Parking Aid - Audible

The rear parking aid system sounds a warning through the rear audio speakers (low pitched tone) to alert the driver of stationary objects near the rear bumper when REVERSE is selected. The parking aid system assists the driver in detecting certain objects while the vehicle moves slowly in REVERSE at speeds of less than 4.8 kmh (3 mph). The parking aid system may not detect moving objects.

The front parking aid system sounds a warning through the front audio speakers (high pitched tone) to alert the driver of stationary objects near the front bumper in all transmission positions except PARK or NEUTRAL. The parking aid system assists the driver in detecting certain objects while the vehicle moves at speeds of less than 4.8 kmh (3 mph). The parking aid system may not detect moving objects.

The parking aid system is disabled if a fault is detected in a parking aid sensor, the communications network or the Parking Aid Module (PAM). This is indicated by a parking aid disabled warning message in the message center.

The parking aid system is enabled and disabled through the message center, located in the IPC. Disabling lasts one key cycle.

If a MyKey® restricted key is in use, the parking aid menu is not available in the message center and cannot be deactivated.

Parking Aid - Video

The video camera system visually aids the driver while reversing or reverse parking the vehicle. This feature provides fixed and active guideline overlays on the video image to assist the driver in parking the vehicle. The visual parking aid also includes a visual alert function that works with the rear audible parking aid system to visually highlight a zone in the video image where an object has been detected. The video camera system is controlled though the FDIM. Refer to the Owner's Literature for information on how to operate the video camera system features.

Scheme 24

Scheme 24: System Diagram
Scheme 24: System Diagram

Network Message Chart

Broadcast MessageOriginating ModuleMessage Purpose
Power modeBCMUsed to command ignition position.
Parking aid enable statusIPCUsed to enable or disable the rear parking aid.
Reverse gear (manual transmission)PCMUsed to enable the parking aid when the transmission is in REVERSE (manual transmission vehicles).
Selector lever (PRNDL) status (automatic transmission)TCMUsed to enable the parking aid when the transmission selector is in REVERSE (automatic transmission vehicles).
Vehicle speedABS moduleUsed to disable the parking aid if the vehicle speed exceeds a preset threshold.

PARKING AID MODULE (PAM) NETWORK INPUT MESSAGES

Broadcast MessageOriginating ModuleMessage Purpose
Tone requestParking Aid Module (PAM)Used to command parking aid sounder tones through the front and/or rear speakers.

AUDIO CONTROL MODULE (ACM) NETWORK INPUT MESSAGES

Parking Aid System - Audible

When the front and/or rear audible parking aid system is active, the Parking Aid Module (PAM) calculates the distance to an object within a 170 degree semicircular area (azimuth) around the front or rear of the vehicle. A varible-rate warning tone is generated through the audio speakers in proportion to the distance that the object is from the front and/or rear of the vehicle.

The rear parking aid system calculates the distance to an object around the rear of the vehicle using 3 ultrasonic sensors. The rear parking aid sensors detect objects approximately 1, 524 mm (60 in) from the rear of the vehicle, 508 mm (20 in) from the rear side of the vehicle, and 304.8 mm (12 in) above the ground. To detect objects behind the vehicle, the Parking Aid Module (PAM) supplies voltage and ground to the rear ultrasonic sensors while monitoring a signal return circuit from each sensor. The 3 rear sensors share common voltage and ground circuits.

The front parking aid system calculates the distance to an object around the front of the vehicle using 4 ultrasonic sensors. The front parking aid sensors detect objects approximately 685.8 mm (27 in) from the front of the vehicle, 457.2 mm (18 in) from the front side of the vehicle, 304.8 mm (12 in) above the ground. To detect objects in front of the vehicle, the Parking Aid Module (PAM) supplies voltage and ground to the front ultrasonic sensors while monitoring a signal return circuit from each sensor. The 4 front sensors share common voltage and ground circuits.

Only objects that reflect a sufficient amount of sound waves will be detected by the front or rear parking aid sensors. The surface properties, size and composition an object can affect the ability of the parking aid system to detect the object. Incorrect sensor alignment or installation, dirt or ice covered sensors, heavy rain and snow can also cause objects not to be detected.

