Engine - 2.0L Zetec: Specifications Ford Focus I рестайлинг

Mechanical 3 illustrations ~267 words

ENGINE DATA SPECIFICATIONS

Description2.0L DOHC 16V
Engine managementEEC V/SEFI
Emission standard96 EEC
Fuel91 RON unleaded
Identification codeCAA
Firing order1-3-4-2
Bore84.8 mm
Stroke88.0 mm
Cubic capacity1,988 cm 3
Compression ratio9.6:1
Maximum engine performance at 5,300 rpm130 hp
Maximum engine torque at 4,000 rpm130 lb ft
Idle speed rpm800 rpm
Speed limitation (rev/min)7,100 rpm

ENGINE DATA SPECIFICATIONS

ENGINE OIL SPECIFICATIONS

Viscosity/ambient temperatureDescriptionSpecification
Recommended engine oils
SAE 5W-20/below -30°C to over +40°CSAE 5W-20 Engine Oil certified for gasoline engines by the American Petroleum InstituteILSAC GF-3 and WSS-M2C153-H
SAE 5W-20/below -30°C to over +40°CFord Formula E Economy Engine OilACEA A1/B1 and WSS-M2C914-A

ENGINE OIL SPECIFICATIONS

If engine oils of this specification are not available, engine oils of specification API SH/EC, ACEA A2/B2 or ACEA A3/B3 may also be used.

CAPACITIES SPECIFICATIONS

DescriptionLiters
Engine oil, initial fill including filter4.35
Engine oil, oil change including filter4.25
Engine oil, oil change excluding filter3.75

CAPACITIES SPECIFICATIONS

LUBRICANTS, FLUIDS, SEALERS AND ADHESIVES SPECIFICATIONS

ItemSpecification
Sealant, camshaft bearing capsWSK-M2G348-A5
Sealant, cylinder block mating faces (Hylosil 502)WSK-M4G320-A
Sealant, cylinder block mating faces (Loctite Ultrablack) (alternative)WSE-M4G320-A2
Sealant, crankshaft position sensorESW-1C155-A
Sealant, crankshaft position sensor (alternative)WSD-M1C-226-A
Sealant, oil panWSE-M4G323-A6
Thread locking compoundSDM-M4G9107-A
Spark plug thread lubricant (Never Seeze)WSD-M13P8-A1
Lubricant, injection nozzle O-ringsWSEM-2C903-A1
Silicone grease for spark plug connector sealA696-M1C171-AA
High-temperature grease for clutch disc engagement splinesESD-M1C220-A

LUBRICANTS, FLUIDS, SEALERS AND ADHESIVES SPECIFICATIONS

CYLINDER BLOCK SPECIFICATIONS

DescriptionMm
Cylinder bore diameter, class 184.800-84.810
Cylinder bore diameter, class 284.810-84.820
Cylinder bore diameter, class 384.820-84.830
Inner diameter, main bearing shells installed58.011-58.038
Inner diameter, main bearing shells installed (main bearing shells with stepped sizes)58.008-58.031
Main bearing radial clearance0.011-0.058
Main bearing radial clearance (main bearing shells with stepped sizes)0.020-0.042
Main bearing parent bore62.287-62.300

CYLINDER BLOCK SPECIFICATIONS

PISTONS SPECIFICATIONS

DescriptionMm
Piston diameter, class 1.84.770-84.780
Piston diameter, class 2.84.780-84.790
Piston diameter, class 3.84.790-84.800
Piston clearance in cylinder0.010-0.030
Piston ring gaps (installed) (1)
Upper compression ring0.30-0.50
Lower compression ring0.30-0.50
Oil scraper ring0.40-1.40
(1) The piston ring gaps must be distributed evenly around the circumference of the piston This also applies to the oil scraper ring elements. Align the ring gaps at 120 degrees to each other.
(1)The piston ring gaps must be distributed evenly around the circumference of the piston This also applies to the oil scraper ring elements. Align the ring gaps at 120 degrees to each other.

PISTONS SPECIFICATIONS

CRANKSHAFT SPECIFICATIONS

DescriptionMm
Main bearing journal diameter57.980-58.000
Main bearing journal end float0.09-0.26
Connecting rod bearing journal diameter46.89-46.91

CRANKSHAFT SPECIFICATIONS

LOWER CRANKSHAFT SPACER SPECIFICATIONS

DescriptionMm
Required spacer washer thickness if there is a gap between the cylinder block and the lower crankcase of
0.26 mm-0.50 mm0.25
0.51 mm-0.75 mm0.50

LOWER CRANKSHAFT SPACER SPECIFICATIONS

CONNECTING ROD SPECIFICATIONS

DescriptionMm
Big end bore diameter49.89-49.91
Small end bore diameter19.951-19.981
Inner diameter, connecting rod bearing shells installed46.926-46.960
Radial connecting rod bearing clearance0.016-0.070
Axial connecting rod bearing clearance0.090-0.320

CONNECTING ROD SPECIFICATIONS

PISTON PIN SPECIFICATIONS

DescriptionMm
Piston pin length55.800-56.200
Piston pin diameter, white19.997-20.000
Piston pin diameter, red20.625-20.628
Piston pin clearance in piston0.016-0.049

