Removal
Note. Typical head restraint guide sleeve shown in illustration, others similar.
Scheme 2
Scheme 3
- NOTE: Follow the unique instructions or graphic for this step in the installation. Use the General Equipment: Flat Headed Screw Driver
Scheme 4
Scheme 5
- NOTE: Always install new head restraint guide sleeves. Difficult adjustment of the head restraint may occur. Failure to follow these instructions may result in component failure. NOTE: The head restraint guide sleeves are not interchangeable. Failure to install the correct head restraint guide sleeves at the correct position may result in component failure. Allow the head restraint guide sleeve to slide freely through the backrest foam pad and backrest trim cover, twist the head restraint guide sleeve while pushing it into the backrest frame hole as far as it will go, using hand pressure. By hand, press the head restraint guide sleeve downward into the backrest.
Note. Driver seat shown in illustration, passenger seat similar.
Note. Removal steps in this procedure may contain installation details.
Pinpoint Test M
M1
SRS
- WARNING: Turn the ignition OFF and wait one minute to deplete the backup power supply. Ignition must remain OFF until repair is complete. Failure to follow this instruction may result in serious personal injury or death in the event of an accidental deployment.
- If a seat side air bag module or safety belt buckle pretensioner or safety belt inflator SRS fault is present, continue to Step 2. Otherwise, turn the ignition off, wait at least one minute and continue to Step 3 .
M2
SRS
- NOTE: The air bag warning indicator illuminates when the correct RCM fuse is removed and the ignition is on.
- Depower the SRS .
- Refer to: «SUPPLEMENTAL RESTRAINT SYSTEM (SRS) DEPOWERING AND REPOWERING»(ref-658836-S20408517042014092900000) .
Installation
Pinpoint Test M
M3
SRS
- Refer to: «SUPPLEMENTAL RESTRAINT SYSTEM (SRS) DEPOWERING AND REPOWERING»(ref-658836-S20408517042014092900000) .
Note. Driver seat shown in illustration, passenger seat similar.
Note. Removal steps in this procedure may contain installation details.
Scheme 6
Scheme 7
Scheme 8
Scheme 9
Scheme 10
Scheme 11
Scheme 12
Scheme 13
Scheme 14
Scheme 15
- Refer to: «FRONT SEAT»(ref-658831-S05870300302014092900000) .
- NOTE: Follow the unique instructions or graphic for this step in installation. If equipped.
- If equipped.
- NOTE: Follow the unique instructions or graphic for this step in installation.
All seats
Pinpoint Test M
M5
If the passenger seat has been serviced, do not prove out the
- Refer to: «FRONT SEAT»(ref-658831-S05870300302014092900000) .
- Passenger seat
M6
OCS
- WARNING: Occupant Classification System (OCS) parts are calibrated as an assembly and must only be replaced in the configuration they are sold. Never separate parts of an assembly. Failure to follow this instruction may result in incorrect operation of the OCS and increases the risk of serious personal injury or death in a crash.
- WARNING: Make sure the front passenger seat repair is complete, the seat and all attached components (head restraint, seat side shield, etc.) are correctly assembled, and the seat is correctly installed to the vehicle before using System Reset to rezero the seat weight. Failure to follow these instructions may result in incorrect operation of the occupant classification system (OCS) and increases the risk of serious personal injury or death in a crash.
- NOTE: To prevent system failure, take the following precautions before carrying out the OCS reset. Make sure the voltage to the OCSM is greater than 8 volts and less than 18 volts. Make sure the OCS is not below 42.8°F (6°C) or above 96.7°F (36°C) when initiating the OCS reset process. If the vehicle has been exposed to extreme cold or hot temperatures, the vehicle must be exposed and kept at a temperature between 42.8°F (6°C) to 96.7°F (36°C) for a minimum of 30 minutes. Make sure nothing is present on the passenger seat before and during the OCS reset process. Prior to carrying out the OCS reset, make sure a minimum of 8 seconds has elapsed after cycling the ignition switch on.
- Using a diagnostic scan tool, carry out the OCS reset. Cycle the ignition switch after the OCS reset.
M7
SRS
M8
OCS
M9
OCS
- Refer to: «OCCUPANT CLASSIFICATION SYSTEM (OCS) SENSOR»(ref-658836-S12119300112014092900000) .
M10
SRS
M11
RCM
M12
RCM
- Driver seat
Note. Driver seat shown in illustration, passenger seat similar.
Scheme 16
Scheme 17
Scheme 18
- Refer to: «FRONT SEAT»(ref-658831-S05870300302014092900000) .
- NOTE: This step is only necessary when installing a new component. Refer to: «FRONT HEAD RESTRAINT GUIDE SLEEVE»(ref-658831-S15404673152014092900000) .
- NOTE: Use care when separating the seat cushion trim cover from the hook-and-loop strips or the hook and-loop strips may be torn from the seat cushion foam pad.
