Shift Interlock Systems: Other Dodge Neon II

COLUMN SHIFT MODELS

The shift interlock system consists of an electro-magnetic solenoid mounted on upper steering column. Brake Transmission Shift Interlock (BTSI) solenoid is energized by brake switch, completing ground circuit when brake pedal is depressed. With ignition switch in LOCK or ACC positions, the gearshift lever is locked in Park. With ignition switch in OFF positions, the gearshift lever is unlocked and allows gearshift lever to move to any position. This enables vehicle to moved in the event the battery is dead or removed. With ignition switch in ON/RUN position, gearshift lever is released from Park when brake pedal is depressed. The ignition interlock system also prevents the ignition switch from being returned to LOCK or ACC positions unless gearshift lever is returned to Park.

Except Sebring Coupe & Stratus Coupe

Shift interlock system on consists of a shift interlock cable/solenoid assembly connected between ignition switch and floor shifter. Brakelight switch and PCM sense circuits are used to control Brake Transmission Shift Interlock (BTSI) solenoid. With ignition switch in LOCK or ACC position, gearshift lever is locked in Park. With ignition switch in ON/RUN position, gearshift lever is released from Park when brake pedal is depressed. Depressing brake pedal de-energizes BTSI solenoid, releasing cable and allowing gearshift lever to be moved to any position. Gearshift lever can be moved with ignition switch in OFF position. This enables vehicle to moved in the event the battery is dead or removed. Shift interlock system also prevents ignition switch from being rotated to LOCK or ACC position unless gearshift lever is returned to Park.

Sebring Coupe & Stratus Coupe

Shift interlock system consists of a shift interlock cable connected between brake pedal mechanism and floor shifter, and an ignition interlock cable connected between ignition switch and floor shifter. With ignition switch in LOCK position, gearshift lever is locked in Park. With ignition switch in any other position other than LOCK, gearshift lever is released from Park when brake pedal is depressed. Shift interlock system also prevents ignition switch from being rotated to LOCK position unless gearshift lever is returned to "P" position. Key cannot be removed from ignition unless switch is in LOCK position.

GEARSHIFT LEVER LOCKED IN PLACE

Note. Symptom test procedures for models not listed are not available. See WIRING DIAGRAMS to aid in diagnosis and repair.

Concorde, Intrepid, LHS & 300M (Column Shift)

Note. For circuit reference, see CONNECTOR IDENTIFICATION and/or WIRING DIAGRAMS .

1. Gain access to BTSI solenoid. See «BTSI SOLENOID»(ref-131133-S40124967412001121400000) under REMOVAL & INSTALLATION. Go to next step.
2. Disconnect solenoid harness connector. Insert ignition key and turn ignition switch to ON/RUN position. Depress brake pedal. Attempt to move gearshift lever from Park. If gearshift lever moves, see «BTSI CIRCUIT»(ref-131133-S03955034082001121400000) under CIRCUIT TESTS. If gearshift lever does not move, go to next step.
3. Remove BTSI solenoid. If shift lever moves, replace solenoid. If shift lever does not move, inspect shift lever assembly. Repair or replace as necessary. See appropriate STEERING COLUMNS article in STEERING.

Concorde, Intrepid, LHS & 300M (Floor Shift)

Note. For circuit reference, see CONNECTOR IDENTIFICATION and/or WIRING DIAGRAMS .

1. Gain access to BTSI solenoid and shift interlock cable. See «SHIFT INTERLOCK CABLE»(ref-131133-S26108112842001121400000) under REMOVAL & INSTALLATION. Go to next step.
2. Disconnect solenoid harness connector. Insert ignition key and turn ignition switch to ON/RUN position. Depress brake pedal. Attempt to move gearshift lever from Park. If gearshift lever moves, see «BTSI CIRCUIT»(ref-131133-S03955034082001121400000) under CIRCUIT TESTS. If gearshift lever does not move, go to next step.
3. Disconnect shift interlock cable from floor shifter. If gearshift lever moves, replace shift interlock cable. If shift lever does not move, inspect shift lever assembly. Repair or replace as necessary.

