Radio Display Module (Disp) - Electrical Diagnostics: Other Dodge Journey I

Monitor Conditions

1. When Monitored: Continuously with the ignition and DISP on.

Set Conditions

1. Set Condition: The code will set if the temperature inside the DISP Module is above 65°C (145°F)

Possible Causes

1. When Monitored: Continuously with the ignition on.

1. Set Condition: The code will set if the temperature inside the Radio Display Module (DISP) is reported as below -40°C (-40°F)

1. When Monitored: Continuously with the ignition and Radio on.

1. Set Condition: The code will set if the temperature inside the DISP module is above +65°C ( +145°F ) and high humidity.

1. When Monitored: At all times.

1. Set Condition: This is a CAN message that the battery voltage was below 10 Volts for over 15 seconds.

1. When Monitored: At all times.

1. Set Condition: This is a CAN message that the system voltage was above 16 Volts for over 15 seconds.

1. When Monitored: At all times.

1. Set Condition: Anytime the Radio Display Module (DISP) senses voltage input below 10.0 Volts, this code will set.

Scheme 170

Scheme 171

1. CHECK POWERTRAIN CONTROL MODULE DTCs Using the scan tool, read Powertrain Control Module (PCM) or Engine Control Module (ECM) DTCs. Are there any Charging or Battery DTCs present? Yes Inspect the Ignition Off Draw (IOD) fuse for an open. If no problems were found. Refer to «DTC-Based Diagnostics/MODULE, Powertrain Control (PCM) - Diagnosis and Testing»(ref-353603-S18034344452010011200000) for gas engine applications or «DTC-Based Diagnostics/MODULE, Engine Control (ECM) - Diagnosis and Testing»(ref-353628) for diesel engine applications and perform the appropriate diagnostic procedure. No Go to step 2
2. TEST FOR INTERMITTENT CONDITION Using the scan tool, record and erase DTCs. Start the engine and run for two minutes. Using the scan tool, read DTCs in the Radio Display Module (DISP). Does the scan tool display B210D-BATTERY VOLTAGE LOW? Yes Go to step 3 No The conditions that caused this code to set are not present at this time. Using the «SYSTEM WIRING DIAGRAMS»(ref-313026) as a guide, inspect the wiring and connectors. Perform the BODY VERIFICATION TEST. Refer to «DTC-Based Diagnostics/MODULE, Totally Integrated Power (TIPM) - Standard Procedure»(ref-353625-S36713451532010011200000) .
3. (A413) FUSED B(+) CIRCUIT OPEN OR EXCESSIVE RESISTANCE Turn the ignition off. Disconnect the Radio Display Module harness connector. Using a 12-volt test light connect to ground, probe the (A413) Fused B(+) circuit in the Radio Display Module harness connector. Does the test light illuminate brightly? Yes Go to step 4 No Repair open or excessive resistance in the (A413) Fused B(+) circuit. Inspect the Ignition Off Draw (IOD) Fuse. If the fuse is open inspect the (A413) Fused B(+) circuit for a short to ground, which may be caused by an internal short of the Radio Display Module. Perform the BODY VERIFICATION TEST. Refer to «DTC-Based Diagnostics/MODULE, Totally Integrated Power (TIPM) - Standard Procedure»(ref-353625-S36713451532010011200000) .
4. (Z907) GROUND CIRCUIT OPEN OR EXCESSIVE RESISTANCE Using a 12-volt test light connect to the (A413) Fused B(+) circuit, probe the (Z907) Ground circuit in the Radio Display Module harness connector. Does the test light illuminate brightly? Yes Using the wiring schematics as a guide, inspect the harness and connectors. Look for bent, pushed out, poor terminal pin fit and, corrosion that may cause an intermittent failure. If okay, replace the Radio Display Module (DISP) in accordance with the Service Information. Perform the BODY VERIFICATION TEST. Refer to «DTC-Based Diagnostics/MODULE, Totally Integrated Power (TIPM) - Standard Procedure»(ref-353625-S36713451532010011200000) . No Repair the open or excessive resistance in the (Z907) Ground circuit. Perform the BODY VERIFICATION TEST. Refer to «DTC-Based Diagnostics/MODULE, Totally Integrated Power (TIPM) - Standard Procedure»(ref-353625-S36713451532010011200000) .

1. When Monitored: At all times.

1. Set Condition: Anytime the Radio Display Module (DISP) senses voltage input above 16.0 Volts, this code will set.

1. When Monitored: With the ignition on.

1. Set Condition: When the Radio Display Module (DISP) experiences a reset event.

1. When Monitored: With the ignition on.

1. Set Condition: When the Radio Display Module (DISP) detects the signal from the Totally Integrated Power Module (TIPM) relevant for vehicle characteristic is missing for a period greater than the specified fault duration.

1. When Monitored: With the ignition on.

1. Set Condition: If the Radio Display Module has an internal fault. This DTC has a maturing time of 1000 milliseconds and a de-maturing time of 200 milliseconds. If the DTCs status changes from active to stored it will stay in memory for 100 consecutive ignition cycles.

1. When Monitored: Continuously when the ignition is on. Battery voltage between 10 and 16 Volts. Ignition Off Draw (IOD) fuse installed.

1. Set Condition: The Radio Display Module (DISP) detects a short to ground on the CAN Interior Bus (125K) (+) circuit or a short to voltage on the CAN Interior Bus (125K) (-) circuit.

1. When Monitored: Continuously when the ignition is on. Battery voltage between 10 and 16 Volts. Ignition Off Draw (IOD) fuse installed.

1. Set Condition: The Radio Display Module (DISP) detects the CAN Interior Bus circuits shorted to ground, shorted together or shorted to voltage.

1. When Monitored: Continuously when the ignition is on. Battery voltage between 10 and 16 Volts. Ignition Off Draw (IOD) fuse installed.

1. Set Condition: Bus messages not received from the Totally Integrated Power Module (TIPM) for approximately two to five seconds.

1. When Monitored: Continuously when the ignition is on. The battery voltage is between 10 and 16 Volts. Ignition Off Draw (IOD) fuse installed.

1. Set Condition: Bus messages not received from the Cluster for approximately two to five seconds.

1. When Monitored: Continuously when the ignition is on. The battery voltage between 10 and 16 Volts. Ignition Off Draw (IOD) fuse installed.

1. Set Condition: Bus messages not received from the Radio for approximately two to five seconds.