PISTON PIN SPECIFICATIONS

CAMSHAFT SPECIFICATIONS

DescriptionMm
Bearing journal diameter25.960-25.980
Camshaft bearing radial clearance0.020-0.070
Camshaft end float0.080-0.220
Lobe lift intake8.90
Lobe lift exhaust8.70
Theoretical valve maximum lift intake8.90
Theoretical valve maximum lift exhaust8.70

CAMSHAFT SPECIFICATIONS

VALVES SPECIFICATIONS

DescriptionMm
Valve clearance in the valve guide
Intake valve0.017-0.064
Exhaust valve0.017-0.064
Intake valve clearance (at 20°C +/- 5°C)0.11-0.18
Exhaust valve clearance (at 20°C +/- 5°C)0.27-0.34

VALVES SPECIFICATIONS

CYLINDER HEAD SPECIFICATIONS

DescriptionSpecification
Maximum distortion (mating surface)0.1 mm
Height of mating surface1.76 mm-2.12 mm
Peak-to-valley height of mating surface (reference length 2.5 mm vertical to groove direction)R 3z = 6.0 microns
Oil pressure at 800-850 rpm1.3 bar-2.5 bar
Oil pressure at 4000 rpm3.7 bar-5.5 bar

CYLINDER HEAD SPECIFICATIONS

TORQUE SPECIFICATIONS

DescriptionNmLb-ftLb-in
Hose clamps435
Intake manifold studs544
Intake manifold bolts and nuts1813
EGR tube assembly to EGR valve4030
EGR pipe to ignition coil bracket653
EGR tube assembly to catalyst4030
Heat shield to exhaust manifold1089
Exhaust manifold studs544
Exhaust manifold nuts1612
Catalytic converter to exhaust manifold4835
Catalytic converter to exhaust4735
Right-hand driveshaft center bearing2518
Generator to bracket2518
Generator bracket to upper cylinder block bolts2518
Generator bracket to lower cylinder block bolts6548
Transmission flange bolts4735
Starter motor to transmission3526
Oil drain plug, MTX transmission4533
Oil control plug, MTX transmission4533
Flywheel bolts11283
Clutch pressure plate2921
Engine roll restrictor to transmission4835
Engine roll restrictor to subframe4835
Engine rear mount to body4835
Engine rear mount (nut on transmission mounting bracket)13398
Engine front mount to engine8059
Engine front mount to body4835
Power steering pump to bracket2418
Power steering pump bracket4835
Cylinder head bolts (1)
Camshaft bearing cap bolts (1)
Cylinder head cover (1)
Spark plugs1511
Timing belt tensioner2518
Camshaft timing belt pulleys6850
Upper timing belt cover1089
Ignition coil (EI) bracket to cylinder head2115
Thermostat housing2015
Fuel rail1089
Engine rear lifting eye1612
Engine rear lifting eye studs653
Engine front lifting eye4735
Cylinder block (1)
Engine oil drain plug2518
Oil pressure switch2720
Cylinder block oil gallery blanking plugs2317
Heater pipe bracket to oil pan1089
Oil pan to lower crankcase (1)
Lower crankcase to cylinder block2216
Oil pump118
Oil intake pipe to oil pump1089
Main bearing bolts (1)
Connecting rod bearing cap bolts (1)
Coolant pump1813
Crankshaft rear oil seal carrier2015
Drive belt idler pulley4030
Crankcase ventilation pipe bracket2317
Crankcase ventilation1089
Coolant pump pulley2418
Crankshaft belt pulley11585
Crankshaft position sensor bracket2115
Crankshaft position sensor to bracket871
Idler pulley2317
Knock sensor2015
(1) Refer to the procedure in this article.
(1)Refer to the procedure in this article.

TORQUE SPECIFICATIONS

Scheme 32

Scheme 32: Engine
Scheme 32: Engine

The vehicle range is fitted with the "New Generation 2.0L Zetec-E engine". The most significant features are

  1. Hydraulic engine mountings
  2. 16 valve DOHC
  3. Full flow oil filter
  4. Aluminum alloy cylinder head
  5. Cast iron block
  6. High temperature resistant coating on exhaust valves
  7. Valve train with mechanical tappets
  8. Modified timing belt guide
  9. Aluminum timing belt cover with integral engine mounting function to reduce noise, vibration and harshness (NVH)
  10. Aluminum crankcase reinforcement and flat oil pan to reduce NVH
  11. Generator with check-back function for generator load

The changes made are

  1. close coupled tri-metal catalytic converter
  2. EGR system
  3. Adjustable valve tappets
  4. use of a cylinder head temperature (CHT) sensor in place of an engine coolant temperature (ECT) sensor.

Scheme 33

Scheme 33: VIN Derivative Location On The Cylinder Block
Scheme 33: VIN Derivative Location On The Cylinder Block

Scheme 34

Scheme 34: Central Timing Belt Cover/Front Engine Mounting Bracket
Scheme 34: Central Timing Belt Cover/Front Engine Mounting Bracket

The new timing belt cover is further reinforced by a vertical support. The central timing belt cover and the front engine mounting have to be removed to fit a new timing belt.
