Engine - 2.0L Ecoboost: Specifications Ford Focus III

Mechanical 3 illustrations ~108 words

ENGINE SPECIFICATIONS

ItemSpecification
Displacement122in 3 (2 L)
No. of cylinders4
Bore3.4449 in (87.5 mm)
Stroke3.2717 in (83.1 mm)
Firing order1-3-4-2
Compression ratio9.3:1
Spark plugNGK T4025R
Spark plug gap0.031 in (.8 mm)
Engine weight - (without accessory drive components and flywheel)311 lb (141 kg)

ENGINE SPECIFICATIONS

LUBRICANTS SPECIFICATIONS

ItemSpecification
Motorcraft® SAE 5W-30 Premium Synthetic Blend Motor Oil (US); Motorcraft® SAE 5W-30 Super Premium Motor Oil (Canada) XO-5W30-QSP (US); CXO-5W30-LSP12 (Canada); or equivalentWSS-M2C946-A, 5W30

LUBRICANTS SPECIFICATIONS

ENGINE OIL CAPACITY SPECIFICATIONS

ItemSpecification
Service fill including oil filter5.7 qt (5.4 L)

ENGINE OIL CAPACITY SPECIFICATIONS

OIL PRESSURE SPECIFICATIONS

ItemSpecification
Oil pressure (hot @ 2, 000 rpm)29-60 psi (200-414 kPa)

OIL PRESSURE SPECIFICATIONS

CYLINDER BLOCK SPECIFICATIONS

ItemSpecification
Cylinder bore diameter3.4449-3.4461 in (87.5-87.53 mm)
Cylinder bore maximum out-of-round0.0003 in (.008 mm)
Main bearing bore diameter2.245-2.246 in (57.018-57.04 mm)
Head gasket surface flatness0.1 mm (0.0039 in) - 0.05 mm (0.002 in)/200 mm (7.874 in) x 200 mm (7.874 in)

CYLINDER BLOCK SPECIFICATIONS

PISTON SPECIFICATIONS

ItemSpecification
Piston diameter (grade 1)3.4435-3.4439 in (87.465-87.475 mm)
Piston diameter (grade 2)3.4438-3.4444 in (87.4725-87.4875 mm)
Piston diameter (grade 3)3.4443-3.4447 in (87.485-87.495 mm)
Piston-to-bore clearance0.0009-0.0019 in (.0225-.0475 mm)
Piston ring groove width - compression (top)0.0484-0.0492 in (1.23-1.25 mm)
Piston ring groove width - compression (bottom)0.0484-0.0492 in (1.23-1.25 mm)
Piston ring groove width - oil0.0799-0.0807 in (2.03-2.05 mm)
Piston skirt coating thickness0.0004-0.0007 in (.009-.019 mm)

PISTON SPECIFICATIONS

PISTON PIN SPECIFICATIONS

ItemSpecification
Diameter0.8857-0.8858 in (22.497-22.5 mm)
Length2.1929-2.2047 in (55.7-56 mm)
Piston-to-pin clearance0.0001-0.0005 in (.0035-.0115 mm)
Piston pin-to-connecting rod clearance0.0004-0.0007 in (.01-.019 mm)
Piston ring width - compression (top)0.05 in (1.2 mm)
Piston ring width - compression (bottom)0.05 in (1.2 mm)
Piston ring width - oil0.08 in (2 mm)
Piston ring gap (in bore) - compression (top)0.0067-0.0106 in (.17-.27 mm)
Piston ring gap (in bore) - compression (bottom)0.0177-0.0256 in (.45-.65 mm)
Piston ring gap (in bore) - oil0.0059-0.0177 in (.15-.45 mm)
Connecting rod bearing-to-crankshaft clearance0.0011-0.0020 in (.027-.052 mm)
Connecting rod bearing thickness0.0589-0.0598 in (1.495-1.519 mm)
Connecting rod crankshaft bore diameter2.1663-2.1671 in (55.025-55.045 mm)
Connecting rod pin bore diameter0.8862-0.8865 in (22.51-22.516 mm)
Connecting rod length (center-to-center)6.1366 in (155.869 mm)
Connecting rod side clearance (assembled-to-crankshaft)0.1020-0.1453 in (2.59-3.69 mm)
Axial clearance0.0055-0.0142 in (.14-.36 mm)

PISTON PIN SPECIFICATIONS

CRANKSHAFT SPECIFICATIONS

ItemSpecification
Main bearing journal diameter2.0464-2.0473 in (51.978-52.002 mm)
Main bearing clearance0.0006-0.0018 in (.016-.046 mm)
Connecting rod journal diameter2.0464-2.0473 in (51.978-52.002 mm)
End play0.0087-0.0177 in (.22-.45 mm)

