COMPONENT LOCATIONS

Note. For component locations refer to illustrations. (Scheme 2)- (Scheme 7).

ComponentLocation
Controller Anti-Lock BrakeOn Left Front Frame Rail, Below Master Cylinder. (Scheme 7)
Data Link Connector (DLC)At Left Side Of Steering Column. (Scheme 3)
Deck Lid Security SwitchBehind Deck Lid Lock Cylinder
Electro-Mechanical Instrument Cluster ModuleIntegral Part Of Instrument Cluster
Fuse BlockUnder Left Side Of Instrument Panel. (Scheme 3)
Left Side Impact Air Bag Control ModuleAt Base Of Left "B" Pillar. (Scheme 4)
Occupant Restraint ControllerUnder Center Of Floor Console. (Scheme 2)
Powertrain Control Module (PCM)In Left Front Of Engine Compartment, Below Air Cleaner Housing. (Scheme 7)
Power Distribution CenterOn Left Side Of Engine Compartment, Near Battery. (Scheme 7)
Right Side Impact Air Bag Control ModuleAt Base Of Right "B" Pillar. (Scheme 4)
Remote Keyless Entry (RKE) ModuleUnder Center Of Dash, Above HVAC Controls. (Scheme 5)
Sentry Key Immobilizer Module (SKIM)On Right Side Of Steering Column. (Scheme 6)

COMPONENT LOCATIONS

Scheme 2

Scheme 2

Scheme 3

Scheme 3

Scheme 4

Scheme 4

Scheme 5

Scheme 5

Scheme 6