Parking Aid Audible Alert

The audio speaker volume is reduced when the park aid warning tone sounds. The audio speaker increases its warning tone rate as the vehicle gets closer to an obstacle. When an object is detected within 304.8 mm (12 in) of the sensors, the warning tone becomes continuous. Objects to the rear side will generate continuous tone only for 3 seconds if the object is stationary or receding from the vehicle. The tone is prioritized to the system (front or rear) which has detected an object closest to the bumper. Tone alternates between front and rear audio speakers if an object is closer than 254 mm (10 in) front and rear.

Parking Aid - Video

Scheme 25

Scheme 25: System Diagram
Scheme 25: System Diagram
Broadcast MessageOriginating ModuleMessage Purpose
Camera commandsAPIMUsed to command the static and active guidelines status, zoom level and object distance
Parking aid range to objectParking Aid Module (PAM)Used to highlight the zone where an object is detected.
Power modeBCMUsed to command ignition position.
Reverse gearPCMUsed to enable the video display.
Selector lever (PRNDL) statusIPCUsed to enable the video display.
Steering angle statusSASMUsed to create the vehicle intended path on video display.

IMAGE PROCESSING MODULE B (IPM-B) NETWORK INPUT MESSAGES

Broadcast MessageOriginating ModuleMessage Purpose
Backup camera statusImage Processing Module B (IPM-B)Used to display the video status for static and active guidelines, zoom level and object distance.

ACCESSORY PROTOCOL INTERFACE MODULE (APIM) AND FRONT CONTROL DISPLAY INTERFACE MODULE (FCDIM) NETWORK INPUT MESSAGES

Image Display

The liftgate must remain closed for correct operation of the video camera system.

All of the video camera features are enabled and disabled within the FDIM menu screen. The video camera system has 5 video features

  1. Fixed guidelines - this feature assists the driver with aligning the vehicle with an object.
  2. Active guidelines - this feature projects the intended path of the vehicle based upon steering wheel input.
  3. Visual park aid alert - this feature assists the driver to visually see the object causing the parking aid system to sound.
  4. Manual zoom - this feature assists the driver with connecting or towing a trailer allowing the driver to manually zoom closer to an object behind the vehicle.
  5. Video camera delay - this feature allows the driver to see the image behind the vehicle after the vehicle is shifted out of REVERSE. The image will not be displayed if the vehicle is shifted into PARK.

For each one of these system features except the camera delay feature, the driver generated backup camera commands are sent from the FDIM to the APIM (vehicles equipped with 8-inch (203-mm) touchscreen) or the FCDIM (vehicles equipped with 4.2-inch (107-mm) display) to the Image Processing Module - B (IPM-B). The Image Processing Module B (IPM-B) then sends the command to the video camera. For vehicles equipped with 8-inch (203-mm) touchscreen, the video camera outputs the video signal to the APIM which in turn displays the video on the FDIM. For vehicles equipped with 4.2-inch (107-mm) display, the video camera outputs the video signal directly to the FCDIM .

The video camera delay feature is controlled within the APIM.

The Image Processing Module B (IPM-B) and the video camera communicate on a LIN which is a dedicated single wire communication network.

The messages sent from the Image Processing Module B (IPM-B) to the video camera are

  1. transmission selector (PRNDL) status
  2. liftgate ajar status
  3. camera configuration data
  4. display manual zoom request
  5. parking aid audible warning status
  6. parking aid sensor distance to object data

The messages sent from the video camera to the Image Processing Module - B (IPM-B) are

  1. camera status
  2. display zoom status
  3. camera part number data
  4. visual park aid alert status
  5. fixed guideline status

Visual Park Aid

The visual park alert feature displays guidelines on top of the video image to assist the driver with maneuvering a vehicle into a space. Active guidelines are not shown when the steering wheel is straight.

The visual park aid alert feature utilizes the 3 parking aid sensor inputs from the Parking Aid Module (PAM) and the video camera image. When the transmission selector is in REVERSE and an object is detected in the path of the parking aid sensor, parking aid range to object data is sent from the Parking Aid Module (PAM) through the Image Processing Module B (IPM-B) to the video camera.