Prowler

Note. For circuit reference, see CONNECTOR IDENTIFICATION and/or WIRING DIAGRAMS .

1. Gain access to BTSI solenoid and shift interlock cable. (Scheme 9) Go to next step.
2. Disconnect solenoid harness connector. Insert ignition key and turn ignition switch to ON/RUN position. Depress brake pedal. Attempt to move gearshift lever from Park. If gearshift lever moves, see «BTSI CIRCUIT»(ref-131133-S03955034082001121400000) under CIRCUIT TESTS. If gearshift lever does not move, go to next step.
3. Disconnect shift interlock cable from floor shifter. If gearshift lever moves, replace shift interlock cable. If shift lever does not move, inspect shift lever assembly. Repair or replace as necessary.

Scheme 9

BTSI CIRCUIT

Note. Symptom test procedures for models not listed are not available. See WIRING DIAGRAMS to aid in diagnosis and repair.

Note. For circuit reference, see CONNECTOR IDENTIFICATION and/or WIRING DIAGRAMS .

1. Inspect junction block fuse No. 14 (10-amp). Junction block fuse panel is located behind left side cover of instrument panel. A blown fuse would allow gearshift lever to move without depressing brake pedal. Replace fuse as needed.
2. Gain access to BTSI solenoid. See «BTSI SOLENOID»(ref-131133-S40124967412001121400000) under REMOVAL & INSTALLATION.
3. Disconnect harness connector at rear of solenoid.
4. Insert key into ignition switch. Turn ignition switch to ON/RUN position.
5. Using test light connected to ground, probe terminal No. 2 on BTSI solenoid harness connector. See «WIRING DIAGRAMS»(ref-131133-S02412989692001121100000) . If test light is illuminated, go to next step. If test light is not illuminated, repair voltage circuit between fuse No. 14 and BTSI solenoid for open or short.
6. Connect test light between BTSI harness connector terminals. If test light is illuminated, go to next step. If test light is not illuminated, repair open ground circuit or faulty stoplight switch as necessary.
7. Depress brake pedal. If test light is not illuminated, go to next step. If test light is illuminated, repair shorted ground circuit or faulty stoplight switch as necessary.
8. Connect BTSI solenoid harness connector. Recheck shift interlock system operation. See «SYSTEM OPERATION CHECK»(ref-131133-S25855899032001121100000) under TROUBLE SHOOTING. If system does not function correctly, replace BTSI solenoid. See «BTSI SOLENOID»(ref-131133-S40124967412001121400000) under REMOVAL & INSTALLATION.

Note. For circuit reference, see CONNECTOR IDENTIFICATION and/or WIRING DIAGRAMS .

1. Inspect junction block fuse No. 14 (10-amp). Junction block fuse panel is located behind left side cover of instrument panel. A blown fuse would allow gearshift lever to move without depressing brake pedal. Replace fuse as needed.
2. Gain access to BTSI solenoid and shift interlock cable. See «SHIFT INTERLOCK CABLE»(ref-131133-S26108112842001121400000) under REMOVAL & INSTALLATION.
3. Disconnect harness connector at rear of solenoid.
4. Insert key into ignition switch. Turn ignition switch of ON/RUN position.
5. Using test light connected to ground, probe terminal No. 2 on BTSI harness connector. See «WIRING DIAGRAMS»(ref-131133-S02412989692001121100000) . If test light is illuminated, go to next step. If test light is not illuminated, repair voltage circuit between fuse No. 14 and BTSI solenoid for open or short.
6. Connect test light between BTSI solenoid harness connector terminals. If test light is illuminated, go to next step. If test light is not illuminated, repair open ground circuit or faulty stoplight switch as necessary.
7. Depress brake pedal. If test light is not illuminated, go to next step. If test light is illuminated, repair shorted ground circuit or faulty stoplight switch as necessary.
8. Connect BTSI solenoid connector. Recheck shift interlock system operation. See «SYSTEM OPERATION CHECK»(ref-131133-S25855899032001121100000) under TROUBLE SHOOTING. If system does not function correctly, replace shift interlock cable. See «SHIFT INTERLOCK CABLE»(ref-131133-S26108112842001121400000) under REMOVAL & INSTALLATION.

