Audio System (Amplifier) - Electrical Diagnostics: Diagnosis Dodge Journey I

Communication Devices 4 illustrations ~2321 words

DIAGNOSTIC CODE INDEX

DTCDescription
B1460CHANNEL 1 AUDIO SPEAKER OUTPUT CIRCUIT PERFORMANCE
B1461CHANNEL 1 AUDIO SPEAKER OUTPUT CIRCUIT LOW
B1462CHANNEL 1 AUDIO SPEAKER OUTPUT CIRCUIT HIGH
B1463CHANNEL 1 AUDIO SPEAKER OUTPUT CIRCUIT OPEN
B1464CHANNEL 1 AUDIO SPEAKER OUTPUT CIRCUIT SHORTED TOGETHER
B1465CHANNEL 2 AUDIO SPEAKER OUTPUT CIRCUIT PERFORMANCE
B1466CHANNEL 2 AUDIO SPEAKER OUTPUT CIRCUIT LOW
B1467CHANNEL 2 AUDIO SPEAKER OUTPUT CIRCUIT HIGH
B1468CHANNEL 2 AUDIO SPEAKER OUTPUT CIRCUIT OPEN
B1469CHANNEL 2 AUDIO SPEAKER OUTPUT CIRCUIT SHORTED TOGETHER
B146ACHANNEL 3 AUDIO SPEAKER OUTPUT CIRCUIT PERFORMANCE
B146BCHANNEL 3 AUDIO SPEAKER OUTPUT CIRCUIT LOW
B146CCHANNEL 3 AUDIO SPEAKER OUTPUT CIRCUIT HIGH
B146DCHANNEL 3 AUDIO SPEAKER OUTPUT CIRCUIT OPEN
B146ECHANNEL 3 AUDIO SPEAKER OUTPUT CIRCUIT SHORTED TOGETHER
B146FCHANNEL 4 AUDIO SPEAKER OUTPUT CIRCUIT PERFORMANCE
B1470CHANNEL 4 AUDIO SPEAKER OUTPUT CIRCUIT LOW
B1471CHANNEL 4 AUDIO SPEAKER OUTPUT CIRCUIT HIGH
B1472CHANNEL 4 AUDIO SPEAKER OUTPUT CIRCUIT OPEN
B1473CHANNEL 4 AUDIO SPEAKER OUTPUT CIRCUIT SHORTED TOGETHER
B1474CHANNEL 5 AUDIO SPEAKER OUTPUT CIRCUIT PERFORMANCE
B1475CHANNEL 5 AUDIO SPEAKER OUTPUT CIRCUIT LOW
B1476CHANNEL 5 AUDIO SPEAKER OUTPUT CIRCUIT HIGH
B1477CHANNEL 5 AUDIO SPEAKER OUTPUT CIRCUIT OPEN
B1478CHANNEL 5 AUDIO SPEAKER OUTPUT CIRCUIT SHORTED TOGETHER
B1479CHANNEL 6 AUDIO SPEAKER OUTPUT CIRCUIT PERFORMANCE
B147ACHANNEL 6 AUDIO SPEAKER OUTPUT CIRCUIT LOW
B147BCHANNEL 6 AUDIO SPEAKER OUTPUT CIRCUIT HIGH
B147CCHANNEL 6 AUDIO SPEAKER OUTPUT CIRCUIT OPEN
B147DCHANNEL 6 AUDIO SPEAKER OUTPUT CIRCUIT SHORTED TOGETHER
B147ECHANNEL 7 AUDIO SPEAKER OUTPUT CIRCUIT PERFORMANCE
B147FCHANNEL 7 AUDIO SPEAKER OUTPUT CIRCUIT LOW
B1480CHANNEL 7 AUDIO SPEAKER OUTPUT CIRCUIT HIGH
B1481CHANNEL 7 AUDIO SPEAKER OUTPUT CIRCUIT OPEN
B1482CHANNEL 7 AUDIO SPEAKER OUTPUT CIRCUIT SHORTED TOGETHER
B1483CHANNEL 8 AUDIO SPEAKER OUTPUT CIRCUIT PERFORMANCE
B1484CHANNEL 8 AUDIO SPEAKER OUTPUT CIRCUIT LOW
B1485CHANNEL 8 AUDIO SPEAKER OUTPUT CIRCUIT HIGH
B1486CHANNEL 8 AUDIO SPEAKER OUTPUT CIRCUIT OPEN
B1487CHANNEL 8 AUDIO SPEAKER OUTPUT CIRCUIT SHORTED TOGETHER
U0019CAN INTERIOR BUS
U0020CAN INTERIOR BUS OFF PERFORMANCE
U0141LOST COMMUNICATION WITH FRONT CONTROL MODULE
U0151LOST COMMUNICATION WITH OCCUPANT RESTRAINT CONTROLLER
U0154LOST COMMUNICATION WITH OCCUPANT CLASSIFICATION MODULE
U0184LOST COMMUNICATION WITH RADIO
U0197LOST COMMUNICATION WITH HANDS FREE MODULE
U0199LOST COMMUNICATION WITH DRIVERS DOOR MODULE
U0200LOST COMMUNICATION WITH PASSENGER DOOR MODULE