The visual alerts are red, yellow or green and appear as highlights on top of the displayed image to indicate in which zone the object is detected. The highlighted visual alerts are still operational if the parking aid system is disabled within the FDIM and the visual alert feature is enabled.

Fixed Guidelines

Note. The color-coded lines cannot indicate accurate or consistent distances between objects located behind the vehicle and at the rear of the vehicle. This normal condition is due to variances in vehicle ride height, including, but not limited to, vehicle loading.

The video camera fixed guidelines feature displays guidelines on top of the video image to assist the driver with alignment of the vehicle. A dashed line on the displayed image represents the center of the vehicle and 3 color-coded lines (red, yellow, green) identify different zones between the rear of the vehicle and objects.

Active Guidelines

The video camera active guidelines feature displays guidelines on top of the video image to assist the driver with maneuvering a vehicle into a space. Active guidelines are not shown when the steering wheel is straight.

Manual Zoom

The manual zoom feature is controlled by the video camera. The manual zoom feature has 3 zoom levels that are only active when the vehicle is in REVERSE. If the manual zoom feature is enabled and the vehicle is shifted out of REVERSE the manual zoom feature is disabled. The manual zoom feature must be re-enabled the next time the vehicle is shifted into REVERSE.

Video Delay

When the video delay is turned on, the video image remains displayed after the transmission is shifted out of REVERSE until the vehicle reaches 8 kmh (5 mph). With the delay off (default), the image displays until the transmission is shifted out of REVERSE.

Parking Aid Sensors

The parking aid sensors are wide beam ultrasonic sensors. The sensors continuously send out ultrasonic signals to detect objects and communicate the information back to the Parking Aid Module (PAM).

Only objects which reflect enough sound waves are detected by the sensors. This varies due to the shape, surface properties and size of objects being detected. Incorrect sensor alignment, dirt covered sensors, heavy rain and snow can cause objects not to be recognized.

Parking Aid Switch

On vehicles equipped with the active park assist system, a parking aid disable switch to allows the driver to temporarily disable the front and rear audible parking aid. The switch is integral to the active park assist switch and is a normally open, momentary contact switch that proves a ground to the Parking Aid Module (PAM) when pressed. This switch is disabled when a MyKey® is in use.

Parking Aid Module (PAM)

The PAM calculates and reports the distance between the rear of the vehicle (and front of the vehicle, if equipped) and an object. The PAM is capable of setting and storing Diagnostic Trouble Codes (DTCs) for the parking aid when a concern exists.

Video Camera

The rear video camera system is active with the ignition in RUN and the transmission selector in REVERSE. The video camera receives commands and sends status over a dedicated LIN to the Image Processing Module - B (IPM-B). The video signal is hardwired from the camera to the APIM which is directly connected to the FDIM. The video camera is configured by the Image Processing Module - B (IPM-B) and does not require Programmable Module Installation (PMI).

Video Display

The video display is the FDIM touchscreen or the FCDIM . Refer to the appropriate INFORMATION AND ENTERTAINMENT SYSTEM - GENERAL INFORMATION - AM/FM/CD , INFORMATION AND ENTERTAINMENT SYSTEM - GENERAL INFORMATION - AM/FM/CD/SYNC or INFORMATION AND ENTERTAINMENT SYSTEM - GENERAL INFORMATION - SYNC/SONY AM/FM/CD article for the procedure.

Image Processing Module B (IPM-B)

The Image Processing Module B (IPM-B) serves as the gateway module between the video camera and modules on the Medium Speed Controller Area Network (MS-CAN). The Image Processing Module B (IPM-B) is configurable and requires Programmable Module Installation (PMI).

The Audible Parking Aid Is Inoperative

Diagnostics in this manual assume a certain skill level and knowledge of Ford-specific diagnostic practices.

REFER to: DIAGNOSTIC METHODS .

Refer to PARKING AID for schematic and connector information.

