Scheme 48
Scheme 49
| Callout | Component Name |
|---|---|
| 1 | Upper I/P Trim Panel |
| 2 | Remote Control Door Lock Receiver (RCDLR) |
Scheme 50
| Connector Part Information OEM: 12059162 Service: 12102635 Description: 4-Way F Micro-Pack 100 Series (BU) |
|---|
| Terminal Part Information Terminal: 12146447/Tray 3 Core/Insulation Crimp: E/C Release Tool/Test Probe: 12031876-1/J-35616-6 |
Keyless Entry Connector End Views
| Pin | Wire Color | Circuit No. | Function |
|---|---|---|---|
| 1 | RD/WH | 640 | Battery Positive Voltage |
| 2 | TN/WH | 1455 | Keyless Entry Signal |
| 3 | Not Used | ||
| 4 | BK/WH | 1551 | Ground |
Remote Control Door Lock Receiver (RCDLR)
Test Description
The number below refers to the step number on the diagnostic table.
- 3: This step checks for a short to voltage.
| Step | Action | Yes | No |
|---|---|---|---|
| Schematic Reference: Keyless Entry Schematics Connector End View Reference: Keyless Entry Connector End Views | |||
| 1 | Did you perform the Diagnostic System Check - Vehicle? | Go to Step 2 | Go to Diagnostic System Check - Vehicle in Vehicle DTC Information |
| 2 | Turn OFF the ignition. Disconnect the remote control door lock receiver (RCDLR). Connect a test lamp from the keyless entry serial data circuit to a good ground. Turn ON the ignition, with the engine OFF. Does the test lamp illuminate? | Go to Step 3 | Go to Step 4 |
| 3 | Test the keyless entry serial data circuit for a short to voltage. Refer to Circuit Testing and Wiring Repairs in Wiring Systems. Did you find and correct the condition? | Go to Step 8 | Go to Step 5 |
| 4 | Inspect for poor connections at the harness connector of the RCDLR. Refer to Testing for Intermittent Conditions and Poor Connections and Connector Repairs in Wiring Systems. Did you find and correct the condition? | Go to Step 8 | Go to Step 6 |
| 5 | Inspect for poor connections at the harness connector of the body control module (BCM). Refer to Testing for Intermittent Conditions and Poor Connections and Connector Repairs in Wiring Systems. Did you find and correct the condition? | Go to Step 8 | Go to Step 7 |
| 6 | Replace the RCDLR. Refer to Control Module References in Computer/Integrating Systems for replacement, setup and programming. Did you complete the replacement? | Go to Step 8 | |
| 7 | Replace the BCM. Refer to Control Module References in Computer/Integrating Systems for replacement, setup and programming. Did you complete the replacement? | Go to Step 8 | |
| 8 | Use the scan tool in order to clear the DTCs. Operate the vehicle within the Conditions for Running the DTC as specified in the supporting text. Does the DTC reset? | Go to Step 2 | System OK |
DTC B3101
The number below refers to the step number on the diagnostic table.
- 3: This step checks the keyless entry serial data circuit for voltage supplied by the BCM.
