Automatic Transaxle External Controls - HF35: Removal & Installation Ford C-MAX II

Removal

Note. Removal steps in this procedure may contain installation details.

Scheme 71

1. Refer to: «FLOOR CONSOLE»(ref-635235-S40115406902014070200000) .
2. Torque: 80 lb.in (9 Nm) Torque: 62 lb.in (7 Nm)

Installation

1. To install, reverse the removal procedure.
2. Adjust the selector lever cable when a new selector lever is installed. Refer to: «SELECTOR LEVER CABLE ADJUSTMENT»(ref-635244-S18449601652014070200000) .

Scheme 72

Scheme 73

Scheme 74

Scheme 75

Scheme 76

1. Refer to: «JACKING AND LIFTING - OVERVIEW»(ref-635208-S40563097982014070200000) .
2. Refer to: «AIR CLEANER»(ref-635250-S37976058432014070200000) .
3. Refer to: «FLOOR CONSOLE»(ref-635235-S40115406902014070200000) .

Scheme 77

Scheme 78

Scheme 79

Scheme 80

1. Torque: 80 lb.in (9 Nm)
2. Torque: 89 lb.in (10 Nm) Torque: 18 lb.ft (25 Nm)
3. Torque: 62 lb.in (7 Nm)
4. Refer to: «FLOOR CONSOLE»(ref-635235-S40115406902014070200000) .
5. Torque: 89 lb.in (10 Nm)
6. Torque: 62 lb.in (7 Nm)
7. Refer to: «AIR CLEANER»(ref-635250-S37976058432014070200000) .
8. Rotate the selector shaft lever clockwise until it stops. Rotate the selector shaft lever counterclockwise 3 detents.
9. Move the slide to the left. While holding the slide, position the adjuster lock upward.
10. Verify that the vehicle only starts in PARK and NEUTRAL and the reverse lamps illuminate in REVERSE.

Note. The grade assist switch is part of the selector lever knob. To install a new grade assist switch, a new selector lever knob must be installed.

Scheme 81

Scheme 82

Scheme 83

Scheme 84

Scheme 85

1. To install, reverse the removal procedure.