Possible Sources

  1. Parking Aid Module (PAM)
  2. TR sensor concern (automatic transmission)
  3. Reversing lamp switch concern (manual transmission)

B1B57:11

Diagnostics in this manual assume a certain skill level and knowledge of Ford-specific diagnostic practices.

REFER to: DIAGNOSTIC METHODS .

Refer to PARKING AID for schematic and connector information.

  1. Wiring, terminals or connectors
  2. Front Parking aid sensor
  3. Active park assist sensor
  4. Parking Aid Module (PAM)

B1B58:11

Diagnostics in this manual assume a certain skill level and knowledge of Ford-specific diagnostic practices.

REFER to: DIAGNOSTIC METHODS .

Refer to PARKING AID for schematic and connector information.

  1. Wiring, terminals or connectors
  2. Rear Parking aid sensor
  3. Parking Aid Module (PAM)

B13B5:14, B1B44:14, B1B48:14

Diagnostics in this manual assume a certain skill level and knowledge of Ford-specific diagnostic practices.

REFER to: DIAGNOSTIC METHODS .

Refer to PARKING AID for schematic and connector information.

  1. Wiring, terminals or connectors
  2. Rear Parking aid sensor
  3. Parking Aid Module (PAM)

B13B5:12, B1B44:12, B1B48:12

Diagnostics in this manual assume a certain skill level and knowledge of Ford-specific diagnostic practices.

REFER to: DIAGNOSTIC METHODS .

Refer to PARKING AID for schematic and connector information.

  1. Wiring, terminals or connectors
  2. Rear Parking aid sensor
  3. Parking Aid Module (PAM)

Scheme 26

Scheme 26: PINPOINT TEST E: B13B5:12, B1B44:12, B1B48:12
Scheme 26: PINPOINT TEST E: B13B5:12, B1B44:12, B1B48:12
  1. E1 RETRIEVE THE DIAGNOSTIC TROUBLE CODES (DTCS) FROM THE PARKING AID MODULE (PAM) SELF-TEST Using a scan tool, perform the Parking Aid Module (PAM) self-test. Check the Parking Aid Module (PAM) Diagnostic Trouble Codes (DTCs) from the self-test. Are multiple parking aid sensor Diagnostic Trouble Codes (DTCs) recorded? Yes: GO to E2 No: For Diagnostic Trouble Codes (DTCs) B13B5:12, B1B44:12 and B1B48:12, GO to E3 For all other Diagnostic Trouble Codes (DTCs), REFER to the «PARKING AID MODULE (PAM) DTC CHART»(ref-515935-S24317435302012120400000) .
  2. E2 CHECK THE BUMPER WIRING HARNESS Inspect the bumper wiring harness for opens, shorts, grounds, or corrosion. Is the bumper wiring harness OK? Yes: GO to E3 No: REPAIR or INSTALL a new bumper wiring harness.
  3. E3 CHECK THE SENSOR CIRCUITRY FOR SHORTS TO VOLTAGE Ignition OFF. Disconnect: Suspect Parking Aid Sensor(s). Ignition ON. For DTC B13B5:12, measure: Click to display connectors Positive Lead Measurement / Action Negative Lead C4228-2 - For DTC B1B44:12, measure: Click to display connectors Positive Lead Measurement / Action Negative Lead C4011-2 - For DTC B1B48:12, measure: Click to display connectors Positive Lead Measurement / Action Negative Lead C4009-2 - Is any voltage present? Yes: REPAIR the circuit in question. No: GO to E4
  4. E4 CHECK THE PARKING AID SENSOR CIRCUITRY FOR A SHORT TOGETHER For DTC B13B5:12, measure: Click to display connectors Positive Lead Measurement / Action Negative Lead C4228-2 ohms C4228-1 For DTC B1B44:12, measure: Click to display connectors Positive Lead Measurement / Action Negative Lead C4011-2 ohms C4011-1 For DTC B1B48:12, measure: Click to display connectors Positive Lead Measurement / Action Negative Lead C4009-2 ohms C4009-1 Is the resistance greater than 10, 000 ohms? Yes: If all the sensor Diagnostic Trouble Codes (DTCs) are set, GO to E5 If one or more parking aid sensor(s) recorded Diagnostic Trouble Codes (DTCs), INSTALL a new sensor(s) for the one in question. REFER to: «Rear Parking Aid Sensor»(ref-515935-S16248491502012120400000) . No: REPAIR the circuits in question.
  5. E5 CHECK FOR CORRECT PARKING AID MODULE (PAM) OPERATION Ignition OFF. Disconnect and inspect all Parking Aid Module (PAM) connectors. Repair: corrosion (install new connector or terminals - clean module pins) damaged or bent pins - install new terminals/pins pushed-out pins - install new pins as necessary Reconnect the Parking Aid Module (PAM) connectors. Make sure they seat and latch correctly. Operate the system and determine if the concern is still present. Is the concern still present? Yes: CHECK OASIS for any applicable Technical Service Bulletins (TSBs). If a TSB exists for this concern, DISCONTINUE this test and FOLLOW TSB instructions. If no Technical Service Bulletins (TSBs) address this concern, INSTALL a new Parking Aid Module (PAM). For the 4-door, REFER to: «Parking Assist Control Module (PAM) - 4-Door»(ref-515935-S18282733842012120400000) . For the 5-door, REFER to: «Parking Assist Control Module (PAM) - 5-Door»(ref-515935-S31149311112012120400000) . No: The system is operating correctly at this time. Concern may have been caused by a loose or corroded connector. ADDRESS the root cause of any connector or pin issues.