Note. For circuit reference, see CONNECTOR IDENTIFICATION and/or WIRING DIAGRAMS .

1. Inspect fuse block fuse No. 19 (10-amp). Fuse panel is located behind left side cover of instrument panel. A blown fuse would allow gearshift lever to move without depressing brake pedal. Replace fuse as needed.
2. Gain access to BTSI solenoid and shift interlock cable. (Scheme 9)
3. Disconnect harness connector at rear of solenoid.
4. Insert key into ignition switch. Turn ignition switch of ON/RUN position.
5. Using test light connected to ground, probe terminal No. 2 on BTSI harness connector. See «WIRING DIAGRAMS»(ref-131133-S02412989692001121100000). If test light is illuminated, go to next step. If test light is not illuminated, repair voltage circuit between fuse No. 19 and BTSI solenoid for open or short.
6. Connect test light between BTSI solenoid harness connector terminals. If test light is illuminated, go to next step. If test light is not illuminated, repair open ground circuit or faulty stoplight switch as necessary.
7. Depress brake pedal. If test light is not illuminated, go to next step. If test light is illuminated, repair shorted ground circuit or faulty stoplight switch as necessary.
8. Connect BTSI solenoid harness connector. Recheck shift interlock system operation. See «SYSTEM OPERATION CHECK»(ref-131133-S25855899032001121100000) under TROUBLE SHOOTING. If system does not function correctly, replace shift interlock cable. See «SHIFT INTERLOCK CABLE»(ref-131133-S26108112842001121400000) under REMOVAL & INSTALLATION.

1. Apply parking brake. Remove upper steering column cover. Note location of gearshift cable and gearshift cable adjuster lock on steering column. (Scheme 10) Using screwdriver, rotate gearshift cable adjuster lock to unlock position.
2. Ensure manual control lever on transaxle is rotated fully rearward to Park, and parking sprag is fully engaged. Manual control lever is lever on transaxle on which gearshift cable is installed.
3. Verify transaxle is in Park and parking sprag is fully engaged by slightly moving vehicle backward and forward. Tilt steering column to fully downward position. Place gearshift lever in Park. Ensure ignition key is removed from ignition switch.
4. Adjust gearshift cable by rotating gearshift cable adjuster lock into locked position. Reinstall upper steering column cover. Ensure gearshift lever operates smoothly without binding, and engine starts only with gearshift lever in Park or Neutral. If engine starts with gearshift lever in any other gear range except Park and Neutral, or binding exists, readjust gearshift cable.

Scheme 10

Concorde, Intrepid, LHS, Prowler & 300M (Floor Shift)

1. Apply parking brake. Place gearshift lever in Neutral. Loosen set screw and remove gearshift lever knob. Remove ashtray located on center console bezel, below radio. Center console bezel fits around gearshift lever and on top of center console.
2. Remove center console bezel-to-center console screw located just below ashtray area on center console bezel. Disengage clips holding each rear corner of center console bezel on center console. Remove center console bezel.
3. Loosen gearshift cable adjuster nut at gearshift cable adjuster. (Scheme 11) Ensure manual control lever on transaxle is rotated fully rearward to Park, and parking sprag is fully engaged. Manual control lever is lever on transaxle on which gearshift cable is installed.
4. Verify transaxle is in Park and parking sprag is fully engaged by slightly moving vehicle backward and forward. Place gearshift lever in Park. Ensure ignition key is removed from ignition. Tighten gearshift cable adjuster nut to 19 ft. lbs. (26 N.m).
5. Reinstall center console bezel and gearshift lever knob. Ensure gearshift lever operates smoothly without binding, and engine starts only with gearshift lever in Park or Neutral. If engine starts with gearshift lever in any other gear range except Park and Neutral, or binding exists, readjust gearshift cable.