CRANKSHAFT SPECIFICATIONS

CYLINDER HEAD SPECIFICATIONS

ItemSpecification
Cylinder head flatness0.08 mm (0.0031 in) maxim overall, a maximum of 0.05 mm (0.0020 in) within 150 mm (5.9055 in) and a maximum of 0.025 mm (0.0010 in) within 25 mm (0.9843 in)
Maximum valve lift @ zero lash (exhaust)0.291 in (7.4 mm)
Maximum valve lift @ zero lash (intake)0.327 in (8.3 mm)
Valve guide diameter0.2169-0.2181 in (5.509-5.539 mm)
Valve seat width - intake/exhaust0.0551-0.0591 in (1.4-1.5 mm)
Valve seat angle45
Valve seat runout0.003 in (.075 mm)
Valve tappet bore diameter1.2205-1.2217 in (31-31.03 mm)
Cam bore diameter0.9848-0.9858 in (25.015-25.04 mm)

CYLINDER HEAD SPECIFICATIONS

VALVE SPECIFICATIONS

ItemSpecification
Valve head diameter - intake1.2795 in (32.5 mm)
Valve head diameter - exhaust1.1024 in (28 mm)
Valve stem diameter - intake0.2165 in (5.5 mm)
Valve stem diameter - exhaust0.2165 in (5.5 mm)
Valve stem-to-guide clearance - intake0.0012-0.0028 in (.03-.07 mm)
Valve stem-to-guide clearance - exhaust0.0012-0.0028 in (, 03-, 07 mm)
Valve face runout0.002 in (.05 mm)
Valve face angle44.67-45

VALVE SPECIFICATIONS

VALVE SPRING - COMPRESSION PRESSURE SPECIFICATIONS

ItemSpecification
Intake and exhaust (installed)40 lb (18 kg)
Intake (valve open) 9.2 mm (0.3622 in) of lift101 lb (46 kg)
Exhaust (valve open) 9.2 mm (0.3622 in) of lift101 lb (46 kg)
Free length1.8860 in (47.904 mm)
Assembled height1.4921 in (37.9 mm)

VALVE SPRING - COMPRESSION PRESSURE

VALVE TAPPET SPECIFICATIONS

ItemSpecification
Diameter1.2197-1.2191 in (30.98-30.964 mm)
Tappet-to-valve clearance - intake0.0075-0.0122 in (.19-.31 mm)
Tappet-to-valve clearance - exhaust0.0118-0.0165 in (.3-.42 mm)
Tappet-to-bore clearance0.0008-0.0024 in (, 02-, 06 mm)

VALVE TAPPET SPECIFICATIONS

CAMSHAFT SPECIFICATIONS

ItemSpecification
Lobe lift - intake0.327 in (8.3 mm)
Lobe lift - exhaust0.291 in (7.4 mm)
Runout0.0012 in (.03 mm)
Thrust clearance0.0045-0.0057 in (.115-.145 mm)
Journal diameter0.9827-0.9835 in (24.96-24.98 mm)
Journal-to-bore clearance0.0014-0.0031 in (.035-.08 mm)

CAMSHAFT SPECIFICATIONS

Scheme 298

Scheme 298: Engine - External Components
Scheme 298: Engine - External Components
ItemPart NumberDescription
18509Coolant pump pulley
26K682Turbocharger
39C374Fuel injection pump cover
49D376Fuel injection pump
58K556Coolant outlet
62A451Brake vacuum pump
76477Flywheel
89F797Fuel rail
99424Intake manifold
108575Thermostat assembly

Scheme 299

Scheme 299: Engine - Front and Upper Components
Scheme 299: Engine - Front and Upper Components
ItemPart NumberDescription
16K340Crankshaft pulley bolt
26316Crankshaft damper
36019Engine front cover
46378Diamond washer
56K254Timing chain tensioner
66K255Timing chain tensioner arm
76268Timing chain
86A895Oil pump chain
96C271Oil pump chain tensioner
106622Oil pump screen and pickup tube
116652Oil pump drive gear
126600Oil pump
136K297Timing chain guide
146306Crankshaft sprocket
158501Coolant pump
166378Diamond washer
176051Head gasket
186049Cylinder head
196500Valve tappet (16 required)
206C524Intake VCT phaser and sprocket
216C525Exhaust VCT phaser and sprocket
226278Washer
236278Washer
246A272Camshaft (exhaust)
25Camshaft front bearing cap (part of 6049)
266K271Valve cover
27Camshaft bearing cap (part of 6049) (8 required)
28Exhaust camshaft rear bearing cap (part of 6049)
29Intake camshaft rear bearing cap (part of 6049)
306K269Brake vacuum pump adapter
316A271Camshaft (intake)
322A451Brake vacuum pump
336K318Crankshaft rear oil seal and retainer
346A642Oil cooler
356A636Oil filter adapter gasket
366A785Crankcase vent oil separator
376881Oil filter adapter
386714Oil filter
396675Oil pan

Scheme 300

Scheme 300: Engine - Lower Block Components
Scheme 300: Engine - Lower Block Components
ItemPart NumberDescription
16K360Balance shaft assembly
2Main bearing beam (part of 6010)
36A338Crankshaft main bearing beam bearing (5 required)
46300Crankshaft assembly
56333Cylinder block crankshaft main bearing (4 required)
66337Cylinder block crankshaft main thrust bearing
76110Piston (4 required)