B13B5:96, B1B44:96, B1B48:96

Diagnostics in this manual assume a certain skill level and knowledge of Ford-specific diagnostic practices.

REFER to: DIAGNOSTIC METHODS .

Refer to PARKING AID for schematic and connector information.

  1. Rear Parking aid sensor
  2. Parking Aid Module (PAM)

B1B36:12, B1B38:12, B1B40:12, B1B42:12

Diagnostics in this manual assume a certain skill level and knowledge of Ford-specific diagnostic practices.

REFER to: DIAGNOSTIC METHODS .

Refer to PARKING AID for schematic and connector information.

  1. Wiring, terminals or connectors
  2. Front parking aid sensor
  3. Parking Aid Module (PAM)

Scheme 27

Scheme 27: PINPOINT TEST G: B1B36:12, B1B38:12, B1B40:12, B1B42:12
Scheme 27: PINPOINT TEST G: B1B36:12, B1B38:12, B1B40:12, B1B42:12
  1. G1 RETRIEVE THE DIAGNOSTIC TROUBLE CODES (DTCS) FROM THE PARKING AID MODULE (PAM) SELF-TEST Using a scan tool, perform the Parking Aid Module (PAM) self-test. Check the Parking Aid Module (PAM) Diagnostic Trouble Codes (DTCs) from the self-test. Are multiple parking aid sensor Diagnostic Trouble Codes (DTCs) recorded? Yes: GO to G2 No: For Diagnostic Trouble Codes (DTCs) B1B36:12, B1B38:12, B1B40:12 or B1B42:12, GO to G3 For all other Diagnostic Trouble Codes (DTCs), REFER to the «PARKING AID MODULE (PAM) DTC CHART»(ref-515935-S24317435302012120400000) .
  2. G2 CHECK THE BUMPER WIRING HARNESS Inspect the bumper wiring harness for opens, shorts, grounds, or corrosion. Is the bumper wiring harness OK? Yes: GO to G3 No: REPAIR or INSTALL a new bumper wiring harness.
  3. G3 CHECK THE SENSOR CIRCUITRY FOR SHORTS TO VOLTAGE Ignition OFF. Disconnect: Suspect Parking Aid Sensor(s) Disconnect: Parking Aid Module (PAM) C4014B. Ignition ON. For DTC B1B36:12, measure: Click to display connectors Positive Lead Measurement / Action Negative Lead C1431-2 - For DTC B1B38:12, measure: Click to display connectors Positive Lead Measurement / Action Negative Lead C1430-2 - For DTC B1B40:12, measure: Click to display connectors Positive Lead Measurement / Action Negative Lead C1428-2 - For DTC B1B42:12, measure: Click to display connectors Positive Lead Measurement / Action Negative Lead C1429-2 - Is any voltage present? Yes: REPAIR the circuit in question. No: GO to G4
  4. G4 CHECK THE PARKING AID SENSOR CIRCUITRY FOR A SHORT TOGETHER For DTC B1B36:12, measure: Click to display connectors Positive Lead Measurement / Action Negative Lead C1431-2 ohms C1431-1 For DTC B1B38:12, measure: Click to display connectors Positive Lead Measurement / Action Negative Lead C1430-2 ohms C1430-1 For DTC B1B40:12, measure: Click to display connectors Positive Lead Measurement / Action Negative Lead C1428-2 ohms C1428-1 For DTC B1B42:12, measure: Click to display connectors Positive Lead Measurement / Action Negative Lead C1429-2 ohms C1429-1 Is the resistance greater than 10, 000 ohms? Yes: If all the sensor Diagnostic Trouble Codes (DTCs) are set, GO to G5 If one or more (but not all) parking aid sensor(s) recorded Diagnostic Trouble Codes (DTCs), INSTALL a new sensor(s) for the one in question. REFER to: «Front Parking Aid Sensor»(ref-515935-S17037486842012120400000) . No: REPAIR the circuits in question.
