Door System, Mirror System & Window System: Specifications Chevrolet Uplander I

Door Locks & Anti-Theft Systems 20 illustrations

Fastener Tightening Specifications

ApplicationSpecification
MetricEnglish
Armrest Screws3 N.m26 lb ft
Bearing Bushing Screw2 N.m18 lb in
Cable Guide Bracket Bolts10 N.m89 lb in
Cone Adjuster Bolt (Body Side)10 N.m89 lb in
Front Door Lock Actuator Screws2 N.m18 lb in
Front Door Lock Module Screws10 N.m89 lb in
Front Door Lock Striker Screws25 N.m18 lb ft
Front Door Outside Handle Screws10 N.m89 lb in
Front Door Pull Handle Screws2 N.m18 lb in
Front Door Window Run Channel Screws10 N.m89 lb in
Front Quarter Window Hinge Stud Nuts10 N.m89 lb in
Front Quarter Window Latch Screws10 N.m89 lb in
Motor Clutch Assembly Bolts10 N.m89 lb in
Motor Clutch Assembly Nuts10 N.m89 lb in
Outside Rearview Mirror Motor Screws10 N.m89 lb in
Outside Rearview Mirror Nuts10 N.m89 lb in
Power Rear Quarter Window Actuator Screws10 N.m89 lb in
Power Sliding Door Latch Detent Switch Retaining Screws0.9 N.m8.5 lb in
Power Sliding Door Latch Release Actuator Screws10 N.m89 lb in
Rear Quarter Window Hinge Stud Nuts10 N.m89 lb in
Rear Quarter Window Latch Screws10 N.m89 lb in
Sliding Door Catch with Reinforcement Channel Bolt25 N.m18 lb ft
Sliding Door Center Roller Bracket (Door Side) Bolts25 N.m18 lb ft
Sliding Door Center Track Bracket Screws10 N.m89 lb in
Sliding Door Center Track Cover Front Screw2 N.m18 lb in
Sliding Door Center Track Cover Rear Screw10 N.m89 lb in
Sliding Door Center Track Screws10 N.m89 lb in
Sliding Door Locating Pin Screws10 N.m89 lb in
Sliding Door Locating Pocket Screws10 N.m89 lb in
Sliding Door Lock Actuator Screws10 N.m89 lb in
Sliding Door Lock Screws10 N.m89 lb in
Sliding Door Lower Roller Bracket Bolts10 N.m89 lb in
Sliding Door Outside Handle Nuts12 N.m106 lb in
Sliding Door Striker Screws10 N.m89 lb in
Sliding Door Swing Out Window Hinge Stud Nuts25 N.m18 lb ft
Sliding Door Swing Out Window Latch Screws10 N.m89 lb in
Sliding Door Upper Roller Bracket Bolts10 N.m89 lb in
Sliding Door Upper Track Screws10 N.m89 lb in
Upper and Lower Body Side Hinge Bolts33 N.m24 lb ft
Upper and Lower Door Side Hinge Bolts33 N.m24 lb ft

Fastener Tightening Specifications

Scheme 1

Scheme 1: Power Window Schematics
Scheme 1: Power Window Schematics

Scheme 2

Scheme 2: Door Lock/Indicator Schematics
Scheme 2: Door Lock/Indicator Schematics

Scheme 3

Scheme 3
Scheme 3

Scheme 4

Scheme 4
Scheme 4

Scheme 5

Scheme 5: Outside Mirror Schematics
Scheme 5: Outside Mirror Schematics

Scheme 6

Scheme 6
Scheme 6

Scheme 7

Scheme 7: Power Sliding Door (PSD) Schematics
Scheme 7: Power Sliding Door (PSD) Schematics

Scheme 8

Scheme 8
Scheme 8

Scheme 9

Scheme 9
Scheme 9

Scheme 10

Scheme 10
Scheme 10

Scheme 11

Scheme 11: Power Door Systems Component Views
Scheme 11: Power Door Systems Component Views
CalloutComponent Name
1Passenger Door Trim Panel
2Door Lock Switch - Passenger
3Window Switch - Passenger
4Door Latch Assembly - Passenger
5Speaker - RF
6Door Latch Assembly - Driver
7Driver Door Trim Panel
8Window Switch - Driver
9Door Lock Switch - Driver
10Outside Rearview Mirror Switch
11Speaker - LF

Scheme 12

Scheme 12
Scheme 12
CalloutComponent Name
1Outside Rearview Mirror Switch - Left Connector
2Window Switch - Driver Connector
3Door Lock Switch - Driver Connector
4Outside Rearview Mirror - Driver
5C301 Driver Door Harness to Body Harness
6Window Motor - Driver
7Speaker - LF
8S555
9Memory Seat Switch - Driver (AG0) Connector
10S551
11Driver Door Key Switch Connector
12Door Latch Assembly - Driver
13Driver Door Key Switch (AU6)