DIAGNOSTIC CODE INDEX

Diagnostic Test

  1. CHECK FOR AN INTERMITTENT CONDITION Turn the ignition on and open one of the front doors. NOTE: A front door must remain open whenever checking or erasing Amplifier DTCs. Using the scan tool, record and erase the Amplifier DTCs. Cycle the ignition switch from on to off, wait five seconds and then back to on. Turn the Radio on and set the volume to 25. Adjust the speakers to the front and center. Using the scan tool, read the active Amplifier DTCs. Does the scan tool display active: B1460-CHANNEL 1 AUDIO SPEAKER OUTPUT CIRCUIT PERFORMANCE? Yes Replace the Amplifier in accordance with the Service Information. Perform the BODY VERIFICATION TEST. Refer to «DTC-Based Diagnostics/MODULE, Totally Integrated Power (TIPM) - Standard Procedure»(/dodge/journey/i-2007-2011/remont/communication-devices/#body-verification-test-tipm) . No Test complete, the condition or conditions that originally set this DTC are not present at this time. Using the «SYSTEM WIRING DIAGRAMS»(ref-313026) as a guide, check all related splices and connectors for signs of water intrusion, corrosion, pushed out or bent terminals and correct pin tension. Perform the BODY VERIFICATION TEST. Refer to «DTC-Based Diagnostics/MODULE, Totally Integrated Power (TIPM) - Standard Procedure»(/dodge/journey/i-2007-2011/remont/communication-devices/#body-verification-test-tipm) .

Scheme 93

Scheme 93: Circuit Schematic
  1. CHECK FOR AN INTERMITTENT CONDITION Turn the ignition on and open one of the front doors. NOTE: A front door must remain open whenever checking or erasing Amplifier DTCs. With the scan tool, record and erase the Amplifier DTCs. Cycle the ignition switch from on to off, wait five seconds and then back to on. Turn the Radio on and set the volume to 25. Adjust the speakers to the front and center. With the scan tool, read the active Amplifier DTCs. Does the scan tool display active: B1465-CHANNEL 2 AUDIO SPEAKER OUTPUT CIRCUIT PERFORMANCE? Yes Replace the Amplifier in accordance with the service information. Perform the BODY VERIFICATION TEST. Refer to «DTC-Based Diagnostics/MODULE, Totally Integrated Power (TIPM) - Standard Procedure»(/dodge/journey/i-2007-2011/remont/communication-devices/#body-verification-test-tipm) . No Test complete, the condition or conditions that originally set this DTC are not present at this time. Using the «SYSTEM WIRING DIAGRAMS»(ref-313026) as a guide, check all related splices and connectors for signs of water intrusion, corrosion, pushed out or bent terminals and correct pin tension. Perform the BODY VERIFICATION TEST. Refer to «DTC-Based Diagnostics/MODULE, Totally Integrated Power (TIPM) - Standard Procedure»(/dodge/journey/i-2007-2011/remont/communication-devices/#body-verification-test-tipm) .
  1. CHECK FOR AN INTERMITTENT CONDITION Turn the ignition on and open one of the front doors. NOTE: A front door must remain open whenever checking or erasing Amplifier DTCs. With the scan tool, record and erase the Amplifier DTCs. Cycle the ignition switch from on to off, wait five seconds and then back to on. Turn the Radio on and set the volume to 25. Adjust the speakers to the front and center. With the scan tool, read the active Amplifier DTCs. Does the scan tool display active: B146A-CHANNEL 3 AUDIO SPEAKER OUTPUT CIRCUIT PERFORMANCE? Yes Replace the Amplifier in accordance with the Service Information. Perform the BODY VERIFICATION TEST. Refer to «DTC-Based Diagnostics/MODULE, Totally Integrated Power (TIPM) - Standard Procedure»(/dodge/journey/i-2007-2011/remont/communication-devices/#body-verification-test-tipm) . No Test complete, the condition or conditions that originally set this DTC are not present at this time. Using the «SYSTEM WIRING DIAGRAMS»(ref-313026) as a guide, check all related splices and connectors for signs of water intrusion, corrosion, pushed out or bent terminals and correct pin tension. Perform the BODY VERIFICATION TEST. Refer to «DTC-Based Diagnostics/MODULE, Totally Integrated Power (TIPM) - Standard Procedure»(/dodge/journey/i-2007-2011/remont/communication-devices/#body-verification-test-tipm) .