| Step | Action | Value(s) | Yes | No |
|---|---|---|---|---|
| Schematic Reference: Keyless Entry Schematics Connector End View Reference: Keyless Entry Connector End Views | ||||
| 1 | Did you perform the Diagnostic System Check - Vehicle? | Go to Step 2 | Go to Diagnostic System Check - Vehicle in Vehicle DTC Information | |
| 2 | Install a scan tool. Turn ON the ignition, with the engine OFF. With a scan tool, observe the status of DTC B3102. Is the DTC B3102 a current code? | Go to Step 3 | Go to Testing for Intermittent Conditions and Poor Connections in Wiring Systems | |
| 3 | Turn OFF the ignition. Disconnect the remote control door lock receiver (RCDLR). Connect a DMM from the keyless entry serial data circuit to a good ground. Turn ON the ignition, with the engine OFF. Observe the voltage. Does the DMM indicate the specified value? | B+ | Go to Step 5 | Go to Step 4 |
| 4 | Test the keyless entry serial data circuit for a short to ground. Refer to Circuit Testing and Wiring Repairs in Wiring Systems. Did you find and correct the condition? | Go to Step 9 | Go to Step 6 | |
| 5 | Inspect for poor connections at the harness connector of the RCDLR. Refer to Testing for Intermittent Conditions and Poor Connections and Connector Repairs in Wiring Systems. Did you find and correct the condition? | Go to Step 9 | Go to Step 7 | |
| 6 | Inspect for poor connections at the harness connector of the body control module (BCM). Refer to Testing for Intermittent Conditions and Poor Connections and Connector Repairs in Wiring Systems. Did you find and correct the condition? | Go to Step 9 | Go to Step 8 | |
| 7 | Replace the RCDLR. Refer to Control Module References in Computer/Integrating Systems for replacement, setup and programming. Did you complete the replacement? | Go to Step 9 | ||
| 8 | Replace the BCM. Refer to Control Module References in Computer/Integrating Systems for replacement, setup and programming. Did you complete the replacement? | Go to Step 9 | ||
| 9 | Use the scan tool in order to clear the DTCs. Operate the vehicle within the Conditions for Running the DTC as specified in the supporting text. Does the DTC reset? | Go to Step 2 | System OK | |
DTC B3102
The numbers below refer to the step numbers on the diagnostic table.
- 3: B+ voltage should be present on the serial data terminal when tested with a DMM, but should not illuminate the test lamp. An illuminated test lamp indicates a short to voltage in the serial data circuit.
- 4: This step checks for a short to voltage in the keyless entry serial data circuit.
| Step | Action | Yes | No |
|---|---|---|---|
| Schematic Reference: Keyless Entry Schematics Connector End View Reference: Keyless Entry Connector End Views | |||
| 1 | Did you perform the Diagnostic System Check - Vehicle? | Go to Step 2 | Go to Diagnostic System Check - Vehicle in Vehicle DTC Information |
| 2 | Install a scan tool. Turn ON the ignition, with the engine OFF. With a scan tool, observe the status of DTC B3103. Is the DTC B3103 a current code? | Go to Step 3 | Go to Diagnostic Aids |
| 3 | Turn OFF the ignition. Disconnect the remote control door lock receiver (RCDLR). Connect a test lamp from the keyless entry serial data circuit to a good ground. Turn ON the ignition, with the engine OFF. Does the test lamp illuminate? | Go to Step 4 | Go to Step 5 |
| 4 | Test the keyless entry serial data circuit for a short to voltage. Refer to Testing for a Short to Voltage and Wiring Repairs in Wiring Systems. Did you find and correct the condition? | Go to Step 9 | Go to Step 6 |
| 5 | Inspect for poor connections at the harness connector of the RCDLR. Refer to Testing for Intermittent Conditions and Poor Connections and Connector Repairs in Wiring Systems. Did you find and correct the condition? | Go to Step 9 | Go to Step 7 |
| 6 | Inspect for poor connections at the harness connector of the body control module (BCM). Refer to Testing for Intermittent Conditions and Poor Connections and Connector Repairs in Wiring Systems. Did you find and correct the condition? | Go to Step 9 | Go to Step 8 |
| 7 | Replace the RCDLR. Refer to Control Module References in Computer/Integrating Systems for replacement, setup and programming. Did you complete the replacement? | Go to Step 9 | |
| 8 | Replace the BCM. Replace the RCDLR. Refer to Control Module References in Computer/Integrating Systems for replacement, setup and programming. Did you complete the replacement? | Go to Step 9 | |
| 9 | Use the scan tool in order to clear the DTCs. Operate the vehicle within the Conditions for Running the DTC, as specified in the supporting text. Does the DTC reset? | Go to Step 2 | System OK |
DTC B3103
Unlock All Doors - Second Operation
Momentarily press the UNLOCK button a second time, within 5 seconds of the first press, in order to perform the following functions
- Unlock all of the doors.
- Illuminate the interior lamps for approximately 20 seconds or until the ignition is turned ON.
