Automatic Transaxle - HF35: Removal & Installation Ford C-MAX II

Automatic Trans 20 illustrations ~628 words

Removal

WARNINGBefore beginning any service procedure in this article, refer to Safety Warnings in GENERAL INFORMATION . Failure to follow this instruction may result in serious personal injury.

Scheme 6

Scheme 6
Scheme 6

Scheme 7

Scheme 7
Scheme 7

Scheme 8

Scheme 8
Scheme 8
  1. Refer to: «HEALTH AND SAFETY PRECAUTIONS»(ref-635189-S18367805802014070200000) .
  2. Refer to: «JACKING AND LIFTING - OVERVIEW»(ref-635208-S40563097982014070200000) .
  3. Refer to: «FRONT HALFSHAFT LH»(ref-635230-S42232773372014070200000) .
  4. Use the General Equipment: Punch
  5. Use the General Equipment: Puller

Installation

Pinpoint Test C

C1 205-153 (T80T-4000-W) Handle
  1. click to open the image
C2 205-153 (T80T-4000-W) Handle
  1. click to open the image
WARNINGBefore beginning any service procedure in this article, refer to Safety Warnings in GENERAL INFORMATION . Failure to follow this instruction may result in serious personal injury.

Scheme 9

Scheme 9
Scheme 9

Scheme 10

Scheme 10
Scheme 10
  1. Refer to: «HEALTH AND SAFETY PRECAUTIONS»(ref-635189-S18367805802014070200000) .
  2. Refer to: «JACKING AND LIFTING - OVERVIEW»(ref-635208-S40563097982014070200000) .
  3. Refer to: «FRONT HALFSHAFT RH»(ref-635230-S23723533852014070200000) .
  4. Use the General Equipment: Punch
  5. Use the General Equipment: Puller

Pinpoint Test C

C1 205-153 (T80T-4000-W) Handle
  1. click to open the image
C2 205-153 (T80T-4000-W) Handle
  1. click to open the image

Note. If removing the TCM to install a new TCM, it is not necessary to remove the TCM mounting bracket. If removing the TCM to service another component, it may be necessary to remove the TCM mounting bracket.

Pinpoint Test C

C5 TCM
  1. NOTE: When disconnecting the high voltage cables from the TCM, cover the TCM terminals with tape or another waterproof seal to keep moisture, water or other fluids from entering the TCM. Failure to cover and seal the TCM terminals can result in damage to the TCM.
  2. Torque: 97 lb.in (11 Nm)
  3. click to open the image

Pinpoint Test C

C3 TCM
  1. Refer to: «TRANSMISSION STRATEGY DOWNLOAD»(ref-635215-S34342733852014070200000)
C4 TCM
  1. Refer to: «PASSIVE ANTI-THEFT SYSTEM (PATS) PARAMETER RESET»(ref-635240-S39090376022014070200000) .
WARNINGBefore beginning any service procedure in this article, refer to Safety Warnings in GENERAL INFORMATION . Failure to follow this instruction may result in serious personal injury.

Scheme 11

Scheme 11
Scheme 11

Scheme 12

Scheme 12
Scheme 12

Scheme 13

Scheme 13
Scheme 13

Scheme 14

Scheme 14
Scheme 14

Scheme 15

Scheme 15
Scheme 15

Scheme 16

Scheme 16
Scheme 16

Scheme 17

Scheme 17
Scheme 17

Scheme 18

Scheme 18
Scheme 18

Scheme 19

Scheme 19
Scheme 19
  1. Refer to: «HEALTH AND SAFETY PRECAUTIONS»(ref-635189-S18367805802014070200000) .
  2. Refer to: «TRANSMISSION»(ref-635215-S37151582242014070200000) .

Pinpoint Test C

C6 307-694 Installer, Manual Lever Seal
  1. click to open the image
WARNINGBefore beginning any service procedure in this article, refer to Safety Warnings in GENERAL INFORMATION . Failure to follow this instruction may result in serious personal injury.

Pinpoint Test C

C4 303-F072 Support Bar, Engine
  1. click to open the image

Pinpoint Test C

C2 303-F072 Support Bar, Engine
  1. click to open the image

Scheme 20

Scheme 20
Scheme 20
  1. Refer to: «JACKING AND LIFTING - OVERVIEW»(ref-635208-S40563097982014070200000) .
  2. Torque: 76 lb.ft (103 Nm) Torque: Stage 1: 35 lb.ft (48 Nm) Stage 2: 60° Torque: Stage 1: 59 lb.ft (80 Nm) Stage 2: 120 ° Torque: 92 lb.ft (125 Nm)
  1. To install, reverse the removal procedure.
WARNINGBefore beginning any service procedure in this article, refer to Safety Warnings in GENERAL INFORMATION . Failure to follow this instruction may result in serious personal injury.

Scheme 21

Scheme 21
Scheme 21

Scheme 22

Scheme 22
Scheme 22

Scheme 23

Scheme 23
Scheme 23
  1. Refer to: «HEALTH AND SAFETY PRECAUTIONS»(ref-635189-S18367805802014070200000) .

Pinpoint Test C

C2 307-694 Installer, Manual Lever Seal
  1. click to open the image
WARNINGBefore beginning any service procedure in this article, refer to Safety Warnings in GENERAL INFORMATION . Failure to follow this instruction may result in serious personal injury.

Note. The transmission cannot be removed from the vehicle separate from the engine. Refer to engine REMOVAL to remove the transmission. Separate the transmission from the engine following the additional steps in this procedure.

Pinpoint Test C

C5 All vehicles
  1. click to open the image
  2. All vehicles

All vehicles

Pinpoint Test C

C4 All vehicles
  1. Torque: 80 lb.in (9 Nm)
  2. Torque: 18 lb.ft (25 Nm)
  3. Torque: 80 lb.in (9 Nm) click to open the image
WARNINGBefore beginning any service procedure in this article, refer to Safety Warnings in GENERAL INFORMATION . Failure to follow this instruction may result in serious personal injury.

Scheme 24

Scheme 24
Scheme 24
  1. Refer to: «HEALTH AND SAFETY PRECAUTIONS»(ref-635189-S18367805802014070200000) .

Scheme 25

Scheme 25: Installation
Scheme 25: Installation
  1. Torque: 80 lb.in (9 Nm)
  2. Refer to: «TRANSMISSION FLUID DRAIN AND REFILL»(ref-635215-S18614222992014070200000) .