Scheme 11

Neon & PT Cruiser

1. Apply parking brake. Remove screw cover plugs over screws just behind cup holders on center console. Remove screws holding center console to floor bracket.
2. Open lid on center console, if equipped. If vehicle is equipped with a non-arm rest center console, remove screw cover plugs near rear of center console.
3. Remove remaining screws and center console. (Scheme 12)or (Scheme 13). Place gearshift lever in Park. Loosen shift cable adjustment screw. (Scheme 14)
4. Ensure gearshift lever and manual control lever on transaxle is in Park. Manual control lever is lever on transaxle on which gearshift cable is installed. Verify transaxle is in Park by attempting to roll vehicle in either direction.
5. Tighten shift cable adjustment screw to 70 INCH lbs. (8 N.m). Ensure engine starts only with gearshift lever in Park or Neutral. If engine starts with gearshift lever in any other gear range except Park and Neutral, or binding exists, readjust gearshift cable. Reinstall center console.

Scheme 12

Scheme 13

Scheme 14

1. Apply parking brake. Place gearshift lever in Neutral. Loosen lock nut on gearshift cable at manual control lever. (Scheme 15) Manual control lever is lever on transaxle on which gearshift cable is installed.
2. Place manual control lever in Neutral. Lightly pull end of gearshift cable toward manual control lever and tighten lock nut on gearshift cable to 89 INCH lbs. (10 N.m). If gearshift cable is properly adjusted, engine should start only with gearshift lever in Park or Neutral.

Scheme 15

Sebring Convertible, Sebring Sedan & Stratus Sedan

1. Apply parking brake. Remove set screw from side of gearshift lever knob. Remove gearshift lever knob, gearshift lever bezel and wiring. Gear selector bezel snaps on top of center console and indicates gearshift lever position.
2. Reinstall gearshift lever knob and set screw. Ensure gearshift lever is in Park. Loosen gearshift cable adjuster nut at gearshift lever. (Scheme 11) Move manual control lever on transaxle to Park. Manual control lever is lever on transaxle on which gearshift cable is installed.
3. Ensure gearshift lever and manual control lever on transaxle is in Park. Tighten gearshift cable adjuster nut at gearshift lever to 19 ft. lbs. (26 N.m).
4. Ensure engine starts only with gearshift lever in Park or Neutral and detent position for Neutral and Drive are within gate areas on gearshift lever. If engine starts with gearshift lever in any other gear range except Park and Neutral, or detents are not within gate areas, readjust gearshift cable. Reinstall gearshift lever bezel.

Concorde, Intrepid, LHS, Prowler & 300M

1. On column shift applications, go to next step. On floor shift applications, go to step 3.
2. On column shift applications, if shift interlock does not operate properly, BTSI solenoid may be malfunctioning. See «GEARSHIFT LEVER LOCKED IN PLACE»(ref-131133-S16634925452001121400000) under SYMPTOM TESTS. If ignition interlock does not operate properly, ignition interlock cassette on steering column must be replaced. Shift interlock cassette cable may only be adjusted once after installing NEW cassette. See «IGNITION INTERLOCK CASSETTE»(ref-131133-S19699351872001121700000) under REMOVAL & INSTALLATION.
3. Remove gearshift lever handle. Remove console bezel. Move gearshift lever to Park and ignition key to LOCK position. If interlock cable is being replaced, remove pin to allow cable to "self adjust." Press locking clip by hand to secure adjustment. (Scheme 16)
4. If interlock cable is not being replaced, pin will not exist. Loosen locking clip on interlock cable to allow cable to "self adjust." Press locking clip by hand to secure adjustment. Install bezel on gearshift console. Install gearshift handle.