  5. G5 CHECK FOR CORRECT PARKING AID MODULE (PAM) OPERATION Ignition OFF. Disconnect and inspect all Parking Aid Module (PAM) connectors. Repair: corrosion (install new connector or terminals - clean module pins) damaged or bent pins - install new terminals/pins pushed-out pins - install new pins as necessary Reconnect the Parking Aid Module (PAM) connectors. Make sure they seat and latch correctly. Operate the system and determine if the concern is still present. Is the concern still present? Yes: CHECK OASIS for any applicable Technical Service Bulletins (TSBs). If a TSB exists for this concern, DISCONTINUE this test and FOLLOW TSB instructions. If no Technical Service Bulletins (TSBs) address this concern, INSTALL a new Parking Aid Module (PAM). For the 4-door, REFER to: «Parking Assist Control Module (PAM) - 4-Door»(ref-515935-S18282733842012120400000) . For the 5-door, REFER to: «Parking Assist Control Module (PAM) - 5-Door»(ref-515935-S31149311112012120400000) . No: The system is operating correctly at this time. Concern may have been caused by a loose or corroded connector. ADDRESS the root cause of any connector or pin issues.

B1B36:14, B1B38:14, B1B40:14, B1B42:14

Diagnostics in this manual assume a certain skill level and knowledge of Ford-specific diagnostic practices.

REFER to: DIAGNOSTIC METHODS .

Refer to PARKING AID for schematic and connector information.

  1. Wiring, terminals or connectors
  2. Front parking aid sensor
  3. Parking Aid Module (PAM)

B1B36:96, B1B38:96, B1B40:96, B1B42:96

Diagnostics in this manual assume a certain skill level and knowledge of Ford-specific diagnostic practices.

REFER to: DIAGNOSTIC METHODS .

Refer to PARKING AID for schematic and connector information.

  1. Front parking aid sensor
  2. Parking Aid Module (PAM)

The Parking Aid Switch Status LED Is Inoperative Or Always On

Diagnostics in this manual assume a certain skill level and knowledge of Ford-specific diagnostic practices.

REFER to: DIAGNOSTIC METHODS .

Refer to PARKING AID for schematic and connector information.

  1. Wiring, terminals or connectors
  2. Parking Aid Module (PAM)
  3. Parking aid switch (integral to the active park assist switch)

The Parking Aid Disable Switch Does Not Operate Correctly

Diagnostics in this manual assume a certain skill level and knowledge of Ford-specific diagnostic practices.

REFER to: DIAGNOSTIC METHODS .

Refer to PARKING AID for schematic and connector information.

