HVAC Climate Control System: Overhaul Ford Escape I рестайлинг 2

A/C Compressor and Clutch Assembly

Note. Internal A/C compressor components are not serviced separately. The A/C compressor is serviced only as an assembly. The A/C compressor clutch, A/C compressor pulley and A/C clutch field coil are serviceable.

Note. Installation of a new receiver/drier is not required when repairing the A/C system, except when there is physical evidence of contamination from a failed A/C compressor or damage to the receiver/drier.

The A/C compressor has the following characteristics

1. A non-serviceable shaft seal.
2. The A/C compressor uses PAG Refrigerant Compressor Oil (R-134a Systems) YN-12-D. This oil contains special additives required for the A/C compressor.
3. The A/C compressor oil in the A/C system may darken over time while maintaining normal oil viscosity. This is normal for A/C systems because of break-in wear and the addition of fluorescent leak detection dye that can discolor the oil.
4. Use the oil matching procedure specified for this vehicle when installing a new A/C compressor or any other A/C component. Refer to «CLIMATE CONTROL SYSTEM - GENERAL INFORMATION AND DIAGNOSTICS»(ref-344063) .

When battery voltage is applied to the A/C compressor clutch field coil, the clutch disc and hub assembly is drawn toward the A/C clutch pulley. The magnetic force locks the clutch disc and hub assembly and the A/C clutch pulley together as one unit, causing the compressor shaft to rotate. When battery voltage is removed from the A/C compressor clutch field coil, springs in the clutch disc and hub assembly move the clutch plate away from the A/C clutch pulley.

Disassembly and Assembly

Plenum chamber

1. Remove the 2 RH temperature blend door actuator screws. To install, tighten to 3 Nm (27 lb-in).
2. Detach the heater core and evaporator core housing wire harness from the plenum chamber.
3. Remove the 2 defrost/panel/floor mode door actuator screws. To install, tighten to 3 Nm (27 lb-in).
4. Remove the defrost/panel/floor mode door actuator.
5. Remove the 6 plenum chamber screws. To install, tighten to 3 Nm (27 lb-in).
6. Remove the plenum chamber. Air inlet duct
7. Detach the heater core and evaporator core housing wire harness from the air inlet duct.
8. Remove the 2 air inlet mode door actuator screws. To install, tighten to 3 Nm (27 lb-in).
9. Remove the air inlet mode door actuator. Complete disassembly
10. Detach and remove the heater core and evaporator core housing wire harness.
11. Remove the 2 blower motor speed control or blower motor resistor screws. To install, tighten to 3 Nm (27 lb-in).
12. Remove the blower motor speed control or blower motor resistor.
13. Remove the heater core tube dash panel seal.
14. Remove the heater core bracket screw and the heater core bracket. To install, tighten to 3 Nm (27 lb-in).
15. Remove the heater core.
16. Remove the Thermostatic Expansion Valve (TXV) dash panel seal.
17. Remove the heater core and evaporator core housing drain dash panel seal.
18. Remove the 2 LH temperature blend door actuator screws (if equipped).
19. Remove the LH temperature blend door actuator (if equipped).
20. Detach the 2 blower motor vent tube clips and disengage the vent tube from the heater core and evaporator core housing.
21. Rotate counterclockwise and remove the blower motor.
22. To assemble, reverse the disassembly procedure.

Scheme 218

ITEM DESCRIPTION

Scheme 219

ITEM DESCRIPTION

1. Remove the passenger airbag module. For additional information, refer to «SUPPLEMENTAL RESTRAINT SYSTEM»(ref-344095) .
2. Remove the Audio Control Module (ACM). For additional information, refer to «INFORMATION AND ENTERTAINMENT SYSTEMS»(ref-344106) .
3. Remove the Instrument Cluster (IC). For additional information, refer to «INSTRUMENTATION, MESSAGE CENTER, AND WARNING CHIMES»(ref-344081) .
4. Remove the instrument panel. For additional information, refer to «INSTRUMENT PANEL AND CONSOLE»(ref-344092) .
5. Remove the 4 defroster duct adapter screws and the defroster duct adapter.
6. Remove the 4 Front Display Interface Module (FDIM) screws and the FDIM. Disconnect the FDIM electrical connector.
7. Remove the 2 instrument cluster opening instrument panel trim screws.
8. Remove the 4 instrument panel trim-to-audio unit bracket screws.
9. Remove the 2 instrument panel trim-to-audio unit bracket nuts.
10. Remove the 3 glove compartment screws and the glove compartment.
11. Remove the 2 glove compartment latch striker screws and the glove compartment latch striker.
12. Remove the lower center instrument panel trim screw.
13. Remove the 4 lower steering column opening instrument panel trim screws.
14. Disconnect the headlamp switch and the message center switch electrical connectors.
15. Remove the 2 upper corner instrument panel trim screws.
16. Remove the 2 lower corner instrument panel trim screws.
17. Remove the 2 instrument panel support-to-defroster duct screws.
18. Remove the 4 LH duct assembly screws and remove the LH duct assembly.
19. Remove the 4 RH duct assembly screws and remove the RH duct assembly.
20. To assemble, reverse the assembly procedure.
