Specifications
| Item | Specification |
|---|---|
| Active park assist sensor azimuth system check object position 1 (P1) distance from sensor | 508 mm (20 in) ± 101.6 mm (4 in) |
| Active park assist sensor azimuth system check object position 2 (P2) and position 3 (P3), distance from sensor | 3, 911.6 mm (154 in) ± 203.2 mm (8 in) |
| Front park assist sensor azimuth system check object position 1 (P1) and position 4 (P4), distance from sensor | 610 mm (24 in) |
| Front park assist sensor azimuth system check object position 2 (P2) and position 3 (P3), distance from sensor | 711 mm (28 in) |
| Rear park assist sensor azimuth system check object position 1 (P1) and position 3 (P3), distance from sensor | 610 mm (24 in) |
| Rear park assist sensor azimuth system check object position 2 (P2), distance from sensor 1, 829 mm | (72 in) |
GENERAL SPECIFICATIONS
Scheme 1
| Item | Description |
|---|---|
| 1 | Speaker, rear door (part of audio system) |
| 2 | Parking Aid Module (PAM) |
| 3 | Parking aid sensors, rear |
| 4 | Speaker, front door (park of audio system) |
| 5 | Parking aid disable switch (if equipped) |
| 6 | Parking aid sensors, front (if equipped) |
Scheme 2
| Item | Description |
|---|---|
| 1 | FDIM |
| 2 | Image Processing Module - B (IPM-B) |
| 3 | Video camera |