Scheme 94

Scheme 94: Circuit Schematic
  1. CHECK FOR AN INTERMITTENT CONDITION Turn the ignition on and open one of the front doors. NOTE: A front door must remain open whenever checking or erasing Amplifier DTCs. With the scan tool, record and erase the Amplifier DTCs. Cycle the ignition switch from on to off, wait five seconds and then back to on. Turn the Radio on and set the volume to 25. Adjust the speakers to the front and center. With the scan tool, read the active Amplifier DTCs. Does the scan tool display active: B146F-CHANNEL 4 AUDIO SPEAKER OUTPUT CIRCUIT PERFORMANCE? Yes Replace the Amplifier in accordance with the Service Information. Perform the BODY VERIFICATION TEST. Refer to «DTC-Based Diagnostics/MODULE, Totally Integrated Power (TIPM) - Standard Procedure»(/dodge/journey/i-2007-2011/remont/communication-devices/#body-verification-test-tipm) . No Test complete, the condition or conditions that originally set this DTC are not present at this time. Using the «SYSTEM WIRING DIAGRAMS»(ref-313026) as a guide, check all related splices and connectors for signs of water intrusion, corrosion, pushed out or bent terminals and correct pin tension. Perform the BODY VERIFICATION TEST. Refer to «DTC-Based Diagnostics/MODULE, Totally Integrated Power (TIPM) - Standard Procedure»(/dodge/journey/i-2007-2011/remont/communication-devices/#body-verification-test-tipm) .
  1. CHECK FOR AN INTERMITTENT CONDITION Turn the ignition on and open one of the front doors. NOTE: A front door must remain open whenever checking or erasing Amplifier DTCs. With the scan tool, record and erase the Amplifier DTCs. Cycle the ignition switch from on to off, wait five seconds and then back to on. Turn the Radio on and set the volume to 25. Adjust the speakers to the rear and center. With the scan tool, read the active Amplifier DTCs. Does the scan tool display active: B1474-CHANNEL 5 AUDIO SPEAKER OUTPUT CIRCUIT PERFORMANCE? Yes Replace the Amplifier in accordance with the Service Information. Perform the BODY VERIFICATION TEST. Refer to «DTC-Based Diagnostics/MODULE, Totally Integrated Power (TIPM) - Standard Procedure»(/dodge/journey/i-2007-2011/remont/communication-devices/#body-verification-test-tipm) . No Test complete, the condition or conditions that originally set this DTC are not present at this time. Using the «SYSTEM WIRING DIAGRAMS»(ref-313026) as a guide, check all related splices and connectors for signs of water intrusion, corrosion, pushed out or bent terminals and correct pin tension. Perform the BODY VERIFICATION TEST. Refer to «DTC-Based Diagnostics/MODULE, Totally Integrated Power (TIPM) - Standard Procedure»(/dodge/journey/i-2007-2011/remont/communication-devices/#body-verification-test-tipm) .