Scheme 13

Scheme 13
Scheme 13
CalloutComponent Name
1Door Lock Switch - Passenger Connector
2Window Switch - Passenger Connector
3Door Latch Assembly - Passenger
4S660
5S666
6Window Motor - Passenger
7C302 Passenger Door Harness to Body Harness
8Outside Rearview Mirror - Passenger

Scheme 14

Scheme 14
Scheme 14
CalloutComponent Name
1Right B-Pillar
2Sliding Door Open/Close Switch - Right (E58) Connector
3C308 Body Harness to Headliner Harness
4G302
5Courtesy/Reading Lamp - Center
6Cargo Lamp

Scheme 15

Scheme 15
Scheme 15
CalloutComponent Name
1Left Sliding Door Module (LSDM) (E59)
2Sliding Door Motor Assembly - Left (E59)
3Sliding Door Unlatch Actuator - Left (E59)
4Door Lock Actuator - Left Middle
5Door Contact Plate - Left C2
6S751 (E59)
7Sliding Door Detent Switch - Left (E59) Connector
8Sliding Door Cable Motor - Left (E59)

Scheme 16

Scheme 16
Scheme 16
CalloutComponent Name
1Sliding Door Cable Motor - Right (E58)
2Sliding Door Motor Assembly - Right (E58)
3Right Sliding Door Module (RSDM) (E58)
4Sliding Door Detent Switch - Right (E58) Connector
5Door Contact Plate - Right C2
6Door Lock Actuator - Right Middle
7Sliding Door Unlatch Actuator - Right (E58)
8S848 (E58)

Scheme 17

Scheme 17
Scheme 17
CalloutComponent Name
1G301
2Sliding Door Open/Close Switch - Left (E59) Connector
3Inflatable Restraint Side Impact Module - Left (AJ7)
4Inflatable Restraint Side Impact Sensing Module (SISM) - Left (AJ7)
5Body Harness
6C315 Left Side Impact Module Jumper Harness (AJ7) to Body Harness (AJ7)
7C305 Fuel Tank Harness and Rear Cross-Car Jumper Harness to Body Harness
8Seatbelt Pretensioner - LF
9Door Contact Plate - Left C1

Scheme 18

Scheme 18
Scheme 18
CalloutComponent Name
1Inflatable Restraint Side Impact Sensing Module (SISM) - Right (AJ7)
2G302
3Door Contact Plate - Right C1
4Seatbelt Pretensioner - RF
5Inflatable Restraint Sensing and Diagnostic Module (SDM)
6Body Harness
7C316 Inflatable Restraint Side Impact Module - Right Jumper Harness (AJ7) to the Body Harness (AJ7)
8Inflatable Restraint Passenger Seat Belt Tension Retractor Sensor
9Inflatable Restraint Side Impact Module - Right (AJ7)

Scheme 19

Scheme 19
Scheme 19
CalloutComponent Name
1Rear Window Wiper Motor
2Speakers - LR/RR
3Door Jamb Switch - Liftgate
4Door Lock Actuator - Liftgate
5Liftgate Latch Assembly

Scheme 20

Scheme 20: Door Contact Plate - Left C1
Scheme 20: Door Contact Plate - Left C1
Connector Part Information OEM: 12160716 Service: 15305855 Description: 8-Way F Metri-Pack 280 Series (BK) Body Side Connector
Terminal Part Information Pins: A, B, E Terminal: 12066214/Tray 2 Core/Insulation Crimp: F/D Release Tool/Test Probe: 12094430/J-35616-4A Pins: C, D, G Terminal:12015858/Tray 4 Core/Insulation Crimp: See Terminal Repair Kit Release Tool/Test Probe: 12094430/J-35616-4A Pins: F Terminal:12034046/Tray 2 Core/Insulation Crimp: E/A Release Tool/Test Probe: 12094430/J-35616-4A

Power Door Systems Connector End Views

PinWire ColorCircuit No.Function
AGY295Door Lock Actuator Lock Control
BTN294Door Lock Actuator Unlock Control
CBK550Ground (E59)
DBK550Ground (E59)
EYE2617Left Sliding Door Detent Switch Signal (E59)
YE2617Left Sliding Door Detent Switch Signal (E59)
FYE2617Left Sliding Door Detent Switch Signal (E59)
GD-GN1898Left Sliding Door Latch Motor Control (E59)
HNot Used

Door Contact Plate - Left C1
