Starting System - 1.6L -- Escape: Removal & Installation Ford Kuga II

Removal

Note. Removal steps in this procedure may contain installation details.

Scheme 5

Scheme 6

Scheme 7

1. Refer to: «JACKING AND LIFTING - OVERVIEW»(ref-658843-S31152527922014092900000) .
2. Refer to: «AIR CLEANER»(ref-658888-S03686657652014092900000) .
3. Refer to: «BATTERY DISCONNECT AND CONNECT»(ref-658873-S03187421432014092900000) .
4. If equipped.
5. Torque : 97 lb.in (11 Nm) Torque : 35 lb.in (4 Nm)
6. Torque : 53 lb.in (6 Nm) Torque : 106 lb.in (12 Nm)
7. From above. Torque : 26 lb.ft (35 Nm) From below. Torque : 26 lb.ft (35 Nm)
8. Refer to: «STARTER MOTOR DRIVE GEAR AND FLYWHEEL RING GEAR INSPECTION»(ref-658903-S06603915602014092900000) .

Installation

1. To install, reverse the removal procedure.