Scheme 95

Scheme 95: Circuit Schematic
  1. CHECK FOR AN INTERMITTENT CONDITION Turn the ignition on and open one of the front doors. NOTE: A front door must remain open whenever checking or erasing Amplifier DTCs. Using the scan tool, record and erase the Amplifier DTCs. Cycle the ignition switch from on to off, wait five seconds and then back to on. Turn the Radio on and set the volume to 25. Adjust the speakers to the rear and center. Using the scan tool, read the active Amplifier DTCs. Does the scan tool display active: B1479-CHANNEL 6 AUDIO SPEAKER OUTPUT CIRCUIT PERFORMANCE? Yes Replace the Amplifier in accordance with the Service Information. Perform the BODY VERIFICATION TEST. Refer to «DTC-Based Diagnostics/MODULE, Totally Integrated Power (TIPM) - Standard Procedure»(/dodge/journey/i-2007-2011/remont/communication-devices/#body-verification-test-tipm) . No Test complete, the condition or conditions that originally set this DTC are not present at this time. Using the «SYSTEM WIRING DIAGRAMS»(ref-313026) as a guide, check all related splices and connectors for signs of water intrusion, corrosion, pushed out or bent terminals and correct pin tension. Perform the BODY VERIFICATION TEST. Refer to «DTC-Based Diagnostics/MODULE, Totally Integrated Power (TIPM) - Standard Procedure»(/dodge/journey/i-2007-2011/remont/communication-devices/#body-verification-test-tipm) .
  1. CHECK FOR AN INTERMITTENT CONDITION Turn the ignition on and open one of the front doors. NOTE: A front door must remain open whenever checking or erasing Amplifier DTCs. With the scan tool, record and erase the Amplifier DTCs. Cycle the ignition switch from on to off, wait five seconds and then back to on. Turn the Radio on and set the volume to 25. Adjust the speakers to the rear and center. With the scan tool, read the active Amplifier DTCs. Does the scan tool display active: B147E-CHANNEL 7 AUDIO SPEAKER OUTPUT CIRCUIT PERFORMANCE? Yes Replace the Amplifier in accordance with the Service Information. Perform the BODY VERIFICATION TEST. Refer to «DTC-Based Diagnostics/MODULE, Totally Integrated Power (TIPM) - Standard Procedure»(/dodge/journey/i-2007-2011/remont/communication-devices/#body-verification-test-tipm) . No Test complete, the condition or conditions that originally set this DTC are not present at this time. Using the «SYSTEM WIRING DIAGRAMS»(ref-313026) as a guide, check all related splices and connectors for signs of water intrusion, corrosion, pushed out or bent terminals and correct pin tension. Perform the BODY VERIFICATION TEST. Refer to «DTC-Based Diagnostics/MODULE, Totally Integrated Power (TIPM) - Standard Procedure»(/dodge/journey/i-2007-2011/remont/communication-devices/#body-verification-test-tipm) .

