Automatic Transaxle Cooling System - HF35: Removal & Installation Ford C-MAX II

Automatic Trans 6 illustrations ~290 words

Removal

WARNINGBefore beginning any service procedure in this article, refer to Safety Warnings in GENERAL INFORMATION . Failure to follow this instruction may result in serious personal injury.

Scheme 87

Scheme 87

Scheme 88

Scheme 88

Scheme 89

Scheme 89
  1. Refer to: «HEALTH AND SAFETY PRECAUTIONS»(ref-635189-S18367805802014070200000) .
  2. Refer to: «ACTIVE GRILLE SHUTTER»(ref-635237-S38052633542014070200000) .
  3. NOTE: Use a Jiffy-tite quick disconnect tool, close the tool around the tube, press the tool into the fitting and rotate until the tool is fully seated into the fitting.

Installation

  1. Backing ring (7J324) Seal (7D258) Material: Motorcraft® MERCON® LV Automatic Transmission Fluid (U.S.)/XT-10-QLVC (U.S.) (WSS-M2C938-A) (MERCON® LV)
  2. Torque: 80 lb.in (9 Nm)
  3. Backing ring (7J324) Seal (7D258) Material: Motorcraft® MERCON® LV Automatic Transmission Fluid (U.S.)/XT-10-QLVC (U.S.) (WSS-M2C938-A) (MERCON® LV)
  4. Torque: 80 lb.in (9 Nm)
  5. Backing ring (7J324) Seal (7D258) Material: Motorcraft® MERCON® LV Automatic Transmission Fluid (U.S.)/XT-10-QLVC (U.S.) (WSS-M2C938-A) (MERCON® LV)
  6. Torque: 80 lb.in (9 Nm)
  7. Backing ring (7J324) Seal (7D258) Material: Motorcraft® MERCON® LV Automatic Transmission Fluid (U.S.)/XT-10-QLVC (U.S.) (WSS-M2C938-A) (MERCON® LV)
  8. Torque: 80 lb.in (9 Nm)
  9. NOTE: To ensure the transmission fluid cooler tubes are secure, push, pull then push the transmission cooler tubes on the transmission fluid cooler.
  10. Backing ring (7J324) Seal (7D258) Material: Motorcraft® MERCON® LV Automatic Transmission Fluid (U.S.)/XT-10-QLVC (U.S.) (WSS-M2C938-A) (MERCON® LV)
  11. Torque: 18 lb.ft (25 Nm)
  12. Refer to: «ACTIVE GRILLE SHUTTER»(ref-635237-S38052633542014070200000) .
  13. Refer to: «TRANSMISSION FLUID LEVEL CHECK»(ref-635215-S42787543582014070200000) .

Removal and Installation

  1. NOTE: The transmission fluid cooler is part of an assembly. If installation of a new transmission fluid cooler is required, Refer to: «RADIATOR»(ref-635216-S23232236142014070200000) .
WARNINGBefore beginning any service procedure in this article, refer to Safety Warnings in GENERAL INFORMATION . Failure to follow this instruction may result in serious personal injury.

Scheme 90

Scheme 90

Scheme 91

Scheme 91

Scheme 92

Scheme 92
  1. Refer to: «HEALTH AND SAFETY PRECAUTIONS»(ref-635189-S18367805802014070200000)
  2. Refer to: «JACKING AND LIFTING - OVERVIEW»(ref-635208-S40563097982014070200000) .
  1. Backing ring (7J342) Seal (7D258)
  2. Torque: 18 lb.ft (25 Nm)
  3. Backing ring (7J342) Seal (7D258)
  4. Torque: 80 lb.in (9 Nm)
  5. Backing ring (7J342) Seal (7D258)
  6. Torque: 18 lb.ft (25 Nm)
  7. Refer to: «TRANSMISSION FLUID LEVEL CHECK»(ref-635215-S42787543582014070200000) .
