Overview
The 2.0L Gasoline Turbocharged Direct Injection (GTDI) 4-cylinder engine has the following features
- Dual overhead camshafts
- Four valves per cylinder
- Composite intake manifold
- Aluminum cylinder head
- Aluminum cylinder block
- GTDI
- Twin Independent Variable Camshaft Timing (Ti-VCT)
Engine Identification
Always refer to these labels when installation of new parts is necessary or when checking engine calibrations. The engine parts often differ within a CID family. Verification of the identification codes will make sure the correct parts are obtained. These codes contain all the pertinent information relating to the dates, optional equipment and revisions.
Scheme 301
| Item | Description |
|---|---|
| 1 | Engine part number |
| 2 | Valencia Engine Plant |
| 3 | Plant code |
| 4 | Engine serial number |
| 5 | Engine displacement |
| 6 | Engine build date YYM (A-L)DD |
Scheme 302
Scheme 303
| Item | Description |
|---|---|
| 1 | Oil pump screen and pickup tube |
| 2 | Oil pump |
| 3 | Turbocharger oil return tube |
| 4 | Turbocharger oil return tube gasket |
| 5 | Timing chain tensioner |
| 6 | Turbocharger oil filter |
| 7 | Cylinder block |
| 8 | Turbocharger oil supply tube |
| 9 | Turbocharger |
| 10 | Intake VCT phaser and sprocket |
| 11 | Exhaust VCT phaser and sprocket |
| 12 | Exhaust camshaft |
| 13 | Camshaft front bearing cap (part of 6049) |
| 14 | VCT oil control solenoid |
| 15 | VCT oil control solenoid |
| 16 | Camshaft rear bearing cap (part of 6049) |
| 17 | Fuel pump housing |
| 18 | Intake camshaft |
| 19 | Vacuum pump |
| 20 | Cylinder head |
| 21 | Head gasket |
| 22 | Crankcase vent oil separator |
| 23 | Oil filter adapter gasket |
| 24 | Oil cooler |
| 25 | EOP switch |
| 26 | Oil Filter Adapter |
| 27 | Oil filter |
| 28 | Crankshaft assembly |
| 29 | Balance shaft assembly |
| 30 | Oil pan |