Scheme 96

Scheme 96: Circuit Schematic
  1. CHECK FOR AN INTERMITTENT CONDITION Turn the ignition on and open one of the front doors. NOTE: A front door must remain open whenever checking or erasing Amplifier DTCs. With the scan tool, record and erase the Amplifier DTCs. Cycle the ignition switch from on to off, wait five seconds and then back to on. Turn the Radio on and set the volume to 25. Adjust the speakers to the rear and center. With the scan tool, read the active Amplifier DTCs. Does the scan tool display active: B1483-CHANNEL 8 AUDIO SPEAKER OUTPUT CIRCUIT PERFORMANCE? Yes Replace the Amplifier in accordance with the Service Information. Perform the BODY VERIFICATION TEST. Refer to «DTC-Based Diagnostics/MODULE, Totally Integrated Power (TIPM) - Standard Procedure»(/dodge/journey/i-2007-2011/remont/communication-devices/#body-verification-test-tipm) . No Test complete, the condition or conditions that originally set this DTC are not present at this time. Using the «SYSTEM WIRING DIAGRAMS»(ref-313026) as a guide, check all related splices and connectors for signs of water intrusion, corrosion, pushed out or bent terminals and correct pin tension. Perform the BODY VERIFICATION TEST. Refer to «DTC-Based Diagnostics/MODULE, Totally Integrated Power (TIPM) - Standard Procedure»(/dodge/journey/i-2007-2011/remont/communication-devices/#body-verification-test-tipm) .
  1. TEST FOR INTERMITTENT CONDITION Turn the ignition on. With the scan tool, record and erase DTCs. Cycle the ignition from on to off 3 times. Turn the ignition on. With the scan tool, read DTCs. Does the scan tool display: U0019-CAN INTERIOR BUS CIRCUIT? Yes Go to step 2 No The conditions that caused this code to set are not present at this time. Using the wiring diagram/schematic as a guide, inspect the wiring and connectors. Perform BODY VERIFICATION TEST. Refer to «DTC-Based Diagnostics/MODULE, Totally Integrated Power (TIPM) - Standard Procedure»(/dodge/journey/i-2007-2011/remont/communication-devices/#body-verification-test-tipm)
  2. CHECK TOTALLY INTEGRATED POWER MODULE DTCs With the scan tool, read Totally Integrated Power Module DTCs Does the scan tool display any CAN INTERIOR BUS DTCs - ACTIVE? Yes Refer to the symptom list for problems related to Communication. Refer to «DTC-Based Diagnostics/MODULE, Totally Integrated Power (TIPM) - Standard Procedure»(/dodge/journey/i-2007-2011/remont/communication-devices/#body-verification-test-tipm) No Go to step 3
  3. CAN INTERIOR BUS (+) CIRCUIT OPEN Turn the ignition off. Disconnect the Amplifier C1 harness connector. Disconnect the Totally Integrated Power Module C7 harness connector. Measure the resistance of the (D265) CAN INTERIOR BUS (+) circuit between the Totally Integrated Power Module C7 harness connector and the Amplifier C1 harness connector. Is the resistance below 2.0 ohms? Yes Go to step 4 Perform BODY VERIFICATION TEST. Refer to «DTC-Based Diagnostics/MODULE, Totally Integrated Power (TIPM) - Standard Procedure»(/dodge/journey/i-2007-2011/remont/communication-devices/#body-verification-test-tipm) No Repair the CAN INTERIOR BUS (+) circuit for an open. Perform BODY VERIFICATION TEST. Refer to «DTC-Based Diagnostics/MODULE, Totally Integrated Power (TIPM) - Standard Procedure»(/dodge/journey/i-2007-2011/remont/communication-devices/#body-verification-test-tipm)
  4. CAN INTERIOR BUS (-) CIRCUIT OPEN Measure the resistance of the (D264) CAN INTERIOR BUS (-) circuit between the Totally Integrated Power Module C7 harness connector and the Amplifier C1 harness connector. Is the resistance below 2.0 ohms? Yes Replace the Amplifier in accordance with the Service Information. Perform BODY VERIFICATION TEST. Refer to «DTC-Based Diagnostics/MODULE, Totally Integrated Power (TIPM) - Standard Procedure»(/dodge/journey/i-2007-2011/remont/communication-devices/#body-verification-test-tipm) No Repair the CAN INTERIOR BUS (-) circuit for an open. Perform BODY VERIFICATION TEST. Refer to «DTC-Based Diagnostics/MODULE, Totally Integrated Power (TIPM) - Standard Procedure»(/dodge/journey/i-2007-2011/remont/communication-devices/#body-verification-test-tipm)
  1. TEST FOR INTERMITTENT CONDITION Turn the ignition on. With the scan tool, record and erase DTCs. Cycle the ignition from on to off 3 times. Turn the ignition on. With the scan tool, read DTCs. Does the scan tool display: U0020-CAN INTERIOR BUS OFF PERFORMANCE? Yes Go to step 2 No The conditions that caused this code to set are not present at this time. Using the wiring diagram/schematic as a guide, inspect the wiring and connectors. Perform the BODY VERIFICATION TEST. Refer to «DTC-Based Diagnostics/MODULE, Totally Integrated Power (TIPM) - Standard Procedure»(/dodge/journey/i-2007-2011/remont/communication-devices/#body-verification-test-tipm)
  2. CHECK FRONT CONTROL MODULE DTCs With the scan tool, read Totally Integrated Power Module DTCs. Does the scan tool display any CAN INTERIOR BUS DTCs - ACTIVE? Yes Go to and perform the appropriate diagnostic procedure. No Go to step 3
  3. CAN INTERIOR BUS (+) CIRCUIT OPEN Turn the ignition off. Disconnect the Amplifier C1 harness connector. Disconnect the Totally Integrated Power Module C7 harness connector. Measure the resistance of the (D265) CAN INTERIOR BUS (+) circuit between the Totally Integrated Power module C7 harness connector and the Amplifier C1 harness connector. Is the resistance below 2.0 ohms? Yes Go to step 4 Perform the BODY VERIFICATION TEST. Refer to «DTC-Based Diagnostics/MODULE, Totally Integrated Power (TIPM) - Standard Procedure»(/dodge/journey/i-2007-2011/remont/communication-devices/#body-verification-test-tipm) No Repair the CAN INTERIOR BUS (+) circuit for an open. Perform the BODY VERIFICATION TEST. Refer to «DTC-Based Diagnostics/MODULE, Totally Integrated Power (TIPM) - Standard Procedure»(/dodge/journey/i-2007-2011/remont/communication-devices/#body-verification-test-tipm)
  4. CAN INTERIOR BUS (-) CIRCUIT OPEN Measure the resistance of the (D264) CAN INTERIOR BUS (-) circuit between the Totally Integrated Power Module C7 harness connector and the Amplifier C1 harness connector. Is the resistance below 2.0 ohms? Yes Replace the Amplifier in accordance with the Service Information. Perform the BODY VERIFICATION TEST. Refer to «DTC-Based Diagnostics/MODULE, Totally Integrated Power (TIPM) - Standard Procedure»(/dodge/journey/i-2007-2011/remont/communication-devices/#body-verification-test-tipm) No Repair the CAN INTERIOR BUS (-) circuit for an open. Perform the BODY VERIFICATION TEST. Refer to «DTC-Based Diagnostics/MODULE, Totally Integrated Power (TIPM) - Standard Procedure»(/dodge/journey/i-2007-2011/remont/communication-devices/#body-verification-test-tipm)