1. Disconnect and isolate negative battery cable. Apply parking brake. Remove screw cover plugs over screws just behind cup holders on center console. Remove screws holding center console to floor bracket. These screws are located just behind cup holders on center console.
2. Open lid on center console, if equipped. If vehicle is equipped with a non-arm rest center console, remove screw cover plugs over screws near rear of center console.
3. Remove remaining screws and center console. (Scheme 12)or (Scheme 13). Remove set screw and gearshift lever knob. Remove screws and gearshift lever indicator bezel located on top of gearshift lever assembly. (Scheme 17) Reinstall gearshift lever knob.
4. Pry up on cable adjuster lock to release and allow cable to "self adjust." Lock cable adjustment by pressing down on adjuster lock until bottomed at cable housing.
5. Verify correct system operation. If shift interlock system does not operate properly, readjust shift interlock cable or check for defective components. Remove gearshift lever knob. Reinstall gearshift lever indicator bezel, gearshift lever knob and center console.

Scheme 16

1. Remove center console to access gearshift assembly. (Scheme 18) Place gearshift lever in Park. Disconnect key interlock cable from lock cam and loosen lock nut. Loosen shift lock cable lock nut. Position shift lock cable so end of cable is positioned above Red marking on gearshift lock cam. (Scheme 19)
2. Reinstall key interlock cable on lock cam. Ensure spring and washer are assembled properly. (Scheme 19) While lightly pushing key interlock cable coupling portion of lock cam in direction "A", tighten key interlock cable lock nut. Reinstall center console.

Scheme 17

Scheme 18

1. Disconnect and isolate negative battery cable. Remove gearshift lever knob. Remove center console. (Scheme 20) Reinstall gearshift lever knob. Ensure gearshift lever is in Park. Turn ignition switch to LOCK position. If interlock cable is being replaced, remove lock pin. see scheme 13 After interlock cable "self adjusts" to correct position, push down on locking clip.
2. If an existing interlock cable requires adjustment, lock pin will not be present. Pull outward on locking clip. After interlock cable adjusts to correct position, push down on locking clip. Check operation of shift interlock system. To install remaining components, reverse removal procedure.

Scheme 19

Scheme 20

STOPLIGHT SWITCH

Note. Stoplight switch may also be known as brakelight switch.

Press and hold brake pedal to fully applied position. Pull stoplight switch plunger to fully extended position. Release brake pedal and pull pedal fully rearward. Pedal will set plunger to correct position as pedal pushes plunger into switch body. Switch will make a ratcheting sound as plunger adjusts into switch. Check stoplight switch operation.

BTSI SOLENOID

Note. Shift interlock solenoid is integrated with cable on floor shift models. See SHIFT INTERLOCK CABLE .

Note. Stoplight switch may also be known as brakelight switch.

1. Stoplight switch is located in mounting bracket near top of brake pedal. Rotate stoplight switch counterclockwise 30 degrees and remove switch from mounting bracket. Disconnect electrical connector from stoplight switch.
2. Pull plunger on stoplight switch outward until plunger has ratcheted outward to fully extended position. Fully depress brake pedal. Install stoplight switch in mounting bracket so index tab on stoplight switch aligns with slot in mounting bracket.
3. With stoplight switch fully seated in mounting bracket, rotate stoplight switch 30 degrees to lock stoplight switch in mounting bracket. Reinstall electrical connector on stoplight switch. Adjust switch. See «STOPLIGHT SWITCH»(ref-131133-S10796289112002020400000) under ADJUSTMENTS.

Scheme 21

Scheme 22

Shift Interlock System Wiring Diagram (2001 Concord, Intrepid, LHS & 300M). Scheme 23

Shift Interlock System Wiring Diagram (2001 Neon). Scheme 24

Shift Interlock System Wiring Diagram (2001-02 PT Cruiser). Scheme 25

Shift Interlock System Wiring Diagram (2002 Concord, Intrepid & 300M). Scheme 26

Shift Interlock System Wiring Diagram (2002 Neon). Scheme 27
