Removal
| WARNING | Always disconnect the battery ground cable at the battery before disconnecting the starter motor battery terminal lead. If a tool is shorted at the starter motor battery terminal, the tool can quickly heat enough to cause a skin burn. Failure to follow this instruction may result in serious personal injury. |
Note. Removal steps in this procedure may contain installation details.
Scheme 14
Scheme 15
Scheme 16
Scheme 17
- Refer to: «BATTERY DISCONNECT AND CONNECT»(ref-658873-S03187421432014092900000) .
- Refer to: «JACKING AND LIFTING - OVERVIEW»(ref-658843-S31152527922014092900000) .
- If equipped.
- Torque: 97 lb.in (11 Nm) Torque: 44 lb.in (5 Nm)
- 3. Torque: 159 lb.in (18 Nm)
- Torque: 26 lb.ft (35 Nm)
- Torque: 106 lb.in (12 Nm) Torque: 53 lb.in (6 Nm)
- Refer to: «STARTER MOTOR DRIVE GEAR AND FLYWHEEL RING GEAR INSPECTION»(ref-658913-S20019984542014092900000) .
Installation
- To install, reverse the removal procedure.
