembly, intermediate/overdrive servo, coast clutch assembly and forward one-way clutch assembly.
Early or Late Shifting
Check tire size and speedometer drive/driven gear.
Erratic/Hunting Shift Timing
Check fluid, vehicle speed input, valve body and miscellaneous internal failures.
Soft/Slipping Shift Feel
Check fluid condition, shift linkage, low line pressure, valve body, oil pump assembly and leaking filter and/or seal.
Harsh Shift Feel
Check fluid level and condition, axle shafts and CV joints, high line pressure, valve body and torque converter.
No First Gear (In "D" Position)
Check shift linkage, valve body and internal seal(s) leakage.
No Low Gear
Check shift linkage and valve body.
Poor Vehicle Performance
Check correct shift linkage to shift lever indexing, torque converter (TCC applied and one-way clutch).
No Engine Braking In Manual Low Position
Check valve body, coast clutch assembly, low/reverse clutch assembly and oil pump assembly.
No Engine Braking In Manual 2nd Position
Check shift linkage, valve body, forward one-way clutch assembly, coast clutch assembly and oil pump assembly.
Vehicle Movement In Neutral Position
Check shift linkage, oil pump assembly and forward/coast clutch assembly.
AIR PRESSURE CHECK
- Disconnect negative battery cable. Remove air cleaner assembly. Disconnect transaxle harness connector. Compress tabs on transaxle electrical harness receptacle and push into case. Raise and support vehicle.
- Remove drain plug and drain fluid. Remove left front fender splash shield. Secure cooler lines away from main control cover assembly (side cover). Remove cover and gasket. Remove 12 valve body bolts. Slightly lift valve body and remove "Z" link.
- Remove valve body with wiring harness. Remove thermostatic oil level control valve bracket. Pull valve straight out of transaxle case. CAUTION: DO NOT air check coast clutch since piston may be forced out of forward clutch piston.
- Install Transmission Test Plate (T94P-77000-S). Air check clutch hydraulic circuits for function and leakage. (Scheme 120) If leakage is detected, disassemble transaxle and inspect. Remove test plate.
- Install thermostatic oil level control valve in transaxle case. Install bracket. Tighten bolt to specification. Refer to «TORQUE SPECIFICATIONS»(ref-25357-S41702441632001011700000). Install new "O" ring on valve body harness connector receptacle. Install receptacle in transaxle case.
- Insert "Z" link into end of manual valve. Place valve body in position on transaxle case and install 12 valve body bolts. Tighten bolts in sequence. (Scheme 121) Tighten bolts to specification. See «TORQUE SPECIFICATIONS»(ref-25357-S41702441632001011700000).
- Remove manual control lever bolt and lever assembly. Using Shifter Shaft Alignment Tool (T94P-77000-H), move manual control lever shaft to "D" position. Install pin to hold the tool in position. (Scheme 122) Move manual valve detent lever assembly to "D" position.
- Loosen nut on ball stud of manual valve detent lever actuating rod assembly. Snug nut on ball stud. Remove shifter pin. Rotate Shifter Shaft Alignment tool until socket can be installed on nut. Tighten bolt to specification. See «TORQUE SPECIFICATIONS»(ref-25357-S41702441632001011700000).
- Rotate lever back to "D" position and recheck adjustment. Remove pin and alignment tool. Install manual control lever assembly. Tighten bolt to specification. See «TORQUE SPECIFICATIONS»(ref-25357-S41702441632001011700000). Install main control cover (side cover) with a new gasket. Tighten retaining bolts in sequence. (Scheme 123) Tighten bolts to specification. Refer to «TORQUE SPECIFICATIONS»(ref-25357-S41702441632001011700000).
- To complete installation, reverse removal procedures. Tighten drain plug to specification. See «TORQUE SPECIFICATIONS»(ref-25357-S41702441632001011700000). Add 6 qts. of ATF fluid. Start and run vehicle. Add fluid as necessary.
Scheme 120
Scheme 121
Scheme 122
Scheme 123
| CAUTION | DO NOT maintain Wide Open Throttle (WOT) in any gear for more than 5 seconds. If engine RPM exceeds maximum specified stall speed, release accelerator immediately. Clutch or band slippage is indicated. |
Line Pressure Low At Idle In All Ranges
Check low fluid level, restricted inlet filter, loose valve body or valve body components, oil pump leakage and sticking main regulator valve.
Line Pressure High In All Ranges
Check main regulator valve, solenoid body and wiring harness and perform Quick Test procedure.
| Selector Position | Idle RPM | WOT Stall RPM |
|---|---|---|
| "P" &"N" | 64-76 | N/A |
| "R" | 64-76 | 259-294 |
| "D" | 45-63 | 168-184 |
| "2" | 45-63 | 168-184 |
| "L" | 45-63 | 168-184 |
LINE PRESSURE SPECIFICATIONS (PSI)
Scheme 124
CONVERTER END PLAY CHECK
With torque converter removed from transaxle, position End Play Checking Device (T81P-7902-D) in converter hub. Tighten nut on device. Position a dial indicator on device. Position dial indicator pointer on converter shell. see scheme 9 Lift up on device handles. If dial indicator reading exceeds.050" (1.27 mm), replace converter.
LEAKAGE CHECK
With torque converter removed from transaxle, check for leakage using torque converter leak tester.
ONE-WAY CLUTCH CHECK
Place 90° end of pick tool in slot on bottom of converter stator. While holding pick, rotate inner race with fingers. One-way clutch should not rotate in counter-clockwise direction and should rotate in clockwise direction. Replace converter if one-way clutch does not operate as specified.
PUMP INSERT CHECK
Install oil pump shaft into torque converter. Using torque wrench with 5/16" socket, ensure insert can hold up to 10 ft. lbs. Replace converter if insert turns.
VALVE BODY
Note. Remove and clean one valve at a time to avoid incorrect installation.