  1. Wiring, terminals or connectors
  2. Parking Aid Module (PAM)
  3. Parking aid switch (integral to the active park assist switch)
  1. Communication concern
  2. Parking Aid Module (PAM)
  3. PCM
  1. Communication concern
  2. TCM
  3. Parking Aid Module (PAM)
  1. Communication concern
  2. ABS module
  3. Parking Aid Module (PAM)
  1. Communication concern
  2. SASM
  3. Parking Aid Module (PAM)
  1. Communication concern
  2. PSCM
  3. Parking Aid Module (PAM)
  1. Communication concern
  2. BCM
  3. Parking Aid Module (PAM)
  1. Charging system concern.
  2. Parking Aid Module (PAM)

The Rear Video Is Inoperative

Diagnostics in this manual assume a certain skill level and knowledge of Ford-specific diagnostic practices.

REFER to: DIAGNOSTIC METHODS .

Refer to PARKING AID for schematic and connector information.

  1. Wiring, terminals or connectors
  2. Video camera
  3. FCDIM (vehicles with 4.2-inch (107-mm) display)
  4. FDIM (vehicles with 8-inch (203-mm) touchscreen
  5. BCM
  6. Image Processing Module - B (IPM-B)

Poor Image Quality

Diagnostics in this manual assume a certain skill level and knowledge of Ford-specific diagnostic practices.

REFER to: DIAGNOSTIC METHODS .

Refer to PARKING AID for schematic and connector information.

  1. Wiring, terminals or connectors
  2. Video camera

The Visual Park Aid Alert Is Inoperative

Diagnostics in this manual assume a certain skill level and knowledge of Ford-specific diagnostic practices.

REFER to: DIAGNOSTIC METHODS .

Refer to PARKING AID for schematic and connector information.

  1. Video camera
  2. Parking Aid Module (PAM) concern
  3. Image Processing Module - B (IPM-B) concern

Visual Inspection and Diagnostic Pre-checks

Verify that the visual park aid is enabled in the FDIM (with 8-inch (203-mm) touchscreen) or FCDIM (with 4.2-inch (107-mm) touchscreen).

The Video Delay Or Guidelines Are Inoperative

Diagnostics in this manual assume a certain skill level and knowledge of Ford-specific diagnostic practices.

REFER to: DIAGNOSTIC METHODS .

Refer to PARKING AID for schematic and connector information.

  1. Video camera
  2. APIM concern (vehicles with 8-inch (203-mm) touchscreen)
  3. FCDIM concern (vehicles with 4.2-inch (107-mm) display)
  4. Image Processing Module - B (IPM-B) concern
  1. Communication Concern
  2. IPC
  3. Image Processing Module - B (IPM-B)
  1. Wiring, terminals or connectors
  2. Battery
  3. Charging system
  4. Image Processing Module - B (IPM-B)
  1. Charging system
  2. Image Processing Module - B (IPM-B)
  1. Communication concern
  2. BCM
  3. Image Processing Module - B (IPM-B)

Manual Zoom Function Is Inoperative

Diagnostics in this manual assume a certain skill level and knowledge of Ford-specific diagnostic practices.

REFER to: DIAGNOSTIC METHODS .

  1. Video camera

Azimuth System Check

  1. Turn the ignition switch to the ON position, engine off.
  2. Apply the parking brake.
  3. Place the gear shift in REVERSE (R) for rear parking aid.
  4. Place the gear shift in DRIVE (D) for front parking aid.
  5. Verify that the PAM detects the objects when placed in the 5 specified locations (P1, P2, P3, P4 and P5).

Scheme 28

Scheme 28: Elevation System Check
Scheme 28: Elevation System Check
  1. Turn the ignition ON, engine OFF.
  2. Set the parking brake.
  3. Place the gearshift in REVERSE (R) for rear parking aid sensors.
  4. Place the gearshift in DRIVE (D) for front parking aid sensors.
  5. Verify no audible alerts are heard. If audible alerts are heard, check to make sure the bumper is correctly installed and is not tilted downward so the sensor is pointing at the ground.
  6. If the audible warning tone is heard, Refer to: «Parking Aid»(ref-515935-S24827745712012120400000) .

More articles — Parking Aid - Except Electric