- NOTE: This step is only necessary when installing a new component.
- To install, reverse the removal procedure.
- Use the General Equipment: Hog Ring Plier
Scheme 19
- WARNING: Turn the ignition OFF and wait one minute to deplete the backup power supply. Ignition must remain OFF until repair is complete. Failure to follow this instruction may result in serious personal injury or death in the event of an accidental deployment. Turn the ignition OFF and wait at least one minute.
- To install, reverse the removal procedure.
Note. To prevent system failure, carry out the OCS reset when a front passenger seat cushion is disassembled, a new trim cover is installed or an OCS service kit is installed. Use a scan tool to carry out the OCS reset command.
Note. Driver seat shown in illustration, passenger seat similar.
Note. Removal steps in this procedure may contain installation details.
Scheme 20
Scheme 21
- Refer to: «FRONT SEAT»(ref-658831-S05870300302014092900000) .
- NOTE: Follow the unique instructions or graphic for this step in installation. If equipped.
- If equipped.
- If equipped.
- NOTE: Use care when separating the seat cushion trim cover from the hook-and-loop strips or the hook and-loop strips may be torn from the seat cushion foam pad. NOTE: This step is only necessary when installing a new component.
All seats
Pinpoint Test M
M3
If the passenger seat has been serviced, do not prove out the
- Refer to: «FRONT SEAT»(ref-658831-S05870300302014092900000) .
- Passenger seat
M4
OCS
- WARNING: Occupant Classification System (OCS) parts are calibrated as an assembly and must only be replaced in the configuration they are sold. Never separate parts of an assembly. Failure to follow this instruction may result in incorrect operation of the OCS and increases the risk of serious personal injury or death in a crash.
- WARNING: Make sure the front passenger seat repair is complete, the seat and all attached components (head restraint, seat side shield, etc.) are correctly assembled, and the seat is correctly installed to the vehicle before using System Reset to rezero the seat weight. Failure to follow these instructions may result in incorrect operation of the occupant classification system (OCS) and increases the risk of serious personal injury or death in a crash.
- NOTE: To prevent system failure, take the following precautions before carrying out the OCS reset. Make sure the voltage to the OCSM is greater than 8 volts and less than 18 volts. Make sure the OCS is not below 6°C (42.8°F) or above 36°C (96.7°F) when initiating the OCS reset process. If the vehicle has been exposed to extreme cold or hot temperatures, the vehicle must be exposed and kept at a temperature between 6°C (42.8°F) to 36°C (96.7°F) for a minimum of 30 minutes. Make sure nothing is present on the passenger seat before and during the OCS reset process. Prior to carrying out the OCS reset, make sure a minimum of 8 seconds has elapsed after cycling the ignition switch on.
- Using a diagnostic scan tool, carry out the OCS reset. Cycle the ignition switch after the OCS reset.
M5
SRS
M6
OCS
M7
OCS
- Refer to: «OCCUPANT CLASSIFICATION SYSTEM (OCS) SENSOR»(ref-658836-S12119300112014092900000) .
M8
SRS
M9
RCM
M10
RCM
Note. Driver seat shown in illustration, passenger seat similar.
Scheme 22
- NOTE: Position the backrest cover up only enough to access the lumbar assembly. Refer to: «FRONT SEAT BACKREST COVER»(ref-658831-S19007156022014092900000) .
- To install, reverse the removal procedure.
Note. Driver seat shown in illustration, passenger seat similar.
Scheme 23
Scheme 24
Scheme 25
- Refer to: «FRONT SEAT BACKREST»(ref-658831-S34139605012014092900000) .
- To install, reverse the removal procedure.
- NOTE: This step is only necessary when installing a new component. If equipped with driver seat memory feature, calibrate the driver seat hard stops using a scan tool.
Note. Driver seat shown in illustration, passenger seat similar.
Scheme 26
Scheme 27
- To install, reverse the removal procedure.
Scheme 28
Scheme 29
Scheme 30
- Refer to: «INSTRUMENT PANEL CENTER FINISH PANEL»(ref-658886-S37837483202014092900000) .
- To install, reverse the removal procedure.
Scheme 31
- To install, reverse the removal procedure.
- NOTE: This step is only necessary when installing a new component. Calibrate the driver seat hard stops using a scan tool.
| WARNING | The following procedure prescribes critical repair steps required for correct restraint system operation during a crash. Follow all notes and steps carefully. Failure to follow step instructions may result in incorrect operation of the restraint system and increases the risk of serious personal injury or death in a crash. |
| WARNING | Wear protective gloves when handling components or parts that have pointed or sharp edges. Failure to follow this instruction may result in serious personal injury. |
Note. Typical seat shown in illustration, others similar.
Scheme 32
Scheme 33
- Refer to: «FRONT SEAT»(ref-658831-S05870300302014092900000) .
Pinpoint Test M
M18
Vehicles with memory seats
- click to open the image
- Vehicles with memory seats
