Parking Aid - Except Electric: Removal & Installation Ford Focus III

Removal

Note. Removal steps in this procedure may contain installation details.

Scheme 6

1. WARNING: Before beginning any service procedure in this service information, refer to Safety Warnings in «SERVICE INFORMATION»(ref-515929) General Information. Failure to follow this instruction may result in serious personal injury.
2. Remove the rear bumper cover. Refer to: «REAR BUMPER COVER - 5-DOOR»(ref-516014-S09679429972012120400000) .

Installation

1. To install, reverse the removal procedure.
2. Carry out the azimuth and elevation system check. Refer to: «AZIMUTH SYSTEM CHECK»(ref-515936-S09197624862012120400000) . Refer to: «Elevation System Check»(ref-515935-S17770743442012120400000) .

Note. Removal steps in this procedure may contain installation details.

Scheme 7

1. WARNING: Before beginning any service procedure in this service information, refer to Safety Warnings in «SERVICE INFORMATION»(ref-515929) General Information. Failure to follow this instruction may result in serious personal injury.
2. Remove the liftgate release handle.

1. To install, reverse the removal procedure.
2. Verify camera operation. If the displayed image is inverted, place the ignition ON and leave on for 5 minutes to allow the Image Processing Module - B (IPM-B) to configure the camera.

Note. Removal steps in this procedure may contain installation details.

Scheme 8

1. Refer to: «HEALTH AND SAFETY PRECAUTIONS»(ref-515929-S17418754162012120400000) .
2. Remove the luggage compartment release handle.

1. To install, reverse the removal procedure.
2. Verify camera operation. If the displayed image is inverted, place the ignition ON and leave on for 5 minutes to allow the IPMB to configure the camera.

Note. Removal steps in this procedure may contain installation details.

Scheme 9

Scheme 10

Scheme 11

Scheme 12

1. Refer to: «HEALTH AND SAFETY PRECAUTIONS»(ref-515929-S17418754162012120400000) .
2. If a new module is being installed, upload the module configuration information from the IPMB into the scan tool by following the instructions on the scan tool.
3. If equipped, remove the subwoofer. Refer to: «SUBWOOFER SPEAKER»(ref-515933-S08673789182012120400000) .

1. To install, reverse the removal procedure.

Note. Removal steps in this procedure may contain installation details.

Scheme 13

1. Refer to: «HEALTH AND SAFETY PRECAUTIONS»(ref-515929-S17418754162012120400000) .
2. If a new module is being installed, upload the module configuration information from the IPMB into the scan tool by following the instructions on the scan tool.
3. If equipped, remove the subwoofer. Refer to: «SUBWOOFER SPEAKER»(ref-515933-S08673789182012120400000) .

1. To install, reverse the removal procedure.

Note. The removal steps in this procedure may include installation details

Note. If the eleventh VIN character (assembly plant code) is L, (Michigan Assembly - Wayne, Michigan), module configuration (PMI) is required when new module is installed. Other vehicles do not require PMI. If a new module will be installed and the eleventh VIN character is L, upload the module configuration to the scan tool by following the instructions on the scan tool.

Scheme 14

Scheme 15

Scheme 16

Scheme 17

Scheme 18

Scheme 19

Scheme 20

Scheme 21

1. Refer to: «HEALTH AND SAFETY PRECAUTIONS»(ref-515929-S17418754162012120400000) .
2. If equipped, remove the subwoofer. Refer to: «SUBWOOFER SPEAKER»(ref-515933-S08673789182012120400000) .
3. NOTE: Four door vehicle shown in illustration, five door similar.
4. Remove the upper C-pillar trim panel. Refer to: «C-PILLAR UPPER TRIM PANEL»(ref-516015-S24024674432012120400000) .
5. Vehicle equipped with bench rear seat.
6. Vehicles equipped with 60/40 rear seat.
7. Vehicles equipped with 60/40 rear seat.

1. To install, reverse the removal procedure.

Note. The removal steps in this procedure may include installation details

Note. If the eleventh VIN character (assembly plant code) is L, (Michigan Assembly - Wayne, Michigan), module configuration (PMI) is required when new module is installed. Other vehicles do not require PMI. If a new module will be installed and the eleventh VIN character is L, upload the module configuration to the scan tool by following the instructions on the scan tool.

Scheme 22

1. Refer to: «HEALTH AND SAFETY PRECAUTIONS»(ref-515929-S17418754162012120400000) .
2. If equipped, remove the subwoofer. Refer to: «SUBWOOFER SPEAKER»(ref-515933-S08673789182012120400000) .
3. NOTE: Four door vehicle shown in illustration, five door similar.
4. Remove the upper C-pillar trim panel. Refer to: «C-PILLAR UPPER TRIM PANEL»(ref-516015-S24024674432012120400000) .
5. Vehicle equipped with bench rear seat.
6. Vehicles equipped with 60/40 rear seat.
7. Vehicles equipped with 60/40 rear seat.

1. To install, reverse the removal procedure.

Note. Removal steps in this procedure may contain installation details.

Note. LH inner front parking aid sensor shown in illustration, all others similar.

Scheme 23

1. Remove the front bumper cover. Refer to: «FRONT BUMPER COVER»(ref-516014-S21426711892012120400000) .

1. To install, reverse the removal procedure.
2. After installing the sensor(s), use the scan tool to verify that the active park assist sensor PIDs are responding correctly. Carry out the Azimuth System check and the Elevation System check. Refer to: «Azimuth System Check»(ref-515935-S14337383492012120400000) . Refer to: «Elevation System Check»(ref-515935-S17770743442012120400000) .
3. If the active park assist sensor does not respond correctly. Refer to: «Parking Aid»(ref-515935-S24827745712012120400000) .
